Camera Image Sensor 1/2.8" CMOS Pixel 4MP Max. Resolution 2560 (H) × 1440 (V) ROM 128 MB RAM 512 MB Electronic Shutter Speed 1/1 s–1/30000 s Scanning System Progressive Min. Illumination Color: 0.005 Lux@F1.8 B/W: 0.0005 Lux@F1.8 0 Lux (IR on) Illumination Distance 40 m (131.23 ft) Illuminator On/Off Control Zoom Prio/Manual/SmartIR/Off Illuminator Number 3 IR lights Lens Focal Length 2.8 mm–12 mm Max. Aperture F1.8–F2.7 Field of View H: 42.8°–91.9° V: 23.8°–49.4° D: 49.1°–109.4° Optical Zoom 4x Focus Control Auto/Semi-Auto/Manual Close Focus Distance 0.2 m–0.5 m (0.66 ft–1.64 ft) Iris Control Fixed DORI Distance Detect Observe Recognize Identify 240 m (787.40 ft) 95 m (311.68 ft) 48 m (157.48 ft) 24 m (78.74 ft) PTZ Preset 300 Power-off Memory Support Idle Motion Preset Artificial Intelligence Smart Capture Support human, motor vehicle and non-motor vehicle image capture. Perimeter Protection Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. Face Detection Support Video Compression H.265; H.264B; H.264M; H.264H; MJPEG; H.265+; H.264+ Streaming Capability 3 streams Resolution 4M (2560 × 1440); 3M (2048 × 1536); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576 ); CIF (352 × 288) Frame Rate Main stream: 4M/3M/1080P/960P/720P (1–25/30 fps) Sub stream 1: D1/CIF (1–25/30 fps) Sub stream 2: 1080P/960P/720P (1–25/30 fps) Bit Rate Control Variable/Constant Bit Rate H.264: 2816 Kbps–8192 Kbps Day/Night Auto (ICR)/Color/B/W BLC Support WDR 120 dB HLC Support White Balance Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp Gain Control Auto/Manual Noise Reduction 2D/3D Motion Detection Support Region of Interest (RoI) Support Image Stabilization Electronic Defog Electronic Digital Zoom 16x Flip 180° Privacy Masking Up to 24 areas, and up to 8 areas in the same view S/N Ratio 55 dB Audio Compression G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723 Network Ethernet 1 (crystal head, 10/100Base-T) Protocol IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; SNMP v1/v2c/v3 (MIB-2); RTCP; RTMP Interoperability ONVIF (Profile S&G&T); CGI Streaming Method Unicast/Multicast User/Host 20 Storage FTP; Micro SD card (256G); NAS Browser IE7 and later versions Chrome 42 and earlier versions Firefox 52 and earlier versions Safari Management Software Smart PSS; DSS; DMSS; IVSS Mobile Phone IOS; Android Certification Certifications CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 ATEX: II 2 G Ex db IIC T6 Gb, II 2 D Ex tb IIIC T80°C Db IECEx: Ex db IIC T6 Gb, Ex tb IIIC T80°C Db Port Audio Input 1 Audio Output 1 Two-way Audio Support Alarm Linkage Capture; preset; record; alarm digital output; audio; send email Alarm Event Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; abnormal power supply detection Power Power Supply DC12V/1.5A±10% PoE (802.3af) Power Consumption Basic: 4W Max.: 9W (IR light on) Environment Operating Temperature –40°C to +60°C (–40°F to +140°F) Operating Humidity ? 95% Protection IP68; TVS 6000V lightning proof; surge protection; voltage transient protection Structure Casing SUS304/SUS316L (customizable) Dimensions 215 mm x 149 mm x 151 mm (8.46" × 5.87" × 5.94") (L × W × H) Net Weight 3 kg (6.61 lb) Gross Weight 6.3 kg (13.89 lb)
