Enterprise Layer 2++ Managed PoE Switch

Grandstream GWN7806PH Pro

The Grandstream GWN7806PH Pro is an enterprise Layer 2++ managed network switch with 48 Gigabit Ethernet PoE ports and six 10Gbps SFP+ ports. It provides a 720W total PoE output budget, support for PoE, PoE+ and PoE++, advanced traffic control, comprehensive security features, switch stacking and flexible local, cloud, software and command-line management.

What is the Grandstream GWN7806PH Pro?

The GWN7806PH Pro is a high-capacity, fully manageable network switch designed for demanding business networks. It combines 48 Gigabit Ethernet PoE ports with six SFP+ uplink ports, switching capability of 216Gbps and support for stacking up to eight GWN7806 Pro devices.

48 × Gigabit Ethernet ports with dynamic PoE, PoE+ and PoE++ output

6 × SFP+ High-speed uplink ports supporting network speeds up to 10Gbps

720W PoE Total PoE output budget with up to 60W available per port

216Gbps Switching capability with 108Gbps non-blocking throughput

High-Capacity Enterprise Connectivity

Gigabit PoE access ports and 10Gbps SFP+ uplinks support scalable business network deployments.

The GWN7806PH Pro includes 48 Gigabit Ethernet ports and six SFP+ ports. The switch uses store-and-forward operation and provides 108Gbps total non-blocking throughput, 216Gbps switching capability and a forwarding rate of 160.704Mpps.

Supported SFP+ modules include up to six SM-10G modules, six MM-10G modules or three RJ45-10G modules. RJ45-10G modules must be inserted at intervals as specified in the supplied datasheet.

Dynamic PoE++ Power Management

Smart PoE controls provide flexible power delivery and allocation across connected endpoints.

IEEE 802.3af/at/bt

All 48 PoE ports support IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt standards, with up to 60W output per port.

720W PoE Budget

A maximum total PoE output of 720W supports the distributed power requirements of compatible PoE endpoints.

Port-Level Power Controls

Supports scheduled PoE operation, port priorities, maximum power settings and dynamic power negotiation through LLDP-MED.

Layer 2++ Switching and Traffic Control

Advanced VLAN, routing, multicast and QoS capabilities support segmented and prioritised networks.

Switching and Routing

4K VLANs with IEEE 802.1Q VLAN tagging
Port, MAC and protocol-based VLANs
QinQ, VLAN mapping, VLAN stacking and Private VLAN
32 VLAN virtual interfaces with 9216 MTU
Policy routing
Up to 1K IPv4 and 1K IPv6 user-defined static routes
STP, RSTP, MSTP, PVST(+) and RPVST(+) spanning-tree support
Static and LACP link aggregation with up to 32 LAG groups

Multicast and QoS

IGMPv2 and IGMPv3 Snooping with up to 640 groups
MLDv1 and MLDv2 Snooping with up to 640 groups
Port priority and priority mapping
SP, WRR, WFQ, SP-WRR and SP-WFQ queue scheduling
Traffic shaping and rate limiting
Pro AV traffic control
IPv4, IPv6 and mixed IPv4/IPv6 deployment support

Advanced Network Security

Authentication, packet inspection and port protection features help defend the network against unauthorised access and common attacks.

Source and ARP Protection

Includes ARP Inspection, IP and IPv6 Source Guard, DHCP and DHCPv6 Snooping, ND Snooping and invalid MAC address filtering.

Authentication and Access Control

Supports 802.1X, MAC authentication, RADIUS, TACACS, AAA, hierarchical user management and password protection.

Attack and Loop Protection

Provides DoS prevention, storm control, CPU protection, port isolation, port security and multiple loop protection mechanisms.

Stacking and Enhanced Reliability

Hardware monitoring, redundancy and stacking features support continuous business network operation.

Up to eight GWN7806 Pro switches can be logically stacked and managed as one virtual device. Stacking can expand available ports, bandwidth and processing capacity while supporting redundant backups between member switches and link aggregation across devices.

The GWN7806PH Pro supports a 1+1 external redundant power supply configuration with one power supply provided by default. It also includes dual-boot hardware redundancy, dual system-file redundancy, power-supply and fan fault alarms, automatic fan-speed control, temperature monitoring and surge protection.

Flexible Management and Monitoring

Manage the switch locally, in the cloud, through on-premise software or using supported command-line and monitoring protocols.

Management Platforms

Embedded controller through the local Web UI
GDMS Networking cloud management
GWN Manager on-premise software controller
GWN App
Compatible GWN Series Routers
Console, Telnet and SSH command-line management
SNMPv1, SNMPv2c and SNMPv3

Monitoring and Diagnostics

CPU and memory usage monitoring
Power-supply, fan and temperature alarms
RMON, Syslog and traffic statistics
Ping, traceroute and Ping watchdog
SPAN and RSPAN port mirroring
Copper testing and fibre-module diagnostics
Backup, restore and mass provisioning

Frequently Asked Questions

Quick answers about the Grandstream GWN7806PH Pro.

How many Ethernet and SFP+ ports does the GWN7806PH Pro have?

It has 48 Gigabit Ethernet ports and six SFP+ ports.

Does every Ethernet port support PoE++?

Yes. The 48 PoE ports support IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt, with up to 60W output per port.

What is the total PoE power budget?

The supplied datasheet specifies a maximum total PoE output of 720W.

What is the maximum SFP+ network speed?

The SFP+ ports support network speeds up to 10Gbps.

Can multiple GWN7806 Pro switches be stacked?

Yes. The GWN7806 Pro models support stacking of up to eight devices.

How can the switch be managed?

Management options include the embedded Web UI, GDMS Networking, GWN Manager, the GWN App, GWN Series Routers, CLI and SNMP.

Does the GWN7806PH Pro support IPv6?

Yes. It supports IPv4, IPv6 and hybrid IPv4/IPv6 network environments.

Is a rack-mounting kit included?

Yes. The supplied package-content information lists two rack-mounting kits.

(GWN7806PH-Pro)

Grandstream GWN7806PH Pro Specifications

Hardware, PoE, switching, management, security, physical and environmental specifications.

Specification	Details
Product and Interfaces
Model	GWN7806PH Pro
Product Type	Enterprise Layer 2++ managed PoE network switch
Gigabit Ethernet Ports	48
SFP+ Ports	6 × SFP+
Maximum Supported Modules	SM-10G: 6 MM-10G: 6 RJ45-10G: 3 RJ45-10G modules must be inserted at intervals.
Management Port	1 × console port
Other Controls	1 × reset pinhole
LED Indicators
System LED	1 × tri-colour LED for device tracking and status indication
Power Supply LEDs	2 × green LEDs for power-supply PWR and RPS status
Data Transfer LEDs	54 × green LEDs
PoE Supply LEDs	48 × yellow LEDs
System and Performance
Flash	8MB NOR Flash and 128MB NAND Flash
RAM	512MB
CPU	Dual-core MIPS interAptive 1GHz
Forwarding Mode	Store-and-forward
Total Non-Blocking Throughput	108Gbps
Switching Capability	216Gbps
Forwarding Rate	160.704Mpps
Packet Buffer	8.4Mb
Network Latency	<4µs
Power and PoE
Power Input	100–240V AC, 50/60Hz
Redundant Power Supply	1+1 external RPS, one power supply provided by default
External Redundant Power Supply Rating	800W
Maximum Power Consumption	870.9W, including 720W PoE output
Maximum Output Power	870.9W
PoE Standards	IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt
PoE Ports	48
Maximum Output per PoE Port	60W
Maximum Total PoE Output	720W
PoE Management	Dynamic PoE power allocation per port User-defined PoE operating periods PoE port priority settings Maximum allowed power settings per port LLDP-MED dynamic power negotiation
Physical Specifications
Dimensions	440 × 300 × 44mm (17.32 × 11.81 × 1.73 inches), L × W × H
Unit Weight	5.3kg (11.68lb)
Mounting	Desktop or rack-mount; rack-mounting kits included
Fans	4
Package Contents
Included Items	1 × switch 1 × 25cm ground cable 4 × rubber footpads 1 × power-cord anti-trip accessory 8 × KM3 × 6 screws 1 × 1.2m AC cable rated at 10A 1 × simplified Quick Installation Guide 1 × regulatory paper 2 × rack-mounting kits
Environmental and Protection
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-10°C to 60°C (14°F to 140°F)
Operating Humidity	10%–90% RH, non-condensing
Storage Humidity	5%–95% RH, non-condensing
MTBF	70,000 hours
System Monitoring	CPU usage, memory usage, power-supply status, fan status and temperature monitoring with alarms
Fan Management	Automatic speed adjustment and fan-failure alarming
Surge Protection	±6kV common mode for power and ±4kV common mode for network ports
ESD Protection	±12kV contact discharge
Compliance	FCC, CE, RCM and IC
Network Protocols and Stacking
Network Protocols	IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af/at/bt, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1d, IEEE 802.1w, IEEE 802.1s and IEEE 802.1x
Stacking	Yes, up to 8 devices
Switching
Jumbo Frames	Maximum length: 12,288
VLAN	4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, QinQ, MAC-based VLAN, protocol-based VLAN, VLAN mapping, VLAN stacking, VLAN translation, Voice VLAN and Private VLAN
Spanning Tree	STP, RSTP, MSTP, PVST(+) and RPVST(+), with up to 64 instances for MSTP, PVST(+) and RPVST(+)
MAC Address Table	32K static, dynamic or filtering MAC addresses with migration records
Link Aggregation	Static and LACP; up to 32 LAG groups and up to 8 members per group
IP Services and Routing
DHCP and DNS	DHCP client, DHCP server, DHCP relay, DHCP Snooping, DHCPv6 client, DHCPv6 Snooping, ND Snooping and DNS
ARP/NDP	1K static and dynamic ARP/NDP entries
VLAN Interfaces	32 VLAN virtual interfaces with 9216 MTU
IP Routing	Policy routing and up to 1K IPv4 plus 1K IPv6 user-defined static routes
Multicast, AV and QoS
IGMP Snooping	IGMPv2 and IGMPv3 with up to 640 Snooping groups
MLD Snooping	MLDv1 and MLDv2 with up to 640 Snooping groups
AV Control	Pro AV
Quality of Service	Port priority, 802.1p mapping, DSCP mapping, IP precedence mapping, SP, WRR, WFQ, SP-WRR and SP-WFQ scheduling, traffic shaping and rate limiting
ACL and Security
Access Control Lists	256 Ethernet, IPv4 and IPv6 ACLs with 4K ACE; MAC, IPv4, IPv6 and expert ACL support; ACL redirection, statistics, mirroring, priority mapping, rate limiting and port or VLAN binding
Authentication	802.1X, MAC authentication, RADIUS, TACACS and AAA
Management Security	Hierarchical user management, password protection, HTTPS, SSH and Telnet
Network Protection	Storm control, port isolation, port security, sticky MAC, invalid MAC filtering, IP/IPv6 Source Guard, DoS prevention, ARP Inspection and CPU protection
Loop Protection	Port loopback detection, BPDU protection, root protection and loopback protection
Additional Security	Kensington Security Slot support and firmware signature
Reliability and Maintenance
Reliability Features	1+1 redundant power-supply modules, stack intelligent upgrade, dual boot and dual system-file redundancy
Maintenance Services	NTP, CPU and memory monitoring, power-supply and fan fault alarms, SNMPv1/v2c/v3, RMON, LLDP, LLDP-MED, backup and restore, Syslog and sFlow
Diagnostics	Ping, traceroute, Ping watchdog, SPAN and RSPAN mirroring, packet capture, copper testing, fibre-module diagnostics and one-click debugging
Upgrade and Provisioning	FTPS, TFTP, HTTP, HTTPS or local upload; mass provisioning through DHCP Option, GDMS Networking, GWN Manager and GWN Series Routers
Management Platforms
Local Management	Embedded controller through the local Web GUI
Cloud Management	GDMS Networking for GWN7800 Pro Series switches
On-Premise Management	GWN Manager software controller
Mobile Management	GWN App integrating GDMS Networking and GWN Manager
Other Management Options	GWN Series Routers, console, Telnet, SSH, SNMP, RMON and CLI

SKU	GWN7806PH-Pro
