Camera Image Sensor 1/2.8" CMOS Max. Resolution 3840 (H) × 2160 (V) ROM 128 MB RAM 1 GB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.007 lux@F1.5 (Color, 30 IRE) 0.0007 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on) S/N Ratio >56 dB Illumination Distance 40 m (131.23 ft) (IR LED) Illuminator On/Off Control Auto; Manual Illuminator Number 2 (IR LED) Pan/Tilt/Rotation Range Pan: 0°–355° Tilt: 0°–75° Rotation: 0°–355° Lens Lens Type Motorized vari-focal Lens Mount ?14 Focal Length 2.7 mm–13.5 mm Max. Aperture F1.5 Field of View H: 109°–30°; V: 56°–17°; D: 131°–35° Iris Control Fixed Close Focus Distance 0.8 m (2.62 ft) DORI Distance Lens Detect Observe Recognize Identify W 88.3 m (289.70 ft) 35.3 m (119.09 ft) 17.7 m (58.07 ft) 8.8 m (28.87 ft) T 289.7 m (950.46 ft) 115.9 m (380.25 ft) 57.9 m (189.96 ft) 29.0 m (95.14 ft) Smart Event IVS Abandoned object; missing object Intelligence IVS (Perimeter Protection) Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection SMD 3.0 Less false alarm, longer detection distance Face Detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. People Counting Tripwire people counting, generating and exporting report (day/month/year); people counting in area; queue management; 4 rules can be set for tripwire, people counting in area and queue management. Heat Map Yes Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) Smart Codec Smart H.265+; Smart H.264+ AI Coding AI H.265 AI H.264 Video Frame Rate Main stream: 3840 × 2160@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) third stream: 1920 × 1080@(1–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 3 streams Resolution 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1920 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–16384 kbps H.265: 32 kbps–16384 kbps Day/Night Auto(ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB Scene Self-adaptation (SSA) Yes White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Image Stabilization Electronic Image Stabilization (EIS) Defog Yes Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) Mirror Yes Privacy Masking 4 areas Audio Audio Compression PCM; G.711a; G.711Mu; G.726; G.723 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; defocus detection; external alarm; face detection; SMD; people counting in area; stay detection; people counting; security exception Network Network Port RJ-45 (10/100 Base-T) SDK and API Yes Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec User/Host 20 (Total bandwidth: 80 M) Storage FTP; SFTP; Micro SD card (support max. 256 GB); NAS Browser IE; Chrome; Firefox Management Software Smart PSS; DSS; DMSS Mobile Client iOS; Android Cyber Security Configuration encryption; trusted execution; Digest; Security logs; WSSE; account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification Certification Certifications CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; ATEX: EN 60079-0/EN 60079-1/EN 60079-31 IECEx : IEC 60079-0/IEC 60079-1/IEC 60079-31 Certificate: ATEX: TÜV 20 ATEX 8579 X; IECEx: IECEx TUR 20.0059X Port RS-485 1 (baud rate range:1200 bps–115200 bps) Audio Input 1 channel (terminal) Audio Output 1 channel (terminal) Alarm Input 3 channels in: 5mA 3V–5V DC Alarm Output 2 channels out: 300 mA 12 VDC Power Power Supply 12 VDC/PoE (802.3af) Power Consumption Basic: 4.0 W (12 VDC); 4.7 W (PoE) Max. (H.265+intelligence on +WDR +IR on + auto focus): 7.3 W (12 VDC); 8.5 W (PoE) Environment Operating Temperature T5/T100 °C : –40 °C ? Tamb ? +60 °C (–40 °F to +140 °F) T6/T80 °C :–40 °C ? Tamb ? +55 °C (–40 °F to +131 °F) Operating Humidity ?95% Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F) Storage Humidity ?95% Protection IP68; IK10 Structure Casing Material SUS316L (316 stainless steel) Product Dimensions 219.5 mm × ?165 mm × 118.2 mm (8.64" × ?6.50" × 4.65") (L × W × H) Net Weight 4.5 kg (9.92 lb) Gross Weight 5.3 kg (11.68 lb)
