Camera Image Sensor Panoramic network camera: 1/1.8”CMOS PTZ camera: 1/1.8”CMOS Max. resolution Panoramic network camera: 8192×1800 PTZ camera: 1920× 1080 Scanning System Progressive Electronic Shutter Speed Panoramic network camera: 1/3 s-1/100000 s, manual or auto adjust PTZ Camera: 1/1 s-1/300000 s, manual or auto adjust Min. Illumination Panoramic network camera: 0.001Lux(colour);0.0001Lux(black); PTZ camera: 0.001Lux(colour);0.0001Lux(black);0Lux(IR on) S/N Ratio Panoramic network camera:51db PTZ camera:51.5db IR Distance Panoramic network camera: — PTZ camera: ? 220 m (721.78t) (IR on) IR On/Off Control Auto/Manual IR LEDs Number Panoramic network camera?— PTZ camera: 7 Lens Lens Type Panoramic network camera:Fixed-focal PTZ camera:Motorized vari-focal Mount Type Panoramic network camera:M16 PTZ camera: Core interface Focal Length Panoramic network camera 2.8 mm PTZ camera: 5.62mm~208mm, 37x optical zoom Max. Aperture Panoramic network camera: F1.6 PTZ camera: F1.4 Field of View Panoramic network camera:Horizontal: 360° Vertical: 80°~85° PTZ camera:Horizontal: Horizontal: 2.61°~59.61° Vertical: 1.48°~34.92° Diagonal: 3°~66.96° Iris Type Panoramic network camera: Fixed aperture PTZ camera: Auto Close Focus Distance Panoramic network camera: 0.2m(0.66ft) PTZ camera:0.1m~1m(0.33ft~3.28ft) DORI Distance Detect Observe Reconize Identify Panoramic network camera 29.0m (95.14ft) 11.6m (38.05ft) 5.8m (19.02ft) 2.9m (9.51ft) PTZ camera 1930.7m (6334.31ft) 772.27m (2533.69ft) 386.1m (1266.73) 193.1m (633.53ft) Smart Event IVS Intrusion, tripwire Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG Smart Codec Smart H.264+ Smart H.265+ Video Frame Rate Panoramic network camera:Main stream(8192×1800@1~30fps),Sub Stream(2048×452@1~30fps),Third Stream(3840×832@`~30fps) PTZ camera: Main stream(1920×1080@1~30fps),Sub Stream(704×480@1~30fps),Third Stream(1280×720@1~30fps) Stream Capability 3 Streams Resolution Panoramic network camera: 8192×1800;7680×1680;5760×1264;4096×900;3840×832;2560×560;2048×452 PTZ camera: 1920 × 1080; 1280 × 960; 1280 × 720; 704 × 576; 704 × 480; 352 × 288; 352 × 240 Bit Rate Control Panoramic network camera: CBR/VBR PTZ camera:CBR/VBR Video Bit Rate Panoramic network camera: H.264:112kbps ~37227Kb/S H.265:44kbps ~22546Kb/S PTZ camera: H.264:24kbps ~10752Kb/S H.265:9kbps ~6400Kb/S Day/Night Auto (ICR)/Color/B/W BLC Yes HLC Yes WDR Panoramic network camera:DWDR PTZ camera: WDR (120 dB ) White Balance Panoramic network camera:Auto/Natural/street lamp/outdoor/manual/regional Custom PTZ camera: Auto/indoor/outdoor/tracking/manual/sodium lamp/natural/street lamp Gain Control Auto/Manual Noise Reduction 3D NR Motion Detection Disable/Enable Region of Interest (RoI) Yes (4 areas) Electronic Image stabilization(EIS) Panoramic network camera: — PTZ camera: Yes Smart IR Panoramic network camera: — PTZ camera: Yes (Adjusted by user.) Defog Panoramic network camera: — PTZ camera: Yes Image Rotation 0°/180°(PTZ camera) Privacy masking 4 areas(Panoramic network camera);24 areas(PTZ camera) Audio Audio Compression G.711Mu;G.711A;G.726 Network Network RJ-45 (10/100/1000 Base-T) Protocol IPv4;IPv6;HTTP;HTTPS;TCP; UDP;ARP;RTP ; RTSP;RTCP; RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS; QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;SAMBA;PPPoE;802.1x;SNMP Interoperability ONVIF (Profile S/Profile G); CGI; Milestone;Genetec User/Host 20 (Total bandwidth: 1000 M) Edge Storage FTP;SFTP; Micro SD card (support max. 256 G); Dahua Cloud; NAS Browser Chrome 42 Firefox 52 IE7;IE8;IE9;IE11 Management Software EVS5XX,EVS7XX,NVR5X-I,NVR4X-4KS2 ,M70,IVSS7X ,DSS Pro&DSS express Certification Certification CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 PTZ Dome Pan Range Pan: 0° to 360° endless Tilt: –12° to 90°, auto flip 180 Manual Control Speed Pan: 240°/s Tilt: 120°/s Remote Lens Reset Yes Preset 300 Tour 8 Tour (up to 32 preset per tour) Pattern 5 patterns Scan 5 Power-off Memory Yes Idle Motion Preset/Pattern/Tour/Scan Time Task Yes Three-dimensional Positioning Yes PTZ Limit Yes Position Display Yes Information Display Yes Time Display Yes Port Optical Fiber FC,single mode, single fiber Audio Input 2 channels (terminal) Alarm Output 2 channels (terminal) Alarm Input 7 channels in: 5mA 3V–5V DC Alarm Output 3 channels out: 1,000mA 30V DC/500mA 50V DC Power Power Supply DC36V Power Consumption MAX:74W Environment Operating Temperature -40°C to +70°C(-104°F to +158°F) Operating Humidity ?95% Storage Temperature -40°C to +70°C (-104°F to +158°F)/Less than 95% RH Ingress Protection IP66;IK10(optional) Structure Enclosure Metal + Plastic Dimensions ?383 mm × 389.8 mm (?1256.56 ft × 1279.8 ft) Net Weight 14.7 kg (32.40 lb) Gross Weight 19.8 kg (43.65 lb)
