14-inch Portable Touch Monitor

Lenovo ThinkVision M14t Gen 2 Monitor

The Lenovo ThinkVision M14t Gen 2 is a 14-inch portable monitor featuring a 2240 x 1400 IPS display, 10-point capacitive touch, a passive digital pen, dual USB-C connectivity and an adjustable tilt, pivot and height stand. The monitor weighs approximately 0.7 kg and comes in Raven Black.

What is the Lenovo ThinkVision M14t Gen 2?

The ThinkVision M14t Gen 2, model 63FDUAR6AU, is a 14-inch 16:10 mobile IPS monitor with 2240 x 1400 resolution. It combines 10-point capacitive touch input, a supplied passive touch pen, two USB-C ports with DisplayPort 1.2 and USB PD 2.0, and an adjustable integrated stand.

14" 2240 x 1400 IPS display with 16:10 aspect ratio

10-Point Capacitive touchscreen with passive digital pen

2 × USB-C DisplayPort 1.2 and USB PD 2.0, up to 65W PD

0.7 kg Approximate monitor weight for mobile use

High-Resolution 14-inch IPS Display

A compact 16:10 display with wide viewing angles and 100% sRGB colour gamut.

2240 x 1400 Resolution

The 14-inch WLED-backlit In-Plane Switching panel provides a 2240 x 1400 resolution, 189 dpi pixel density and a 16:10 aspect ratio.

Wide Viewing Angles

The IPS panel provides horizontal and vertical viewing angles of 178° / 178°.

100% sRGB

The display supports 16.7 million colours, a 100% sRGB colour gamut and a 1500:1 contrast ratio.

Touch and Pen Input

Direct interaction through a 10-point capacitive touch panel and supplied passive pen.

The ThinkVision M14t Gen 2 features a 10-point capacitive touchscreen. Lenovo also specifies a passive digital pen, with one touch pen included in the box.

The display operates at a 60Hz refresh rate with a 6ms response time in Extreme mode and an 8ms response time in Typical mode.

Adjustable Integrated Stand

Flexible tilt, pivot and lift adjustment is built into the monitor design.

0° to +90° Tilt

The integrated stand supports tilt adjustment from 0° to +90°.

-90° to +90° Pivot

Pivot adjustment from -90° to +90° provides flexible screen positioning.

11 mm Lift

The stand provides 11 mm of lift adjustment and the monitor also supports a 100 mm VESA mounting pattern using two holes.

Dual USB-C Connectivity

Matching USB-C connectivity is provided on both sides of the monitor.

The left and right sides each provide one USB-C port supporting Hi-Speed USB / USB 2.0, USB PD 2.0 and DisplayPort 1.2, with up to 65W power delivery.

Display Comfort Features

Low blue light features and ergonomic certifications are included in the supplied specification.

The ThinkVision M14t Gen 2 includes Natural Low Blue Light and is listed with Eyesafe Display 2.0, TÜV Low Blue Light hardware solution and TÜV Rheinland Low Blue Light ergonomic certifications.

Brightness is specified as 300 cd/m² at the panel and 270 cd/m² for the set. Power consumption is listed as 8W typical and 9.5W maximum.

Lenovo Accessories and Display Manager

Display management software support across multiple operating systems.

Lenovo Accessories and Display Manager supports Windows 10, Windows 11, Mac OS and Windows on Arm, with functions varying across systems. Lenovo Accessories and Display Manager was formerly known as Lenovo Display Control Center.

The supplied operating system support specification lists Windows 10 and Windows 11.

What's Included

Supplied components listed for model 63FDUAR6AU.

Monitor with stand
1 × USB-C to USB-C cable, 1 m, 5Gbps
2 × clips
1 × touch pen
1 × L-shape dongle
1 × protect bag
Quick setup guide

Frequently Asked Questions

Key information about the Lenovo ThinkVision M14t Gen 2 63FDUAR6AU.

What resolution does the ThinkVision M14t Gen 2 have?

It has a 14-inch IPS display with 2240 x 1400 resolution and a 16:10 aspect ratio.

Does the ThinkVision M14t Gen 2 have a touchscreen?

Yes. It has a 10-point capacitive touch panel.

Is a pen included?

Yes. The supplied specification lists a passive digital pen and includes one touch pen in the box.

What connections does the monitor provide?

It has two USB-C ports, one on each side. Each supports Hi-Speed USB / USB 2.0, USB PD 2.0 and DisplayPort 1.2, with up to 65W PD.

Can the stand be adjusted?

Yes. The integrated stand supports 0° to +90° tilt, -90° to +90° pivot and 11 mm of lift adjustment.

How much does the ThinkVision M14t Gen 2 weigh?

Lenovo lists an approximate monitor weight of 0.7 kg and a packaging weight of 1.9 kg.

What warranty is supplied?

The supplied specification lists a 3-year limited warranty.

Product dimensions and weight may vary according to configuration, component variation and manufacturing processes. Product imagery in the supplied Lenovo material is illustrative and may not exactly match the actual appearance or colour of the model.

(63FDUAR6AU)

Lenovo ThinkVision M14t Gen 2 63FDUAR6AU Specifications

Display, touch, stand, connectivity, physical, software, certification and included accessory specifications.

Specification	Details
Display
Display Size	14"
View Area	301.6 x 188.5 mm
Panel	In-Plane Switching (IPS)
Backlight	WLED
Aspect Ratio	16:10
Resolution	2240 x 1400
Pixel Pitch	0.1346 x 0.1346 mm
Pixel Density	189 dpi
Viewing Angle	178° horizontal / 178° vertical
Response Time	6ms (Extreme mode) / 8ms (Typical mode)
Colour Support	16.7 million
Refresh Rate	60Hz
Brightness	300 cd/m² (panel) / 270 cd/m² (set)
Contrast Ratio	1500:1
Colour Gamut	100% sRGB
Screen Surface Treatment	None
Curvature	None
Touchscreen	10-point capacitive touch panel
Camera	None
Microphone	None
Speakers	None
Power
Power Consumption	8W typical / 9.5W maximum
Design and Adjustment
Stand	Tilt, pivot and height-adjust stand
Tilt Range	0° to +90°
Pivot Range	-90° to +90°
Lift	11 mm
Case Colour	Raven Black
Side Bezel Width	6.1 mm
Mounting	Supports VESA mount 100 mm, 2 holes
ThinkCentre M Series Support	None
Pen	Digital Pen (Passive)
Dimensions and Weight
Dimensions – Highest Position	314.8 x 96.4 x 235.3 mm 12.39 x 3.8 x 9.26 inches
Dimensions – Lowest Position	314.8 x 96.7 x 224.3 mm 12.39 x 3.81 x 8.83 inches
Lenovo Packaging Dimensions	384 x 76 x 277 mm 15.12 x 2.99 x 10.91 inches
Supplier Carton Dimensions	270 x 260 x 50 mm
Monitor Weight	Approx. 0.7 kg (1.5 lbs) Lenovo notes that system weight is approximate and may vary according to component source, manufacturing variation and configuration.
Packaging Weight	1.9 kg (4.2 lbs)
Connectivity
Left Port	1 × USB-C (Hi-Speed USB / USB 2.0), with USB PD 2.0 and DisplayPort 1.2, up to 65W PD
Right Port	1 × USB-C (Hi-Speed USB / USB 2.0), with USB PD 2.0 and DisplayPort 1.2, up to 65W PD
Software and Features
Operating System Support	Windows 10, Windows 11
Lenovo Accessories and Display Manager	Supports Windows 10 & 11, Mac OS and Windows on Arm. Functions vary across systems. Formerly Lenovo Display Control Center.
Special Feature	Natural Low Blue Light
Sync Technology	None
Certifications
Environmental Certifications	ENERGY STAR Certified, EPEAT Gold, RoHS, EU Energy Efficiency Level (Level-C)
Ergonomic Certifications	Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Low Blue Light
Warranty
Base Warranty	3-year limited warranty
In the Box
Included Items	Monitor with stand 1 × USB-C to USB-C cable (1 m, 5Gbps) 2 × clips 1 × touch pen 1 × L-shape dongle 1 × protect bag Quick setup guide
Model Information
Model	63FDUAR6AU
Machine Type	63FD
Region	APS
EAN / UPC / JAN	0197531619846 / 197531619846 / None
Announce Date	2024-05-24

SKU	63FDUAR6AU
Barcode #	197531619846
Brand	Lenovo
Shipping Weight	1.0000kg
Shipping Width	0.270m
Shipping Height	0.050m
Shipping Length	0.260m
Shipping Cubic	0.003510000m3
