Camera Image Sensor 1/1.8" CMOS Max. Resolution 2688 (H) × 1520 (V) ROM 128 MB RAM 1 GB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.003 Lux@F1.8 (Color, 30IRE) 0.0003 Lux@F1.8 (B/W, 30IRE) 0 Lux (Illuminator on) S/N Ratio ?56 dB Illumination Distance 40 m (131.2 ft) (IR LED) Illuminator On/Off Control Auto/Manual Illuminator Number 3 (IR LED) Pan/Tilt/Rotation Range Pan: 0°–355° Tilt: 0°–80° Rotation: 0°–355° Lens Lens Type Motorized vari-focal Mount Type ?14 Focal Length 2.7 mm–12 mm Max. Aperture F1.8 Field of View Horizontal: 107°–44° Vertical: 69°–29° Diagonal: 134°–53° Iris Type Auto Close Focus Distance W/T: 1.2 m (3.9 ft) DORI Distance Lens Detect Observe Recognize Identify W 57.0 m (131.2 ft) 23.0 m (75.5 ft) 11.0 m (36.1 ft) 5.7 m (18.7 ft) T 130.7 m (428.8 ft) 52.0 m (170.6 ft) 26.0 m (85.3 ft) 13.0 m (42.7 ft) Smart Event IVS Abandoned object; missing object Heat Map Yes Professional, intelligent IVS (Perimeter Protection) Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection Face Detection Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting People Counting Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports. Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm. Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm. Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) Smart Codec Smart H.265+/H.264+ Video Frame Rate Main stream: 2688 × 1520 (1 fps–25/30 fps) /1920 × 1080 (1 fps–50/60 fps) Sub stream: D1 (1 fps–50/60 fps) Third stream: 1080p (1 fps–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 3 streams Resolution 2688 × 1520; 2560 × 1440; 2304 × 1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–8192 kbps H.265: 32 kbps–8192 kbps Day/Night Auto (ICR)/Color/B/W BLC Yes HLC Yes WDR 140 dB Scene Self-adaptation (SSA) Yes White Balance Auto/natural/street lamp/outdoor/manual/regional custom Gain Control Auto/Manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Electronic Image Stabilization (EIS) Yes Smart Illumination Yes Defog Yes Image Rotation 0°/90°/180°/270° Mirror Yes Privacy Masking 8 areas Audio Audio Compression PCM; G.711a; G.711Mu; G.726; G.723 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; scene changing; intrusion; tripwire; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; input abnormal detection; intensity change detection; people counting; face detection; people counting in area; stay alarm; people No. exception detection; queue management Network Network RJ-45 (10/100 Base-T) SDK and API Yes Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P User/Host 20 (Total bandwidth: 80 M) Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS Browser IE: IE8 and later Chrome Firefox Management Software Smart PSS; DSS; DMSS Mobile Phone IOS; Android Certification Certification CE-LVD: EN62368-1,EN60950-22 (optional) CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60 950-1 CAN/CSA C22.2 No.60950-1-07,UL 50E NEMA Type 4X (optional) Port Audio Input 1 channel (terminal) Audio Output 1 channel (terminal) Alarm Input 3 channels in: 5mA 3V–5V DC Alarm Output 2 channels out: 300mA 12V DC Power Power Supply 12V DC (±25%)/24V AC (±30%)/PoE (802.3af)/ePoE Power Consumption Basic power consumption: 3.6W (12V DC); 3.1W (24V AC); 4.4W (PoE) Max. power consumption (H.265 + max. stream + intelligent function + IR LED + focus): 11.7W (12V DC); 11.3W (24V AC); 11.9W (PoE) Heat power consumption: 3.3W (12V DC); 4.4W (24V AC); 5.5W (PoE) Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/Less than 95% RH Strorage Conditions –40°C to +60°C (–40°F to +140°F) Protection Grade IP67, IK10, Anti-Corrosion Protection: NEMA 4X (optional) Structure Casing Metal Dimensions 129.1 mm × ?157.9mm (5.1"× ?6.2") Net Weight 1500.0 g (3.3 lb) Gross Weight 1600.0 g (3.5 lb)
