Camera Image Sensor 1/2.8” STARVIS™ CMOS Effective Pixels 1920(H) x 1080(V), 2 Megapixels Scanning System Progressive Electronic Shutter Speed 1/1s~1/30,000s Minimum Illumination Color: 0.005Lux@F1.6; B/W: 0.0005Lux@F1.6; 0Lux@F1.6 (IR on) S/N Ratio More than 56dB IR Distance Distance up to 350m (1148ft) IR On/Off Control Auto/Manual IR LEDs 8 Smart Wiper Support Lens Focal Length 3.95mm~177.7mm Max. Aperture F1.6~ F4.95 Angle of View H: 70.3° ~ 1.8° Optical Zoom 45x Focus Control Auto/Manual Close Focus Distance 100mm~ 1000mm DORI Distance Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. Detect Observe Recognize Identify 2345m(7694ft) 938m(3077ft) 469m(1539ft) 234m(768ft) PTZ Pan/Tilt Range Pan: 0° ~ 360° endless; Tilt: 0° ~ 360° endless, effective tilt angle: -55° ~ 223° Manual Control Speed Pan: 0.1° ~120° /s; Tilt: 0.1° ~60° /s Preset Speed Pan: 120° /s; Tilt: 60° /s Presets 300 PTZ Mode 5 Pattern, 8 Tour, Auto Pan ,Auto Scan Speed Setup Human-oriented focal Length/ speed adaptation Power up Action Auto restore to previous PTZ and lens status after power failure Idle Motion Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period Protocol DH-SD, Pelco-P/D (Auto recognition) Intelligence Event Trigger Motion detection, Video tampering , Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly Auto Tracking Support IVS Tripwire, Intrusion, Abandoned/Missing Advanced Intelligent Functions Face Detection, Heat Map Video Compression H.265+/H.265/H.264+/H.264 Streaming Capability 3 Streams Resolution 1080P(1920×1080)/1.3M(1280×960)/720P(1280× 720)/D1(704×576/704×480)/CIF(352×288/352×240) Frame Rate Main stream: 1080P/1.3M/720P(1~50/60fps) Sub stream1: D1/CIF(1 ~ 25/30fps) Sub stream2: 1080P/1.3M/720P/D1/CIF (1~25/30fps) Bit Rate Control CBR/VBR Bit Rate H.265/H.264: 448K ~ 8192Kbps Day/Night Auto(ICR) / Color / B/W Backlight Compensation BLC / HLC / WDR(120dB) White Balance Auto, ATW, Indoor, Outdoor, Manual Gain Control Auto / Manual Noise Reduction Ultra DNR (2D/3D) Motion Detection Support Region of Interest Support Electronic Image Stabilization (EIS) Support Defog Support Digital Zoom 16x Flip 180° Privacy Masking Up to 24 areas Audio Compression G.711a/G.711mu/PCM/G.726/AAC/G722.1/G.729/MPEG2-Layer2 Network Ethernet RJ-45 (10Base-T/100Base-TX) Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP,DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x Interoperability ONVIF Profile S&G, API Streaming Method Unicast / Multicast Max. User Access 20 users Edge Storage NAS (Network Attached Storage),Local PC for instant recording, Micro SD card 256GB Web Viewer IE, Chrome, Firefox, Safari Management Software Smart PSS, DSS, DMSS Smart Phone IOS, Android Certifications Certifications CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 UL: UL60950-22,CSA C22.2 NO. 60950-22-07 Interface Video Interface 1 port(BNC, 1.0V[p-p], 75?) RS485 1 Audio I/O 1/1 Alarm I/O 7/2 Electrical Power Supply AC24V/5A(±25%), Hi-PoE Power Consumption For DH-PTZ19245U-IRB-N: AC 24V: 25W, 40W (IR on), 80W (IR on, Heater on) Hi-PoE: 25W, 40W (IR on) For DH-PTZ19245U-IRB-N-B: AC 24V/Hi-PoE: 25W, 40W (IR on) Environmental Operating Conditions For DH-PTZ19245U-IRB-N: AC 24V: -50°C ~ 70°C (-58°F ~ +158°F) Hi-PoE : -40°C ~ 70°C (-40°F ~ +158°F) For DH-PTZ19245U-IRB-N-B: -40°C ~ 70°C (-40°F ~ +158°F) Less than 95% RH Ingress Protection IP68 Vandal Resistance N/A Construction Casing Metal Dimensions ?234(mm) x 205(mm) x 405.5(mm) Net Weight 9.8kg(21.61lb) Gross Weight 15.5kg(34.17lb)
