Camera Image Sensor 1/2.7”5Megapixel progressive CMOS Max. Resolution 2592 (H) × 1944 (V) ROM 128 MB RAM 512 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.003 Lux @ F1.0 S/N Ratio > 56 dB Illumination Distance 40 m (131.2 ft) Illuminator On/Off Control Auto/Manual Illuminator Number 2 (Warm light) Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° Lens Lens Type Fixed-focal Mount Type M12 Focal Length 2.8 mm; 3.6 mm; 6 mm Max. Aperture F1.0 Field of View 2.8 mm: Horizontal 98° × Vertical 71° × Diagonal 129° 3.6 mm: Horizontal 77° × Vertical 56° × Diagonal 101° 6 mm: Horizontal 53° × Vertical 40° × Diagonal 66° Iris Type Fixed Close Focus Distance 2.8 mm: 1.2 m (3.9 ft) 3.6 mm: 2.1 m (6.9 ft) 6 mm: 4.5 m (14.8 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 67.4 m (221.1 ft) 27 m (88.6 ft) 13.5 m (44.3 ft) 6.7 m (22.0 ft) 3.6 mm 80.0 m (262.5 ft) 32.0 m (105.0 ft) 16.0 m (52.5 ft) 8.0 m (26.2 ft) 6 mm 120.0 m (393.7 ft) 48.0 m (157.5 ft) 24.0 m (78.7 ft) 12.0 m (39.4 ft) Professional, intelligent IVS (Perimeter Protection) Tripwire; intrusion (support the classification and accurate detection of vehicle and human) Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) Smart Codec Smart H.265+/Smart H.264+ Video Frame Rate Main stream: 2592 × 1944 @1-20 fps/ 2688 × 1520 @1-25/30 fps Sub stream: 704 × 576 @1-25 fps/704 × 480 @ 1-20fps Third stream: 1920 × 1080 @1-25/30 fps Stream Capability 3 streams Resolution 5M (2592 × 1944); 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (354 × 288/354 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps Day/Night Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto/natural/street lamp/outdoor/manual/regional custom Gain Control Auto/Manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas) Region of Interest (RoI) Yes (4 areas) Smart Illumination Yes Image Rotation 0°/90°/180°/270° (Support with 2592×1944 resolution and lower) Mirror Yes Privacy Masking 4 areas Audio Built-in MIC Yes Audio Compression PCM; G.711a; G.711Mu; G.726; G.723 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; safety exception; light alarm; sound alarm (11 built-in sounds and custom voices importing) Network Network RJ-45 (10/100 Base-T) SDK and API Yes Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade Interoperability ONVIF( Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P User/Host 20 (Total bandwidth: 80 M) Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS Browser IE: IE8 and later Chrome Firefox Safari: Safari 12 and later Management Software Smart PSS; DSS; DMSS Mobile Phone IOS; Android Certification Certification CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B Port Audio Input 1 channel (RCA port) Audio Output 1 channel (RCA port) Alarm Input 1 channel in: 5mA 3V–5V DC Alarm Output 1 channel out: 300mA 12V DC Power Power Supply 12V DC/PoE (802.3af) Power Consumption Basic power consumption: 2W (12V DC); 2.6W (PoE) Max. power consumption (H.265 + warm light + IVS + sound alarm + red and blue lights flash): 7.5W (12V DC); 8.8W (PoE) Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/Less than 95% RH Storage Conditions –40°C to +60°C (–40°F to +140°F) Protection Grade IP67 Structure Casing Metal + plastic Dimensions 288.4 mm × 94.4 mm × 84.7 mm (11.4" × 3.7" × 3.3") (L × W × H) Net Weight 1.0 kg (2.2 lb) Gross Weight 1.23 kg (2.7 lb)
