System Main Processor Industrial-grade processor Operating System Embedded Linux Operating Interface Web, Local GUI AI AI by Recorder Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus AI by Camera Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; stereo analysis, crowd distribution; people counting; ANPR; heat map; PPE detection AcuPick AI by Camera + Recorder Max. 64-channel, 1 combined event per channel Perimeter Protection Perimeter Performance AI by Recorder (Number of Channels) Simultaneous mode: 32 channels, 10 IVS rules for each channel Heterogeneous mode: 24 channels, 10 IVS rules for each channel Refer to the information on video output for details on the mode Perimeter Performance of AI by Camera (Number of Channels) All channels (64 targets/s) Face Detection Face Attributes 6 attributes Face Detection Performance of AI by Recorder (Number of Channels) Simultaneous mode: 8 channels (up to 12 face images/s each channel) Heterogeneous mode: 5 channels (up to 12 face images/s each channel) Refer to the information on video output for details on the mode Face Detection Performance of AI by Camera (Number of Channels) 64 channels Face Recognition Face Database Capacity Up to 40 face databases with 300,000 images, with a total capacity of 48 G. Face Recognition Performance of AI by Recorder (Number of Channels) Simultaneous mode: 32-channel FD (by camera) + FR (by recorder),image stream: 32 face images/s; 8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder),image stream: 16 face images/s; 5-channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s Refer to the information on video output for details on the mode Face Recognition Performance of AI by Camera (Number of Channels) 64 channels SMD Plus SMD Plus by Recorder 32 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change SMD Plus by Camera All channels (128 targets/s) Video Metadata Metadata Performance of AI by Recorder (Number of Channels) 8 channels, 23 attributes extraction. Metadata Performance of AI by Camera (Number of Channels) 64 channels People Attributes 9 human body attributes Motor Vehicle Attributes 9 attributes Non-motor Vehicle Attributes 4 attributes Vehicle License Plate Comparison ANPR by Camera (Number of Channels) All channels (64 targets/s) License Plate Database Capacity 1. Up to 20,000 plate numbers. 2. Blocklist and allowlist Audio and Video Access Channel 128 channels Network Bandwidth AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing Resolution 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF Decoding Capability AI disabled: 2-channel 32 MP@30 fps; 2-channel 24 MP@30 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 11-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps?128-channel D1@30 fps AI enabled: 1-channel 32 MP@30 fps; 1-channel 24 MP@30 fps; 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 5-channel 6 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps? 80-channel D1@30 fps Video Output 2 VGA, 4 HDMI; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode (simultaneously outputs video sources for all the HDMI1-4 and VGA1-2 ports) Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1 and HDMI2 is 4K; max. resolution of HDMI3 is 8K; max. resolution of HDMI4 is 1080p Heterogeneous mode (simultaneously outputs video sources for the VGA1 and HDMI1, or VGA2 and HDMI2. It also outputs heterogeneous video sources for HDMI1–4) Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1, HDMI2 and HDMI3 is 4K; max. resolution of HDMI4 is 1080p Multi-screen Display Main Screen: 1/4/8/9/16/25/36/64 Sub Screen: 1/4/8/9/16/25/36 Third-party Camera Access ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha Compression Standard Video Compression Smart H.265+; H.265; Smart H.264+; H.264 Audio Compression G.711a; G.711u; PCM; G726 Network Network Protocol HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI Mobile Phone Access iOS; Android Interoperability ONVIF 22.06(Profile T; Profile S; Profile G); CGI; SDK Browser Chrome; IE; Safari; Edge; Firefox Network Mode Multi-address; load balance; fault tolerance Recording Playback Multi-channel Playback Up to 16 channels Record Mode General, motion detection; intelligent; alarm; POS Backup Method USB device and network Playback Mode Instant playback; general playback; event playback; tag playback; smart playback Storage Disk Group Yes RAID RAID 0/1/5/6/10 Hot Swapping Yes Alarm General Alarm Motion detection; local alarm; alarm box; camera external alarm; network alarm; scene changing; PIR alarm; thermal alarm Anomaly Alarm Error (no disk, disk error, low space, RAID exception, low quota space; abnormal disk health; network disconnection; IP conflict; MAC conflict; abnormal fan speed); video loss; video tampering; camera offline; audio detection Intelligent Alarm Face detection; face and body detection; face recognition; perimeter protection; SMD; video metadata; stereo analysis, crowd distribution; ; ANPR; heat map Alarm Linkage Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email Port Audio Input 1-channel RCA Audio Output 2-channel RCA Alarm Input 32 channels Alarm Output 16 channels Disk Interface 16 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature. eSATA 1 RS-232 1 RS-485 2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication) USB 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports) HDMI 4 VGA 2 Network Port 4 (10/100/2500 Mbps Ethernet port, RJ-45) General Power Supply 100–240 VAC, 50±2% Hz Redundant Power Yes Power Consumption <25 W (without HDD) Net Weight 13.03 kg (28.73 lb) Gross Weight 15.42 kg (34.01 lb) Product Dimensions 485.0 mm × 529.0 mm × 133.2 mm(19.09" × 20.83" × 5.24") (W × D × H) Packaging Dimensions 634.0 mm × 709.0 mm × 429.0 mm(24.96" × 27.91" × 16.89") (W × D × H) Operating Temperature –10 °C to +55 °C (14 °F to +131 °F) Storage Temperature –20 °C to +60 °C (–4 °F to +140 °F) Operating Humidity 10%–93% (RH), non-condensing Installation Rack or desktop Certifications Class A CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
