System Main Processor Industrial-grade processor Operating System Embedded Linux Operating Interface Web; Local GUI QuickPick 2.0 QuickPick 2.0 AI by Recorder (Number of Channels) 6 channels Perimeter Protection Perimeter Performance AI by Recorder (Number of Channels) Advanced Mode: 6 channels, 10 IVS rules for each channel General Mode: 12 channels, 10 IVS rules for each channel Face Detection Face Attributes 6 attributes Face Detection Performance of AI by Recorder (Number of Channels) 6 channels(up to 12 face images/s each channel) Privacy Protection Privacy Protection Performance of AI by Recorder (Number of Channels) 1 channel Face Recognition Face Database Capacity Up to 10 face databases with 20,000 images. Face Recognition Performance of AI by Recorder (Number of Channels) 6 channels SMD Plus SMD Plus by Recorder 16 channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change SMD Plus by Camera 32 channels AI Video Quality Analytics AI Video Quality Analytics by Recorder 16 channels: Supports detecting brightness levels, color cast, defocus, overexposure, contrast levels, black and white Scene Changing Scene Changing by Recorder 1 channel Irregular Black Block Masking Irregular Black Block Masking by Recorder 1 channel EPTZ EPTZ by Recorder 1 channel Audio and Video Analog Camera Input 16 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect Camera Input 1. CVI: 4K@25/30 fps; 4K@12.5/15 fps; 6 MP@20 fps; 5 MP@25 fps; 5 MP@20 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps. 2. TVI: 4K@15 fps; 5 MP(2560 x 1944)@20 fps; 5 MP(2960 x 1665)@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps. 3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps. IP Camera Input Up to 32 channels of IPC access 16 IP channels by default + 16 channels (analog channels are converted to IP channels) Incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After IP extension is enabled, EPTZ, Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, SMD, Perimeter Protection, QuickPick 2.0 and Privacy Protection cannot be used. Encoding Capacity Encode Enhancement disabled? Main stream: 4K@(1 fps–15 fps); 6 MP@(1 fps–20 fps); 5 MP/4K-N/4 MP/3 MP/1080p/720p/960H/D1/CIF@(1 fps–25/30 fps) Sub stream: 960H@(1 fps–15 fps);D1/CIF@(1 fps–25/30 fps) Encode Enhancement enabled? Main stream: the 1st, 5th, 9th, 13th channel 4K@(1 fps–30 fps), others 4K@(1 fps–15 fps); 6 MP@(1 fps–20 fps); 5 MP/ 4K-N/4 MP/3 MP/1080p/720p/ 960H/D1/CIF@(1 fps–25/30 fps) Sub stream: 960H@(1 fps–15 fps); D1/CIF@(1 fps–25/30 fps) *When Encode Enhancement is enabled, EPTZ, Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, Perimeter Protection, QuickPick 2.0 and Privacy Protection cannot be used. Dual-stream Yes Video Bit Rate 32 kbps–8192 kbps Audio Sampling 8 kHz, 16 bit Audio Bit Rate 64 kbps Video Output 1 HDMI, 1 VGA, 1 CVBS HDMI : 3840 × 2160,1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable. Multi-screen Display When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled: 1/4/8/9/16/25/36 Third-party Camera Access Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF Compression Standard Video Compression AI Coding; Smart H.265+; H.265; Smart H.264+; H.264 Audio Compression G.711a; G.711u; PCM Network Network Protocol HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.) Mobile Phone Access iOS; Android Interoperability ONVIF 24.06 (Profile T; Profile S; Profile G); CGI; SDK Browser Chrome; IE; Safari; Edge; Firefox Recording Playback Record Mode General; alarm; motion detection; intelligent; POS Recording Playback 1/4/9/16 Backup Method USB device and network Playback Mode Instant playback; general playback; event playback; tag playback; smart playback Storage Disk Group Yes Alarm General Alarm Motion detection; alarm box; HDCVI alarm; camera external alarm; network alarm; PIR alarm Anomaly Alarm Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline Intelligent Alarm Face detection; face recognition; perimeter protection; SMD Plus Alarm Linkage Record; snapshot (panoramic); IPC external alarm output; audio; buzzer; log; preset; email Ports CVBS Output 1 channel Audio Input 1-channel RCA 16-channel BNC (Coaxial Audio) Audio Output 1-channel RCA Two-way Talk Yes (share the same audio input with the first channel) Disk Interface 2 SATA ports. Each disk can contain up to 16 TB. This limit varies depending on the environment temperature. RS-485 1 USB 2 (1 front USB 2.0 port, 1 rear USB 3.0 port) HDMI 1 VGA 1 Network Port 1 (10/100/1000 Mbps Ethernet port, RJ-45) General Power Supply 12 VDC, 5 A Power Consumption <32 W (without HDD) Net Weight 2.40 kg (5.30 lb) Gross Weight 4.00 kg (8.82 lb) Product Dimensions 375.0 mm × 332.0 mm × 53.0 mm (14.76'' × 13.08'' × 2.09'') (W × D × H) Packaging Dimensions 449.0 mm × 170.0 mm × 421.0 mm (17.68" × 6.70" × 16.58") (W × D × H) Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F) Storage Temperature –20 °C to +60 °C (–4 °F to +140 °F) Operating Humidity 10%–90% (RH), non-condensing Installation Desktop Certifications CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 FCC: Part 15 Subpart B
