Camera Image Sensor 1/3" CMOS Max. Resolution 2880 (H) × 1620 (V) Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Illumination Distance Up to 30 m (98.43 ft) (IR); Up to 30 m (98.43 ft) (Warm Light) Illuminator On/Off Control Auto Illuminator Number 2 (IR LED); 2 (Warm light) Angle Adjustment Pan: 0°–355°; Tilt: 0°–90° Lens Max. Aperture F1.6 Field of View H: 78°; V: 40°; D: 93° Intelligence Vehicle Detection Yes Human Detection Yes Video Video Compression H.265 Video Frame Rate Main stream: 2880 × 1620@(1-25/30 fps) sub stream: 640 × 360@(1-25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Resolution 5M (2880 × 1620); nHD (640 × 360) Video Bit Rate H.265: 80 kbps–4096 kbps Day/Night Auto(ICR)/Color/B/W WDR DWDR Motion Detection Yes Smart Illumination Yes Image Rotation 0°/180° Audio Built-in MIC Yes, built-in Mic Built-in Speaker Yes, built-in speaker Audio Compression G.711a Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE 802.11b/g/n/ax 2.412-2.472 GHz, 2.4 G Storage Micro SD card (up to 256 GB) Management Software DMSS Mobile Client iOS;Android Certification Certifications CE Power Power Supply 12 VDC, 1 A Power Consumption Basic: 1.68 W Max.: 4.56 W (H.265+warm light on) Environment Operating Temperature –20 °C to +50 °C (–4 °F to +122 °F) Operating Humidity ?95% Structure Casing Material Plastic Product Dimensions 116 mm × 138 mm × 139 mm (4.57" × 5.43" × 5.47") (L × W × H) Net Weight 425 g (0.94 lb)
