StarTech.com SFPGLCSXMMST

Cisco GLC-SX-MM compatible 1000BASE-SX multimode SFP

A Cisco GLC-SX-MM compatible SFP optical module for 1GbE multimode fibre links up to 550m, using duplex LC at 850nm.

1GbE / 1.25GbpsMultimode fibreLC / 850nm / 550mLifetime warranty

StarTech SFPGLCSXMMST Cisco compatible 1000BASE-SX multimode SFP

Key capabilities

Cisco GLC-SX-MM compatible

Designed, programmed and tested for compatible Cisco equipment.

550m multimode reach

Supports 1000BASE-SX links up to 550m / 1804ft.

850nm duplex LC

Uses multimode fibre through an LC duplex interface.

Hot-swappable SFP

The exact product description identifies the module as hot-swappable.

What to know before buying

This model does not support DDM. Confirm the host accepts Cisco GLC-SX-MM compatible SFP modules and the multimode fibre installation is suitable for 1000BASE-SX.

Australian version and manufacturer warranty

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com Lifetime manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

What is the StarTech SFPGLCSXMMST compatible with?

Cisco GLC-SX-MM compatible networking equipment.

What network speed does it support?

1GbE, with a listed maximum data rate of 1.25Gbps.

What fibre type does it use?

Multimode fibre.

What connector and wavelength are used?

Duplex LC at 850nm.

What is the maximum distance?

Up to 550m / 1804ft.

Does it support DDM?

No.

What power consumption is listed?

Less than 1W.

What warranty applies in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(SFPGLCSXMMST)

Features and highlights

Cisco GLC-SX-MM compatible

Designed, programmed and tested for compatible Cisco equipment.

550m multimode reach

Supports 1000BASE-SX links up to 550m / 1804ft.

850nm duplex LC

Uses multimode fibre through an LC duplex interface.

Hot-swappable SFP

The exact product description identifies the module as hot-swappable.

1GbE / 1.25Gbps
Multimode fibre
LC / 850nm / 550m
Lifetime warranty

Warranty confidence: Official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com terms and assessment.

Specifications

Verified specifications for StarTech SFPGLCSXMMST.

Warranty Information

Warranty	Lifetime

Hardware

Compatible Brand	Cisco
Industry Standards	IEEE 802.3z 1000BASE-SX
WDM	No

Performance

Compatible Networks	1000 Mbps (1 Gbps)
DDM	No
Fiber Operating Mode	Half/Full-Duplex
Max Transfer Distance	550 m (1804 ft)
Maximum Data Transfer Rate	1.25 Gbps
MTBF	3,381,761 hours
Type	Multi Mode
Wavelength	850nm

Connector(s)

Local Unit Connectors	1 - Fiber Optic LC Duplex Female

Special Notes / Requirements

Note	For use in Gigabit fiber networking equipment and media converters
System and Cable Requirements	MSA or Cisco compliant SFP port

Power

Power Consumption (In Watts)	< 1 W

Environmental

Humidity	30~70% RH
Operating Temperature	0°C to 70°C (32°F to 158°F)
Storage Temperature	-40°C to 85°C (-40°F to 85°F)

Physical Characteristics

Product Height	0.4 in [1 cm]
Product Length	2.4 in [60 mm]
Product Width	0.5 in [12 mm]
Weight of Product	0.6 oz [16 g]

Packaging Information

Package Height	1.3 in [32 mm]
Package Length	4.6 in [11.8 cm]
Package Width	3.7 in [95 mm]
Shipping (Package) Weight	3.4 oz [95 g]

What's in the Box

Included in Package	1 - 1.25 Gbps Multimode LC SFP

SKU	SFPGLCSXMMST
Barcode #	65030849692
Brand	STARTECH
Shipping Weight	0.0500kg
Shipping Width	0.100m
Shipping Height	0.050m
Shipping Length	0.120m
Shipping Cubic	0.000600000m3
