StarTech.com SFP10GLRST

Cisco SFP-10G-LR compatible 10GBASE-LR SFP+ transceiver

A Cisco SFP-10G-LR compatible 10GbE SFP+ optical module for single-mode fibre links up to 10km, using duplex LC at 1310nm with DDM.

10GbESingle-mode fibreLC / 1310nm / 10kmLifetime warranty

Key capabilities

Cisco SFP-10G-LR compatible

Designed, programmed and tested for compatible Cisco switches and routers.

10km single-mode reach

Supports 10GBASE-LR links up to 10km / 6.2mi.

1310nm duplex LC

Uses a duplex LC optical interface at 1310nm.

DDM and low power

DDM is supported and the technical table lists power below 1.3W.

What to know before buying

Confirm the target device accepts Cisco SFP-10G-LR compatible modules. This SKU is distinct from the SFP-10G-LR-S compatible SFP10GLRSST model.

Australian version and manufacturer warranty

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com Lifetime manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

What is SFP10GLRST compatible with?

Cisco SFP-10G-LR compatible networking equipment.

What speed does it support?

10Gbps.

What fibre type does it use?

Single-mode fibre.

What connector and wavelength are used?

Duplex LC at 1310nm.

What is the maximum distance?

Up to 10km / 6.2mi.

Does it support DDM?

Yes.

How does it differ from SFP10GLRSST?

SFP10GLRST is the Cisco SFP-10G-LR compatible model; SFP10GLRSST is the SFP-10G-LR-S compatible model.

What warranty applies in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(SFP10GLRST)

Features and highlights

Cisco SFP-10G-LR compatible

Designed, programmed and tested for compatible Cisco switches and routers.

10km single-mode reach

Supports 10GBASE-LR links up to 10km / 6.2mi.

1310nm duplex LC

Uses a duplex LC optical interface at 1310nm.

DDM and low power

DDM is supported and the technical table lists power below 1.3W.

10GbE
Single-mode fibre
LC / 1310nm / 10km
Lifetime warranty

Warranty confidence: Official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com terms and assessment.

Specifications

Verified specifications for StarTech SFP10GLRST.

Warranty Information

Warranty	Lifetime

Hardware

Compatible Brand	Cisco
Industry Standards	IEEE 802.3ae 10GBASE-LR

Performance

Compatible Networks	10 Gbps
DDM	Yes
Fiber Operating Mode	Full-Duplex
Max Transfer Distance	10 km (6.2 mi)
Maximum Data Transfer Rate	10 Gbps
MTBF	2,104,865 hours
Type	Single Mode
Wavelength	1310nm

Connector(s)

Local Unit Connectors	1 - Fiber Optic LC Duplex Female

Special Notes / Requirements

Note	For use in 10 Gigabit fiber networking equipment and media converters
System and Cable Requirements	MSA or Cisco compliant SFP port

Power

Power Consumption (In Watts)	< 1.3 W

Environmental

Humidity	5~95% RH
Operating Temperature	0°C to 70°C (32°F to 158°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)

Physical Characteristics

Color	Silver
Enclosure Type	Zinc-Plated Casing
Product Height	0.5 in [1.3 cm]
Product Length	2.2 in [56.6 mm]
Product Width	0.5 in [13.7 mm]
Weight of Product	0.8 oz [22 g]

Packaging Information

Package Height	1.3 in [33 mm]
Package Length	4.6 in [11.8 cm]
Package Width	3.6 in [92 mm]
Shipping (Package) Weight	3.4 oz [95 g]

What's in the Box

Included in Package	1 - SFP+ transceiver

SKU	SFP10GLRST
Barcode #	65030864275
Brand	Startech
Shipping Weight	0.0500kg
Shipping Width	0.100m
Shipping Height	0.040m
Shipping Length	0.120m
Shipping Cubic	0.000480000m3

Lifetime official manufacturer warranty

StarTech.com warranty in Australia

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com Lifetime manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase.

Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment. This wording does not promise automatic replacement or guaranteed claim approval.
