Lenovo M90a G5 23.8-Inch All-in-One PC – Intel Core i5-14500 Touch

The Lenovo M90a G5 All-in-One PC is designed for professional environments that demand reliable performance and a clean, space-saving setup. Powered by an Intel Core i5-14500 processor, it delivers responsive performance for everyday business applications and multitasking.

With a 23.8-inch Full HD IPS display featuring 10-point multi-touch support, this all-in-one PC enhances productivity and interaction while reducing desk clutter. Fast NVMe storage, modern connectivity, and Windows 11 Pro make it well suited for secure and efficient office and hybrid work environments.

Key Features

Intel Core i5-14500 processor for reliable business performance
23.8-inch Full HD IPS anti-glare display
10-point multi-touch screen for intuitive interaction
256GB PCIe 4.0 NVMe solid-state storage
Integrated Intel UHD Graphics 770
Wi-Fi and Bluetooth connectivity
Keyboard and mouse included
All-in-one design reduces cable clutter and saves desk space
Windows 11 Pro pre-installed

Technical Specifications

Processor: Intel Core i5-14500
Display: 23.8 inch FHD 1920 x 1080 IPS anti-glare touch display
Memory: 8GB DDR5-4800 SO-DIMM
Storage: 256GB M.2 2280 PCIe 4.0 x4 NVMe SSD
Graphics: Integrated Intel UHD Graphics 770
Wireless: Wi-Fi and Bluetooth
Operating System: Windows 11 Pro
Form Factor: All-in-One desktop
SKU: 12SH001AAU

(12SH001AAU)

PERFORMANCE Processor Intel® Core i5-14500, 14C (6P + 8E) / 20T, P-core 2.6 / 5.0GHz, E-core 1.9 / 3.7GHz, 24MB Graphics Integrated Intel® UHD Graphics 770 Chipset Intel® Q670 Chipset Memory 1x 8GB SO-DIMM DDR5-4800 Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable Max Memory Models with Core i3/i5: Up to 64GB DDR5-4800 Models with Core i7: Up to 64GB DDR5-5200 Storage 256GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 Storage Support Models with Intel® UHD graphics: Up to two drives, 2x M.2 SSD M.2 SSD up to 2TB each Card Reader 3-in-1 Card Reader Optical None Audio Chip High Definition (HD) Audio, Realtek® ALC233NL-VB2-CG codec Speakers 3Wx2 Camera 5.0MP + IR Hybrid Microphone 2x, Array Power Supply 180W 90% DESIGN Display 23.8" FHD (1920x1080) IPS Anti-glare 250nits, 60Hz, 99% sRGB, hardware low blue light, flick free, eyesafe, non-touch Touchscreen None Keyboard USB Traditional Keyboard, Black, English Mouse USB Calliope Mouse, Black Optional Bay None Expansion Slots Models with Intel® UHD graphics: Three M.2 slots (one for WLAN, two for SSD) Case Color Black Stand UltraFlex V Stand Mounting VESA mount Form Factor AIO (23.8 inches) Dimensions (WxDxH) Lowest in flat mode: 539.6 x 344.19 x 227.54 mm (21.24 x 13.55 x 8.96 inches) Highest in vertical mode: 539.6 x 252.60 x 472.00 mm (21.24 x 9.94 x 18.58 inches) Weight Around 7.83 kg (17.3 lbs) CONNECTIVITY Ethernet Integrated 100/1000M WLAN + Bluetooth Intel® Wi-Fi® 6 AX201, 11ax 2x2 + BT5.2 Rear Ports 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 15W charging 3x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x HDMI® (HDMI in 1.4 / HDMI out 2.1 TMDS combo port) 1x DisplayPort 1.4 1x Ethernet (RJ-45) Right Ports 3x USB-A (USB 10Gbps / USB 3.2 Gen 2) 1x headphone / microphone combo jack (3.5mm) Optional Right Ports (configured) 1x card reader Optional Ports (configured) None SECURITY & PRIVACY Security Chip Discrete TPM 2.0, TCG certified, FIPS 140-2 certified Fingerprint Reader No fingerprint reader Physical Locks Kensington® Security Slot, 3 x 7 mm Chassis Intrusion Switch Chassis Intrusion Switch Additional Security None Other Security ThinkShutter camera cover MANAGEABILITY System Management Non-vPro® SERVICE Base Warranty 3-year, Onsite Included Upgrade None CERTIFICATIONS Green Certifications ENERGY STAR® 8.0 EPEAT Gold Registered ErP Lot 3 GREENGUARD® RoHS compliant TCO Certified 9.0 TCO edge Other Certifications TÜV Rheinland® Low Blue Light (Hardware Solution) Eyesafe® Certified 2.0 TÜV Rheinland® Flicker Free UL Anti-dust Mil-Spec Test MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Fungus, Solar Radiation, Contamination by Fluids, Salt Fog) SOFTWARE Operating System Windows® 11 Pro, English Bundled Software None ACCESSORIES Bundled Accessories None
