View PDF Brochure
Eight embedded camera channels
The appliance supports expansion to a maximum of twenty-four channels.
QNAP QVP-41C 4-Bay Diskless J6412 8GB High-Performance NVR for Home, SMBs & SOHO
Model # QVP-41C
-
SKU: QVP-41C
- Pick Up Available
- Australian Warranty
- Checkout Securely
QNAP dedicated surveillance NVR
QNAP QVP-41C 4-Bay QVR Pro Surveillance NVR
A diskless 4-bay QVR Pro surveillance appliance with an Intel Celeron J6412 processor, 8GB memory, eight embedded camera channels and support for up to twenty-four channels.
Drive bays4 SATA bays
Embedded channels8 included
Maximum channelsUp to 24
Networking2 × 2.5GbE
Purpose-built QVR Pro surveillance appliance
The QVP-41C runs QVR Pro OS and reserves its system and storage resources for video surveillance. It supports up to twenty-four H.264 camera channels at 1920 × 1080 and 30 FPS, with maximum surveillance throughput listed as 300Mbps.
Storage, local display and camera management
- Four hot-swappable SATA bays support 3.5-inch hard drives and 2.5-inch SATA SSDs; the unit is supplied without drives.
- Two HDMI 1.4b outputs support resolutions up to 4096 × 2160 at 30Hz, with local live-view and playback limits defined in the supplied specifications.
- RAID modes include Single Disk, JBOD, RAID 0, RAID 1, RAID 5, RAID 5 with spare, RAID 6, RAID 10 and RAID 10 with hot spare.
- The supplied description states ONVIF support, compatibility with thousands of cameras from more than 200 brands and Intel OpenVINO support for QVR Face.
Drives and channel planning
Hard drives are not included. Confirm compatible drives, the required camera licences and channel count, and camera compatibility before deployment. The two M.2 2280 PCIe Gen 3 x2 slots are stated not to support features related to QVP software.
Frequently asked questions
Answers below are based only on the supplied product information for QVP-41C.
How many camera channels are included with the QVP-41C?
It includes eight embedded camera channels and supports up to twenty-four channels.
Does the QVP-41C include hard drives?
No. The supplied specifications state that it is supplied without hard drives, so compatible drives are purchased separately.
What processor and memory are installed?
It uses an Intel Celeron J6412 four-core/four-thread processor with 8GB memory installed and support for up to 16GB.
What local display capability is listed?
Two HDMI 1.4b outputs support up to 4096 × 2160 at 30Hz. The supplied limits include up to 24 live cameras at 720p or 12 at 1080p.
Which RAID modes are supported?
The supplied data lists Single Disk, JBOD, RAID 0, RAID 1, RAID 5, RAID 5 with spare, RAID 6, RAID 10 and RAID 10 with hot spare.
What warranty applies to the QVP-41C?
The product is covered by the applicable QNAP manufacturer warranty; the exact duration should be confirmed for this SKU.
(QVP-41C)
Features and highlights
QNAP QVP-41C 4-Bay QVR Pro Surveillance NVR
Four hot-swappable SATA bays
Supports 3.5-inch HDDs and 2.5-inch SATA SSDs; drives are not included.
Dual 2.5GbE networking
Two 2.5 Gigabit Ethernet ports are supplied.
Dual HDMI local display
Two HDMI 1.4b outputs support up to 4096 × 2160 at 30Hz.
Additional supplied highlights
- Intel Celeron J6412 processor with 8GB installed memory and 16GB maximum.
- Up to 300Mbps surveillance throughput.
- ONVIF and Intel OpenVINO/QVR Face support are stated in the supplied description.
- Online RAID capacity expansion and RAID level migration are supported.
Technical specifications
Specifications below are organised from the supplied product information for QVP-41C.
| Specification | Details |
|---|---|
| System and Processor | |
| Operating System | QVR Pro OS (QVP) |
| CPU | Intel Celeron J6412 4-core/4-thread processor, burst up to 2.6GHz |
| CPU Architecture | 64-bit x86 |
| Graphics Processor | Intel UHD Graphics |
| Hardware-Accelerated Transcoding | Yes |
| Flash Memory | 4GB, dual-boot OS protection |
| Memory | |
| System Memory | 8GB |
| Maximum Memory | 16GB, using 2 × 8GB |
| Memory Slots | 2 × SO-DIMM DDR4 |
| Surveillance Capacity | |
| Embedded Channels | 8 |
| Maximum Channels | 24 channels, H.264, 1920 × 1080, 30 FPS |
| Maximum Live Cameras on Local Display | 24 channels at 720p, H.264, 30 FPS 12 channels at 1080p, H.264, 30 FPS |
| Maximum Playback Cameras on Local Display | 12 |
| Maximum Concurrent Client Connections | 8, with 4 live cameras per remote client; the number varies with the number of live cameras |
| Maximum Throughput | 300Mbps |
| Storage | |
| Drive Bays | 4 × 3.5-inch SATA 6Gb/s, 3Gb/s; supplied without hard drives |
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-Swappable | Yes |
| M.2 SSD Slots | 2 × M.2 2280 PCIe Gen 3 x2; the datasheet states these slots do not support features related to QVP software |
| Internal Drive File System | EXT4 |
| Tray Locker | Yes |
| RAID | |
| Supported Storage Modes | Single Disk JBOD RAID 0 RAID 1 RAID 5 RAID 5 + Spare RAID 6 RAID 10 RAID 10 + hot spare |
| RAID Recovery | Yes |
| Online RAID Capacity Expansion | Yes |
| Online RAID Level Migration | Yes |
| Networking and Connectivity | |
| 2.5 Gigabit Ethernet Ports | 2 |
| USB 2.0 Ports | 2 |
| USB 3.2 Gen 2 10Gbps Ports | 2 |
| HDMI Outputs | 2 × HDMI 1.4b, up to 4096 × 2160 at 30Hz |
| Wake on LAN | Yes |
| Physical Specifications | |
| Form Factor | Tower |
| LED Indicators | HDD 14, status, LAN, USB port and M.2 port |
| Buttons | Power, reset and USB Auto Copy |
| Dimensions (H × W × D) | 168.5 × 160.2 × 220.5mm |
| Net Weight | 2.21kg |
| Gross Weight | 3.61kg |
| Fan | 1 × 120mm, 12VDC |
| Sound Level | 16.9dB(A) |
| System Warning | Buzzer |
| Power and Environment | |
| Power Supply | 90W adapter, 100240V |
| HDD Sleep Mode Power Consumption | 28.974W |
| Typical Operating Power Consumption | 35.79W |
| Operating Temperature | 040°C (32104°F) |
| Relative Humidity | 595% RH, non-condensing; wet bulb 27°C (80.6°F) |
| Management | |
| Scheduled Power On/Off | Yes, 15 settings |
| Telnet and SSH Login | Yes, administrator only |
| Syslog Server and Client | Yes |
| Languages | English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil and Greek |
| SKU | QVP-41C |
| Model # | QVP-41C |
| Barcode # | 4711103084359 |
| Brand | QNAP |
| Shipping Weight | 2.9200kg |
QNAPManufacturer warranty
QNAP manufacturer warranty
The QNAP QVP-41C is covered by the applicable QNAP manufacturer warranty.
Warranty coverage, duration, eligibility and claim assessment are subject to QNAP terms for the exact product. Please retain your DeviceDeal tax invoice as proof of purchase.
