The supplied configuration lists 802.11ax Wi-Fi 6 and Bluetooth 5.x wireless connectivity.
Zebra ZQ610 Plus 2-inch Mobile Direct Thermal Label and Receipt Printer Wi-Fi 6 Bluetooth
Model # ZQ61-AAXAA04-00
-
SKU: ZQ61-AAXAA04-00
Don't pay: $1,737.82
$1,399.00
SAVE $338.82 (20%)
- Pick Up Available
- Australian Warranty
- Checkout Securely
Zebra ZQ610 Plus 2-inch mobile printer with Wi-Fi 6
This Zebra ZQ610 Plus is a 2-inch/48mm mobile label and receipt printer with Wi-Fi 6 802.11ax, Bluetooth 5.x and a supplied belt clip.
2-inch / 48mm formatWi-Fi 6 802.11axBluetooth 5.xBelt clip included
A large display, user-friendly interface and customisable menu provide visible status and direct printer configuration.
The printer can enter sleep mode while idle and wake when a print job is sent over Wi-Fi or Bluetooth.
Supplied media configuration
This configuration includes a linered platen and supports media with a 0.75-inch core.
Portable daily use
A belt clip is included, while the over-moulded, seamless design and tempered-glass display support mobile operation.
Language and font configuration
English, Latin, Traditional Chinese and Korean fonts are listed as part of the supplied Group A configuration.
Key specifications
| Printer family | ZQ610 Plus |
|---|---|
| Mobile print width | 2 inches / 48mm |
| Wi-Fi | Wi-Fi 6 dual radio, 802.11ax |
| Bluetooth | Bluetooth 5.x |
| Media platen | Linered |
| Media core | 0.75 inches |
| Display | Large colour display |
| Operating system | Link-OS |
| Included carrying accessory | Belt clip |
| Fonts | English, Latin, Traditional Chinese and Korean |
| Font group | Group A |
Frequently asked questions
Which wireless standard is supplied?
This configuration lists Wi-Fi 6 dual radio with 802.11ax and Bluetooth 5.x.
Which media core is listed?
The supplied configuration identifies a 0.75-inch core.
Is a belt clip included?
Yes. A belt clip is listed in the supplied configuration.
(ZQ61-AAXAA04-00)
- Apple® iOS, Android™ and Windows® Mobile connectivity
- Direct thermal printing of barcodes, text and graphics
- CPCL, EPL™ and ZPL® programming languages
- 512 MB Flash supports downloadable programs, receipt formats, fonts and graphics (128 MB available for user storage)
- ZQ620 Plus and ZQ610 Plus: 3250 mAh (nominal) 23.4 Wh removable, rechargeable PowerPrecision+ Li-Ion battery
- ZQ630 Plus: 6600 mAh (nominal) 47.5 Wh removable, rechargeable PowerPrecision + Li-Ion battery
- Built-in battery charger
- Belt clip for unobtrusive and convenient printing (not compatible with extended capacity battery)
- Black mark and gap media sensing using fixed center position sensors
- Easy-to-use peel and present mode
Interfaces/Ports
| USB Host | Yes |
Technical Information
| Application/Usage | Mobile |
| Manufacturing | |
| Retail | |
| Warehouse | |
| Transportation & Logistic | |
| Healthcare | |
| Barcode Symbology Supported | FIM Postnet |
| GS1 DataBar (RSS) | |
| Interleaved 2 of 5 | |
| Maxi Code | |
| MSI | |
| EAN-8 | |
| EAN-13 | |
| Data Matrix | |
| Code 93 | |
| Code 39 | |
| Code 128 | |
| Codabar (NW-7) | |
| AZTEC | |
| 2D | |
| 2 and 5 Digits Add-on | |
| Micro PDF-417 | |
| UPC-E | |
| UPC-A | |
| UCC/EAN 128 | |
| TLC 39 | |
| QR Code | |
| POSTNET | |
| Plessey | |
| MSI PLESSEY | |
| PDF417 | |
| Maximum Print Width | 48 mm (1.89") |
| Recommended Use | Label/Receipt Print |
| Features | Water Resistant |
| Belt Clip | |
| Print Technology | Direct Thermal |
| Peel Facility | Yes |
| Print Color Capability | Monochrome |
| Maximum Print Length | 813 mm |
| Character Sets | English |
| Agfa Monotype | |
| Universal Font Scaling Technology (UFST) | |
| Fonts Included | Chinese Korean fonts |
| Ingress Protection (IP) Rating | IP54 |
| Maximum Print Resolution (dpi) | 203 |
Power Description
| Power Source | Battery |
Software
| Operating System Supported |
Link-OS |
Cutter
| Cutter | Yes |
| Cutter Type | Tear Bar |
Memory
| Flash Memory | 512 MB |
| Standard Memory | 256 MB |
Battery Information
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 3250 mAh |
| Battery Included | Yes |
Display & Graphics
| Display Screen | Yes |
| Screen Size | 5.1 cm (2") |
| Display Screen Type | LCD |
Fonts & Emulation
| Language Emulation | CPCL |
| ZPL | |
| XML | |
| EPL |
Miscellaneous
| Platform Supported | SPARC |
| PC | |
| Android | |
| Energy Star | Yes |
Physical Characteristics
| Weight (Approximate) | 600 g |
| Height | 72.4 mm |
| Width | 91.4 mm |
| Depth | 170.9 mm |
Network & Communication
| Bluetooth | Yes |
| Ethernet | Yes |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ac |
| Ethernet Technology | Fast Ethernet |
General Information
| Product Type | Direct Thermal Printer |
| Manufacturer Part Number | ZQ61AAXAA0400 |
| Manufacturer Website Address | http://www.zebra.com/ap/en.html |
| Manufacturer | Zebra Technologies Corporation |
| Product Model | ZQ610 Plus |
| Product Name | ZQ610 Plus Direct Thermal Printer |
| Product Series | ZQ600 Plus |
| Brand Name | Zebra |
Media Types & Handling
| Media Thickness | 165.1 µm |
| Maximum Roll Diameter | 34.90 mm |
| Media Type | Receipt |
| Label | |
| Linered Label | |
| Media Sensor | Black Mark Sensor |
| Gap Sensor | |
| Label Present Sensor | |
| Maximum Label Width | 55.40 mm |
| SKU | ZQ61-AAXAA04-00 |
| Brand | ZEBRA |
| Shipping Weight | 3.0000kg |
| Shipping Width | 0.105m |
| Shipping Height | 0.093m |
| Shipping Length | 0.200m |
