Camera Image Sensor Panorama: 1/2.8" CMOS Detail: 1/2.8" CMOS Pixel Panorama: 4 MP Detail: 4 MP Max. Resolution Panorama: 3840 (H) × 1080 (V) Detail: 2560 (H) × 1440 (V) ROM Panorama: 4 GB Detail: 4 GB RAM Panorama: 1 GB Detail: 1 GB Electronic Shutter Speed Panorama: 1/1 s–1/10,000s Detail: 1/1s–1/30,000s Scanning System Progressive Min. Illumination Panorama: Color: 0.001 lux@F1.0 B/W: 0.0001 lux@F1.0 Detail: Color: 0.005 lux@F1.6 (1/25 s, 30 IRE, gain 100) B/W: 0.0005 lux@F1.6 (1/25 s, 30 IRE, gain 100) 0 Lux (IR on) Illumination Distance Panorama: 30 m (98.43 ft) (White light) Detail: 200 m (656.17 ft) (IR) Illuminator On/Off Control Zoom Prio; Manual; Smart IR; Off Illuminator Number Panorama: 4 (White light) Detail: 4 (IR), 2 (White light) Lens Focal Length Panorama: 2.8 mm Detail: 4.8 mm–154 mm Max. Aperture Panorama: F1.0 Detail: F1.6–4.0 Field of View Panorama: H: 180° ± 5°; V: 51° Detail: H: 55.8°–2.3°; V: 31.9°–1.3°; D: 63.7°–2.7° Optical Zoom Panorama: NA Detail: 32× Focus Control Panorama: NA Detail: Auto; semi-auto; manual Close Focus Distance Panorama: 0.3 m (0.98 ft) Detail: 0.8 m–5 m (2.62 ft–16.40 ft) Iris Control Panorama: Fixed Detail: Auto; manual DORI Distance Detect Observe Recognize Identify Panorama: 38.6 m (126.64 ft) Detail: 3080 m (10104.99 ft) Panorama: 15.3 m (50.20 ft) Detail: 1216.6 m (3991.47 ft) Panorama: 7.7 m (25.26 ft) Detail: 616 m (2021.00 ft) Panorama: 3.9 m (12.80 ft) Detail: 308 m (1010.50 ft) PTZ Pan/Tilt Range Detail: H: 0°–360° endless V: –20°–+90° Manual Control Speed Detail: Pan: 0.1°/s–160°/s Tilt: 0.1°/s–120°/s Preset Speed Detail: Pan: 240°/s; Tilt: 200°/s Preset 300 Tour 8 (up to 32 presets per tour) Pattern 5 Scan 5 Power-off Memory Yes Idle Motion Pattern;Preset;Scan;Tour PTZ Protocol DH-SD Pelco-P/D(Auto recognition) Intelligence IVS (Perimeter Protection) Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking Face Detection Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first Auto Tracking Yes Active Deterrence Light Warning Supports white light warning; the flashing time can be configured as: 5 to 30 seconds, and the frequency can be configured as high/medium/low Sound Warning A total of 11 audio alarm contents, and supports importing custom audio. The sound can be configured at three levels: high/medium/low, and the duration time can be configured as 5 to 30 seconds. 110 dB. Video Video Compression H.264H;H.264B;Smart H.265+;H.265;MJPEG(Sub Stream);Smart H.264+;H.264M Streaming Capability 3 streams Resolution Panorama: 3840 × 1080; 960 × 268; D1 (704 × 576/704× 480); VGA (640 × 480); CIF (352 × 288/352 × 240); Details: 2560 × 1440 (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640× 480); CIF (352 × 288/352 × 240) Video Frame Rate Panorama: 50 Hz Main stream (3840 × 1080@25 fps), Sub stream 1 (960 × 268@25 fps), Sub stream 1 (704 × 576@25 fps), Sub stream 1 (640 × 480@25 fps), Sub stream 1 (352 × 288@25 fps), Sub stream 2 (1920 × 540@25 fps), Sub stream 2 (1920 × 1080@25 fps), Sub stream 2 (1280 × 960@25 fps), Sub stream 2 (1280 × 720@25 fps) 60 Hz Main stream (3840 × 1080@30 fps), Sub stream 1 (960 × 268@30 fps), Sub stream 1 (704 × 576@30 fps), Sub stream 1 (640 × 480@30 fps), Sub stream 1 (352 × 288@30 fps), Sub stream 2 (1920 × 540@30 fps), Sub stream 2 (1920 × 1080@30 fps), Sub stream 2 (1280 × 960@30 fps), Sub stream 2 (1280 × 720@30 fps) Details: 50 Hz Main stream (2560 × 1440@25 fps), Main stream (2048 × 1536@25 fps), Main stream (2304 × 1296@25 fps), Main stream (1920 × 1080@25 fps), Main stream (1280 × 960@25 fps), Main stream (1280 × 720@25 fps) Sub stream 1 (704 × 576@25 fps), Sub stream 1 (640 × 480@25 fps), Sub stream 1 (352 × 288@25 fps), Sub stream 2 (1280 × 720@25 fps) 60 Hz Main stream (2560 × 1440@30 fps), Main stream (2048 × 1536@30 fps), Main stream (2304 × 1296@30 fps), Main stream (1920 × 1080@30 fps), Main stream (1280 × 960@30 fps), Main stream (1280 × 720@30 fps) Sub stream 1 (704 × 480@30 fps), Sub stream 1 (640 × 480@30 fps), Sub stream 1 (352 × 240@30 fps)Sub stream 2 (1280 × 720@30 fps) Bit Rate Control CBR/VBR Video Bit Rate Panorama: H.264: 2,816 kbps-13,824 kbps H.265: 1,024 kbps-8,192 kbps Detail: H.264: 2,816 kbps-13,056 kbps H.265: 1,024 kbps-7,936 kbps Day/Night Paronama: Auto (ICR)/Color/B/W Detail: Auto (ICR)/Color/B/W BLC Yes WDR Paronama: Yes Detail: Yes HLC Yes White Balance Panorama: Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp Detail: Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp Gain Control Paronama: Auto/manual Detail: Auto/manual Noise Reduction Paronama: 2D/3D noise reduction Detail: 2D/3D noise reduction Motion Detection Yes Region of Interest (RoI) Yes Image Stabilization Electronic Image Stabilization (EIS) Defog Paronama: Electronic Defog Detail: Electronic Defog Digital Zoom 16× Image Rotation 180° S/N Ratio Paronama: ?55 dB Detail: ?55 dB Audio Audio Compression PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 Network Network Port RJ-45 (10/100 Base-T) Network Protocol FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RTP;802.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;UDP;IGMP;HTTP;SSL;DHCP;SMTP;Qos;RTSP;ARP Interoperability CGI;ONVIF (Profile S&G&T) User/Host 20 (total bandwidth: 64 M) Storage FTP; Micro SD card (up to 512 G); NAS Browser IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions iOS 10 and later versions Management Software MDSS;DSS Pro Mobile Client iOS;Android Certification Certifications CE: DHQA-ESH-P22100890/DHQA-ESH-P22100654B-A1 Port Audio Input 1 channel (LINE IN, bare wire) Audio Output 1 channel (LINE OUT, bare wire) Alarm Linkage Capture; PTZ linkage (preset; tour; pattern); recording; alarm digital input; audio; send email Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; SD card abnormal detection; memory space detection; tampering detection Alarm I/O 2/1 Audio I/O 1/1 Power Power Supply 36 VDC/2.23 A ± 25% Power Consumption Basic power consumption: 20 W Max. power consumption: 35 W (IR + heater + intelligent functions + PTZ working) Environment Operating Temperature –40 °C to +65 °C (–40 °F to +149 °F) Operating Humidity ?95% Protection IP66 Structure Casing Material Plastic, aluminum alloy Product Dimensions 247 mm × 202 mm × 359.8 mm (9.72" × 7.95" × 14.17") (L × W × H) Net Weight 5.3 kg (11.68 lb) Gross Weight 7.12 kg (15.70 lb)
