Camera Image Sensor 1/1.8” CMOS Max. Resolution 3840(H) × 2160(V) ROM 128 MB RAM 1 GB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.004 Lux@F1.4 (Color, 30IRE) 0.0004 Lux@F1.4 (B/W, 30IRE) 0 lux (Illuminator on) S/N Ratio > 56 dB Illumination Distance 50 m (164.0 ft) Illuminator On/Off Control Auto; manual Illuminator Number 2 (IR) Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° Lens Lens Type Fixed-focal Lens Mount M16 Focal Length 2.8 mm; 3.6 mm; 6 mm Max. Aperture F1.4 Field of View 2.8 mm: Horizontal 111° ; Vertical 59° ?Diagonal 131° 3.6 mm: Horizontal 87°? Vertical 47° ?Diagonal 102° 6 mm: Horizontal 55° ?Vertical 30° ?Diagonal 64° Iris Control Fixed Close Focus Distance 2.8 mm: 1.8 m (5.9 ft) 3.6 mm: 2.5 m (8.2 ft) 6 mm: 4.3 m (14.1 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 85.4 m (280.2 ft) 34.2 m (112.2 ft) 17.1 m (56.1 ft) 8.5 m (27.9 ft) 3.6 mm 106 m (347.8 ft) 42.4 m (139.1 ft) 21.2 m (69.6 ft) 10.6 m (34.8 ft) 6 mm 164.8 m (540.7 ft) 65.9 m (216.2 ft) 33 m (108.3 ft) 16.5 m (54.1 ft) Smart Event IVS Abandoned object; missing object Heat Map Yes Professional, intelligent IVS (Perimeter Protection) Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection Face Detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. People Counting Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports. Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm. Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm. Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. Audio Built-in MIC Yes Audio Compression PCM; G.711a; G.711Mu; G.726; G.723 Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) Smart Codec Smart H.265+/H.264+ Video Frame Rate Main stream: 3840× 2160 (1 fps–25/30 fps) Sub stream: D1 (1 fps–25/30 fps) Third stream: 1080p (1 fps–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 3 streams Resolution 3840 × 2160; 3072 × 2048; 3072 × 1728; 2592 × 1944; 2688 × 1520; 2048 × 1536; 2304 × 1296; 1080p (1920 × 1080); 1.3 M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 3 kbps–20480 kbps H.265: 3 kbps–20480 kbps Day/Night Auto (ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto; manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Smart Illumination Yes Defog Yes Image Rotation 0°/90°/180°/270°(Support 90°/270° with 4M resolution and lower) Mirror Yes Privacy Masking 8 areas Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; scene changing; intrusion; tripwire; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; input abnormal detection; intensity change detection; people counting; face detection; people counting in area; stay alarm; people No. exception detection; queue management Network Network Port RJ-45 (10/100 Base-T) SDK and API Yes Cyber Security Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade Network Protocol IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P User/Host 20 (Total bandwidth: 80 M) Storage FTP; SFTP; Micro SD card (Support max. 256 G); NAS Browser IE: IE8 and later Chrome Firefox Management Software Smart PSS; DSS; DMSS Mobile Client iOS; Android Certification Certifications CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 Power Power Supply 12 VDC (±30%)/PoE (802.3af)/ePoE Power Consumption Basic power consumption: 3.7W (12V DC); 4.6W (PoE) Max. power consumption (H.265 + max. stream + intelligent function + IR LED): 6.7W (12 VDC); 7.8W (PoE) Environment Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F) Protection IP67 Structure Casing Inner core: Metal Cover: Metal Decoration ring: Plastic Quick install mounting plate: Metal Product Dimensions 104.4 mm × ?121.9 mm (4.11" × ?4.80") Net Weight 500 g (1.1 lb) Gross Weight 680 g (1.5 lb)
