Camera Image Sensor 1/2.8" CMOS Max. Resolution 1920 (H) × 1080 (V) ROM 128 MB RAM 512 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.002 lux@F1.5 (Color, 30 IRE) 0.0002 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on) S/N Ratio >56 dB Illumination Distance 60 m (196.85 ft) (IR) Illuminator On/Off Control Auto Illuminator Number 4 (IR LED) Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° Lens Lens Type Motorized vari-focal Lens Mount ?14 Focal Length 2.7 mm–13.5 mm Max. Aperture F1.5 Field of View Horizontal: 109°–30° Vertical: 57°–17° Diagonal: 131°–35° Iris Control Auto Close Focus Distance 0.8 m (2.62 ft) DORI Distance Lens Detect Observe Recognize Identify W 44.1 m (144.69 ft) 17.6 m (57.74 ft) 8.8 m (28.87 ft) 4.4 m (14.44 ft) T 146.2 m (479.66 ft) 58.4 m (191.60 ft) 29.2 m (85.80 ft) 14.6 m (47.90 ft) Smart Event IVS Abandoned object; missing object Heat Map Yes Professional, intelligent IVS (Perimeter Protection) Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection SMD 3.0 Less false alarm, longer detection distance Face Detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting People Counting Tripwire people counting and people counting in area; generating and exporting report (day/month/year); queue management; 4 rules can be set for tripwire, people counting in area and queue management Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) Smart Codec Smart H.265+; Smart H.264+ AI Coding AI H.265; AI H.264 Video Frame Rate Main stream: 1920 × 1080@(1 fps–25/30 fps) Sub stream: D1@(1 fps–25/30 fps) Third stream: 1080p@(1 fps–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 3 streams Resolution 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–8192 kbps H.265: 32 kbps–8192 kbps Day/Night Auto(ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto;Manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Image Stabilization Electronic Image Stabilization (EIS) Smart Illumination Yes Defog Yes Image Rotation 0°/90°/180°/270° Mirror Yes Privacy Masking 8 areas Audio Audio Compression PCM; G.711a; G.711Mu; G.726; G.723 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; input error; voltage detection; face detection; people counting in area; stay detection; people counting; people number error detection; queue management; intensity change Network Network Port RJ-45 (10/100 Enhancement Base-T) SDK and API Yes Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone User/Host 20 (Total bandwidth: 88 M) Storage FTP; SFTP; Micro SD card (support max. 256 GB); NAS Browser IE: IE8 and later Chrome Firefox Management Software Smart PSS, DSS, DMSS Mobile Client iOS; Android Certification Certifications CE-LVD: EN 62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 Port Audio Input 1 channel (RCA port) Audio Output 1 channel (RCA port) Alarm Input 2 channels in: 5 mA 3–5 VDC Alarm Output 1 channel out: 300 mA 12 VDC Power Power Supply 12 VDC (±30%); PoE (802.3af); ePoE Power Consumption Basic: 2.5 W (12 VDC); 3.2 W (PoE) Max. (max. stream + IR LED + focus): 9.4 W (12 VDC); 10.3 W (PoE) Environment Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F) Operating Humidity ?95% Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F) Protection IP67; IK10 Structure Casing Metal + plastic Product Dimensions 273.2 mm × 95 mm × 95 mm (10.76" × 3.74" × 3.74") (L × W × H) Net Weight 1110 g (2.45 lb) Gross Weight 1510 g (3.33 lb)
