Camera Image Sensor 1/2.8”4Megapixel progressive CMOS Max. Resolution 2560 (H) × 1440 (V) ROM 4GB RAM 1GB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 2.0 mm: 0.007 lux@F2.0 (Color, 30 IRE) 0.0007 lux@F2.0 (B/W, 30 IRE) 0 lux (Illuminator on) 2.8 mm: 0.005 lux@F1.6 (Color, 30 IRE) 0.0005 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) S/N Ratio >56 dB Illumination Distance 20 m (65.62 ft) (IR LED) Illuminator On/Off Control Auto Illuminator Number 1 (IR LED) Pan/Tilt/Rotation Range Tilt: –10° to 70° Lens Lens Type Fixed-focal Lens Mount M12 Focal Length 2.0 mm; 2.8 mm Max. Aperture 2.0 mm: F2.0 2.8 mm: F1.6 Field of View 2.0 mm: Horizontal: 122°; Vertical: 72°; Diagonal: 141° 2.8 mm: Horizontal: 95°; Vertical: 52°; Diagonal: 114° Iris Control Fixed Close Focus Distance 2.0 mm: 0.5 m (1.64 ft) 2.8 mm: 1.1 m (3.61 ft) DORI Distance Lens Detect Observe Recognize Identify 2.0 mm 44.8 m (146.98 ft) 17.9 m (58.73 ft) 9.0 m (29.52 ft) 4.5 m (14.76 ft) 2.8 mm 63.6 m (126.64 ft) 25.4 m (50.52 ft) 12.7 m (25.26 ft) 6.4 m (12.80 ft) Smart Event IVS Abandoned object; missing object Professional, intelligent IVS (Perimeter Protection) Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection Face Detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting People Counting Tripwire people counting, drawing polygonal lines for tripwire, generating and exporting report (day/week/month/year); People counting in area, generating and exporting report (day/week/month); Queue management, generating and exporting report (day/week/month); 4 rules can be set for tripwire, people counting in area and queue management; Supports crowd detection; Supports intelligence trajectory. Abnormal Behavior Analysis Leave post detection which triggers alarms when no one is in the detection area, personnel have left their post or there is an abnormal number of people on duty in the detection area. Supports setting up to 20 personnel on duty at the same time. Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) Smart Codec Smart H.265+; Smart H.264+ Video Frame Rate Main stream: 2560 × 1440 @(1–25/30 fps ) Sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) Third stream: 1920 × 1080 @ (1–25/30 fps) Stream Capability 3 streams Resolution 4 M (2560 × 1440); 3 M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3 M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps Day/Night Auto (ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Smart Illumination Yes Defog Yes Privacy Masking 4 areas Audio Built-in MIC Yes Built-in Speaker Yes Audio Compression PCM; G.711a; G.711Mu; G.726; G.723 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; face detection; In Area No.; stay alarm; people counting; abnormal number of people detection; security exception Network Network Port RJ-45 (10/100/1000 Base-T) SDK and API Yes Cyber Security Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P Interoperability ONVIF (Profile S/Profile G/Profile T); CGI User/Host 20 (Total bandwidth: 64 M) Storage FTP; SFTP; Micro SD card (support max. 512 GB); NAS Browser IE: IE 9 and later Chrome Firefox Safari: Safari 12 and later Management Software Smart PSS; DSS; DMSS Mobile Client iOS; Android Certification Certifications CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC:47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 Port RS-485 1 (baud rate range: 1200 bps–115200 bps) Audio Input 2 channels (RCA port) Audio Output 1 channel (RCA port) Alarm Input 2 channels in: 5 mA 3 V–5 VDC Alarm Output 2 channels out: 300 mA 12 VDC Analog Output 1 channel (CVBS output: BNC) Power Power Supply 12 VDC/PoE (802.3af) Power Consumption Basic: 4 W (12 VDC); 6.4 W (PoE) Max. (H.265+main stream/IR intensity+IR on): 11.3 W (12 VDC); 12.9 W (PoE) Environment Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F) Operating Humidity ?95% Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F) Protection IP67; IK10 Structure Casing Metal Product Dimensions 204.0 mm × 78.0 mm × 61.6 mm (8.03" × 3.07" × 2.43") (L × W × H) Net Weight 0.82 kg (1.81 lb) Gross Weight 1.18 kg (2.60 lb)
