Video and Audio Video Input 10 (2-ch analog + 8-ch PoE IPC) Video Compression H.265/smart H.265/H.264/smart H.264 Dual-stream Support (up to D1 encoding for sub stream) Video Frame Rate PAL: 1 to 25 fps; NTSC: 1 to 30 fps Video Output 1-ch VGA; 1-ch HDMI; 1 × CVBS (transfer via EXTEND port) Output resolution: 800×600/1280×1024 Multi-screen Display 1/4/6/8/9/16 split screens Audio Compression G711A/G711U/G726/PCM Audio Output 3 channels Audio Sampling 8KHz, 16Bit Network Band Eurasian Version Latin American Version LTE-FDD: B1/3/5/7/8/20 LTE-TDD: B38/40/41 WCDMA: B1/5/8 GSM/EDGE: B3/8 LTE-FDD: B1/2 /3/4/5/7/8/28 LTE-TDD: B40 WCDMA: B1/2/4/5/8 GSM/EDGE: B2/3/5/8 Tx Power Frequency Bands Max. Tx Power GSM850/EGSM900 33 dBm ±2 dB DCS1800/PCS1900 30 dBm ±2 dB WCDMA bands 23 dBm ±2 dB LTE bands 23 dBm ±2 dB Wi-Fi Frequency 2.4 GHz Wi-Fi Protocol 802.11 b/g/n AI DSM Support drowsy driving, distracted driving, calling, no driver, wearing IR blocking sunglasses, smoking, lens tampering, and unbelted alarms. ADAS Support Lane Departure Warning, Forward Collision Warning and Headway Monitoring Warning. ANPR Support recognition of license plate, vehicle color and vehicle brand. Face Recognition Supports face attribute detection and face comparison. Recording Playback Recording Priority Manual recording > alarm recording > motion detection recording > Timed recording Recording Playback 1/4 channels Backup HDD/SSD, USB flash drive and network backup Storage HDD/SSD 2 × 2.5-inch HDD/SSDs (SATA), up to 2 TB for each Heat Dissipation Built-in fan cooling SD card 1 (up to 256 GB) Alarm General Alarm Motion detection, video loss, video tampering, local alarm, camera offline Abnormal Alarm No HDD, HDD error, insufficient capacity, illegal login, battery low voltage, high temperature, rollover, collision, over speed, low speed, rapid turn, rapid speedup, sharp brake, network security exception, ACC off Alarm Linkage Log, record, snapshot, tour, buzzer, email, alarm output Sensor Gyroscope Supports event detection and alarm such as rollover, collision, rapid speedup/slowdown/turn. External Interface Alarm Input 9 channels (Alarm 1-8 are local alarm input, Alarm 9 is pulse input) Alarm Output 2 channels (1 relay out, 1 controllable 12 V 0.75A out) Audio Talk Support RS–232 3 RS–485 1 CAN 1 USB Port Front panel: 2 × USB 3.0 Rear panel: 1 × USB 2.0 from EXTEND port Network Port 1 × 10M/100M RJ45 Satellite Positioning GPS/GLONASS General Power Supply 6–36 VDC Power Consumption ?12W (without any peripheral) Operating Temperature -30°C to +70°C Operating Humidity 10%–90% Dimension 180 mm × 190 mm × 50 mm (7.0" × 8.7" × 2.0") Weight Net Weight: 2.1kg Gross Weight: 3.2kg Installation Embedded or bracket installation
