Now, you can easily connect to a Gigabit network through the USB-Cª or Thunderboltª 3 port on your laptop or desktop computer, and add connectivity for an additional USB (Type-A) peripheral device.  It's a great companion for your MacBook, Chromebook Pixelª, Dellª XPS 12, Dell Latitude 12 7000 Series 2-in-1 or other devices.

Powerful Gigabit network connections

The USB-C network adapter supports full Gigabit bandwidth by harnessing the performance of USB 3.1 Gen 1 (5 Gbps). You can quickly access very large files over the network at Gigabit speed.

Native driver support makes installation easy

Get up and running quickly. Simply plug the adapter into the USB Type-Cª port on your laptop and connect to your network. The network adapter chipset provides native driver support in Chrome OSª and Windows¨ 8.1, and supports Mac OSX (10.10) with driver installation.

Trouble-free connections through USB-Type-C

The USB-C connector is smaller and easier to use than previous USB connectors. ItÕs a reversible plug so you can connect to your devices with either side facing up, without frustration or the risk of port damage.

With a compact design, this USB-C network adapter is as portable as your laptop, perfect for ultra-portable devices that have a USB-C port, such as the MacBook and Chromebook Pixelª. The network adapter is bus-powered which makes it easy to connect when youÕre on the go.

Additional connectivity with an extra USB 3.1 port

Some computers with USB Type-C only offer one port for external connectivity. This Ethernet adapter features a built-in USB Type-A port, giving you the freedom to attach an additional peripheral device, such as a USB mouse.

The US1GC301AU is backed by a StarTech.com 2-year warranty and free lifetime technical support.


Applications

  • Add Gigabit Ethernet capabilities to your MacBook, Chromebook Pixel, Dell XPS 12 or Dell Latitude 12 7000 Series 2-in-1
  • Turn your USB-C port into a Gigabit LAN RJ45 port
  • Add an extra USB peripheral along with your network adapter

(US1GC301AU)

Warranty Information
Warranty 2 Years
Hardware
Bus Type USB 3.1 Gen 1
Chipset ID ASIX - AX88179
VIA/VLI - VL812
Industry Standards IEEE 802.3, 802.3u and 802.3ab
Interface RJ45 (Gigabit Ethernet)
Ports 1
USB Pass-Through Yes
Performance
Auto MDIX Yes
Compatible Networks 10/100/1000 Mbps
Full Duplex Support Yes
Jumbo Frame Support 4K max.
Maximum Data Transfer Rate 5 Gbps (USB 3.1 Gen 1)
Type and Rate USB 3.1 Gen 1 - 5 Gbit/s
Connector(s)
Connector Type(s) 1 - USB Type-C (24 pin) USB 3.0 (5Gbps) Male
External Ports 1 - USB 3.1 USB Type-A (9 pin, Gen 2, 10 Gbps) Female
1 - RJ-45 Latching Female
Software
OS Compatibility Windows¨ XP, Vista, 7, 8, 8.1, 10
Windows Server¨ 2003, 2008 R2, 2012
Mac OS¨ 10.6 to 10.14 VLAN tagging is currently not supported in Mac OS
Linux Kernel 2.6.25 to 4.11.x LTS Versions only
Indicators
LED Indicators 1 - 1 - 10/100 Link/Activity (Green)
1 - Gigabit Link/Activity (Amber)
Power
Power Source USB-Powered
Environmental
Humidity 5% ~ 80% RH
Operating Temperature 0¡C to 50¡C (32¡F to 122¡F)
Storage Temperature -10¡C to 60¡C (14¡F to 140¡F)
Physical Characteristics
Cable Length 8 in [20.3 cm]
Color Black
Enclosure Type Plastic
Form Factor Attached Cable
Product Height 0.7 in [1.7 cm]
Product Length 10.8 in [27.5 cm]
Product Width 1.4 in [3.5 cm]
Weight of Product 1.3 oz [38 g]
Packaging Information
Package Height 1.2 in [30 mm]
Package Length 6.7 in [17 cm]
Package Width 5.6 in [14.3 cm]
Shipping (Package) Weight 3.2 oz [92 g]
What's in the Box
Included in Package 1 - USB-C to GbE network adapter
SKU US1GC301AU
Barcode # 65030862806
Brand Startech
Shipping Weight 0.5000kg
Shipping Width 0.160m
Shipping Height 0.030m
Shipping Length 0.170m
