StarTech Cisco Meraki MA-SFP-1GB-LX10 Compatible SFP Transceiver Module - 1000BASE-LX MASFP1GBLX10
Model # MASFP1GBLX10
-
SKU: MASFP1GBLX10
- Pick Up Available
- Australian Warranty
- Checkout Securely
The MASFP1GBLX10 is a Cisco Meraki MA-SFP-1GB-LX10 compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Merakiª brand switches and routers. It delivers dependable 1GbE (100Mbps) connectivity over fiber cable, for 1000Base-LX compliant networks, with a maximum distance of up to 10 km (6.2 mi).
Technical Specifications:
- Wavelength: 1310nm
- Maximum Data Transfer Rate: 1.25 Gbps
- Type: Single Mode Fiber
- Connection Type: LC Connector
- Maximum Transfer Distance: 10 km (6.2 mi)
- MTBF: 3,092,408 hours
- Power Consumption: Less than 1 Watt
- Digital Diagnostics Monitoring (DDM): Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
Applications
- Replacing defective or damaged SFP modules_in Cisco Meraki switches and routers
- Expand your network to remote segments
(MASFP1GBLX10)
| Warranty Information | ||
|---|---|---|
| Warranty | Lifetime | |
| Hardware | ||
| Compatible Brand | Cisco Meraki | |
| Industry Standards | IEEE 802.3z 1000BASE-LX | |
| Performance | ||
| Compatible Networks | 1000 Mbps (1 Gbps) | |
| DDM | Yes | |
| Fiber Operating Mode | Full-Duplex | |
| Max Transfer Distance | 10 km (6.2 mi) | |
| Maximum Data Transfer Rate | 1.25 Gbps | |
| MTBF | 3,092,408 hours | |
| Type | Single Mode | |
| Wavelength | 1310nm | |
| Connector(s) | ||
| Local Unit Connectors | 1 - Fiber Optic LC Duplex Female | |
| Special Notes / Requirements | ||
| System and Cable Requirements | MSA or Cisco Meraki compliant SFP port | |
| For use in Gigabit fiber networking equipment and media converters | ||
| Power | ||
| Power Consumption (In Watts) | < 1 W | |
| Environmental | ||
| Humidity | 5~95% RH | |
| Operating Temperature | 0¡C to 70¡C (32¡F to 158¡F) | |
| Storage Temperature | -40¡C to 85¡C (-40¡F to 185¡F) | |
| Physical Characteristics | ||
| Color | Silver | |
| Enclosure Type | Aluminum | |
| Product Height | 0.5 in [1.3 cm] | |
| Product Length | 2.2 in [56.6 mm] | |
| Product Width | 5.1 in [13 cm] | |
| Weight of Product | 0.7 oz [20 g] | |
| Packaging Information | ||
| Package Height | 1.3 in [33 mm] | |
| Package Length | 3.7 in [93 mm] | |
| Package Width | 4.6 in [11.8 cm] | |
| Shipping (Package) Weight | 1.6 oz [46 g] | |
| What's in the Box | ||
| Included in Package | 1 - SFP transceiver | |
| SKU | MASFP1GBLX10 |
| Barcode # | 65030869454 |
| Brand | STARTECH |
| Shipping Weight | 0.0400kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.110m |
| Shipping Cubic | 0.000550000m3 |
