Camera Image Sensor 1/1.8” 8Megapixel progressive CMOS Max. Resolution 3840 (H) × 2160 (V) ROM 4 GB RAM 2 GB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100000 s Min. Illumination 0.003 Lux@F1.2 (Color, 30IRE) 0.0003 Lux@F1.2 (B/W, 30IRE) 0 Lux (Illuminator on) S/N Ratio > 56 dB Illumination Distance 40 m (131.23 ft) Illuminator On/Off Control Auto Illuminator Number 3 (IR LED) Pan/Tilt/Rotation Range Pan: 0°–355° Tilt: 0°–80° Rotation: 0°–355° Lens Lens Type Motorized vari-focal Mount Type Module interface Focal Length 2.7 mm-12 mm Max. Aperture F1.2 Field of View Horizontal: 114°(W)–47°(T) Vertical: 59°(W)–27°(T) Diagonal: 141° (W–55°(T) Iris Type Auto;Precise iris control Close Focus Distance w: 1 m (W: 3.28 ft) T: 2.5 m (T: 8.20 ft) DORI Distance Lens Detect Observe Recognize Identify W 87 m (285.43 ft) 34.9 m (144.50 ft) 17.4 m (57.08 ft) 8.7 m (28.54 ft) T 186.7 m (612.53 ft) 74.7 m (245.08 ft) 37.3 m (122.37 ft) 18.6 m (61.02 ft) Smart event IVS Abandoned object, moving object Professional, intelligent IVS (Perimeter Protection) Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering. Face Detection Face detection, track, priority, snapshot,Upload Optimized snapshot picture; face enhancement, face exposure, face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), Mouth mask, beard; Face matting setting: face, single inch photo Three snapshot; methods: real-time snapshot, priority snapshot, quality priority; Face angle filter Priority time setting; Support Duration Optimal,Non-living Filtering; Face Recognition There are two models: General mode and counting mode. General mode: Face detection; track; snapshot; snapshot optimization; face enhancement; face exposure; face attribute extraction including 6 attributes (gender, age, glasses, expressions, mask and beard) and 8 expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear); supports up to 5 face databases with 50,000 face pictures in total; supports non-living filtering Counting mode: Offers advanced customer counter, filtering of specified face database, and exporting of reports before and after removing duplicate faces. Face and Body Detection There are two modes: General mode and PPE Detection. General mode: Supports enabling face detection and human detection at the same time, and alarms can be triggered. PPE Detection: Supports PPE detection, can detect attributes including face mask, safety helmet, glasses, and safety vest, top color and bottom color, and determine whether PPE requirements are met. Alarms can be triggered according to the alarm settings. ANPR ANPR, track, priority, snapshot Vehicle attributes: License plate, vehicle type, vehicle color Other attributes: Seat belt, smoking, phoning Video Metadata Supports human body, human face, motor vehicle and non-motor vehicle image capture, attributes extraction, counting targets by directions (A>B, B>A, or A< >B), and exporting the report. People Counting Support tripwire number counting, people counting in area, and displaying and outputting yearly/monthly/daily reports.Support queue management, and displaying and outputting monthly/daily reports.Support 4 tripwire rules configuration, people counting in 4 areas, and 4 queue management functions Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. Video Video Compression H.265, H.264, H.264H, H.264B, MJPEG(only supported by sub stream) Smart Codec Smart H.265+/ Smart H.264+ Video Frame Rate Main Stream: 3840 × 2160 (1–25/30 fps) Sub Stream: 704 × 576 (1–25fps);704 × 480 (1–30fps) Third stream: 1920 × 1080 (1–25/30 fps) Fourth stream: 1920 × 1080 (1–25/30 fps) Fifth stream: 704 × 576 (1–25fps);704 × 480 (1–30fps) Stream Capability 5 streams Resolution 8M (3840 × 2160)/6M (3072 × 2048/3072 × 1728)/5M (2592 × 1944)/4M (2688 × 1520)/3M (2048 × 1536/2304 × 1296)/1080p(1920 × 1080)/1.3M (1280 × 960)/720p(1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 Kbps–16384 Kbps H.265: 12 Kbps–16384 Kbps Day/Night Auto (ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto/natural/street lamp/outdoor/manual/regional custom Gain Control Auto/Manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest(RoI) Yes (4 areas) Electronic Image Stabilization(EIS) Yes Smart Illumination Yes Defog Yes Image Rotation 0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower) Mirror Yes Privacy Masking 8 areas Audio Audio Compression G.711a; G.711Mu; G726; G.723 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; defocus detection; external alarm; face detection; people counting in area; stay alarm; people counting; people counting exception detection; safety exception; queue management; face & body detection; face & body detection (match attributes alarm); face & body detection (mismatch attributes alarm); face recognition Network Network RJ-45 (10/100/1000 Base-T) SDK and API Yes Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade Protocol IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P;RTMP User/Host 20(Total bandwidth: 160M) Storage FTP; Micro SD card (256 G); NAS; SFTP Browser IE: IE9 and later Chrome: Chrome 42 and later Firefox: Firefox 48.0.2 and later Management Software Smart PSS; DSS; DMSS Mobile Phone IOS, Android Certification Certifications CE-LVD: EN62368-1,EN60950-22 (optional) CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07,UL 50E NEMA Type 4X (optional) Port RS-485 1 (baud rate range: 1200 bps–115200 bps) Audio Input Audio Interface: 1/1 channel In/Out Audio Output Alarm Input 2 channel Out: 1000mA 30V DC/500mA 50V AC 3 channel In: 5mA 5V DC Alarm Output Power Power Supply 12V DC/24V AC/PoE+ (802.3at); ePoE Power Consumption Basic power consumption: 5.4W (12V DC); 5W(24V AC); 4.9W (PoE) Max. power consumption (Max. stream + intelligent function + IR LED + focus): 16.7W (12V DC);15.7W(24V AC); 15.6W (PoE) Heat power consumption: 3.3W (12V DC);5.5W(24V AC); 5.5W (PoE) Environment Operating Conditions –40°C to +60°C (–40°F to +140°F)/Less than 95% RH Storage conditions –40°C to +60°C (–40°F to +140°F) Protection Grade IP67, IK10, Anti-Corrosion Protection: NEMA 4X (optional) Structure Casing Metal+Plastic Dimensions 129.1 mm × ?157.9 mm (5.08" × ?6.22") (L × W × H) Net Weight 1500 g (3.31lb) Gross Weight 1600 g (3.53 lb) Installation Ceiling Mount; side Mount; pole Mount
