Camera Image Sensor 1/2.7”5Megapixel progressive CMOS Max. Resolution 2592 (H) × 1944 (V) ROM 128 M RAM 512 M Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.005 Lux@F1.6 (Color, 30 IRE) 0.0005 Lux@F1.6 (B/W, 30 IRE) 0 Lux (Illuminator on) S/N Ratio >56 dB Illumination Distance 50 m (164.0 ft) Illuminator On/Off Control Auto/Manual Illuminator Number 2 (IR LED); 1 (Warm light) Pan/Tilt/Rotation Range Pan: 0°–355° Tilt: 0°–80° Rotation: 0°–355° Lens Lens Type Fixed-focal Mount Type M12 Focal Length 2.8 mm; 3.6 mm; 6 mm Max. Aperture 2.8 mm: F1.6 3.6 mm: F1.6 6 mm: F1.6 Field of View 2.8 mm: Horizontal 98° × Vertical 71° × Diagonal 129° 3.6 mm: Horizontal 80° × Vertical 58° × Diagonal 107° 6 mm: Horizontal 50° × Vertical 37° × Diagonal 64° Iris Type Fixed Close Focus Distance 2.8 mm: 0.9 m (3.0 ft) 3.6 mm: 1.6 m (5.2 ft) 6 mm: 3.2 m (10.5 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8mm 56.0 m (183.7 ft) 22.4 m (73.5 ft) 11.2 m (36.7 ft) 5.6 m (18.4 ft) 3.6mm 80.0 m (262.5 ft) 32.0 m (105.0 ft) 16.0 m (52.5 ft) 8.0 m (26.2 ft) 6mm 120.0 m (393.7 ft) 48.0 m (157.5 ft) 24.0 m (78.7 ft) 12.0 m (39.4 ft) Smart event IVS Abandoned object; missing object Heat Map Yes Professional, intelligent IVS (Perimeter Protection) Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection Face Detection Face detection; track; optimization; snapshot; face enhancement; face exposure; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting People Counting Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/ monthly/daily reports Support the counting of number in area, and 4 rules configuration Count number of people or stay time and link alarm Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) Smart Codec Smart H.265+/Smart H.264+ Video Frame Rate Main stream: 2592 × 1944@(1-20 fps)/2688 × 1520@(1-25/30 fps) /1920 × 1080@(1-50/60 fps) Sub stream: (704 × 576@1-50 fps/704 × 480@1-60 fps) Third stream: (1920 × 1080@1-25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 3 streams Resolution 5M (2592 × 1944); 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps Day/Night Auto (ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto/natural/street lamp/outdoor/manual/regional custom Gain Control Auto/Manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas) Region of Interest (RoI) Yes (4 areas) Smart Illumination Yes Defog Yes Image Rotation 0°/90°/180°/270° (Support 90°/270° with 4M resolution and lower) Mirror Yes Privacy Masking 8 areas Audio Built-in MIC Yes Audio Compression PCM; G.711a; G.711Mu; G.726; G.723 Alarm Alarm Event No SD card; SD card full; SD card error; service life warning; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; defocus detection; external alarm; face detection; people counting in area; stay alarm; people counting; people No. exception detection; safety exception; light alarm; sound alarm (21 built-in sounds and custom voices importing) Network Network RJ-45 (10/100 Base-T) SDK and API Yes Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade Protocol IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec User/Host 20 (Total bandwidth: 80 M) Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS Browser IE: IE8, IE9, IE11 Chrome Firefox Management Software Smart PSS; DSS; DMSS Mobile Phone IOS; Android Certification Certification CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 Port Audio Input 1 channel (RCA port) Audio Output 1 channel (RCA port) Alarm Input 1 channel in: 5mA 3V–5V DC Alarm Output 1 channel out: 300mA 12V DC Power Power Supply 12V DC (±30%)/PoE (802.3af) Power Consumption Basic power consumption: 1.9W (12V DC); 2.5W (PoE) Max. power consumption (WDR + H.265 + IR full intensity + white light + max. speaker volume): 8.9W (12V DC); 9.6W (PoE) Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/Less than 95% RH Strorage Conditions –40°C to +60°C (–40°F to +140°F) Protection Grade IP67; IK10 Structure Casing Metal Dimensions 105 mm × ?126 mm (4.1" × ?5.0") Net Weight 716.4 g (1.6 lb) Gross Weight 929.7 g (2.0 lb)
