SKU: LtAP-2HnDR11e-LTE7
The MikroTik LtAP LTE7 kit combines LTE Category 7 connectivity, 2.4 GHz Wi-Fi and built-in GPS in a heavy-duty weatherproof enclosure. Its three Mini SIM slots and flexible power inputs suit the vehicle networking and tracking applications described for this model.
The LTE modem supports up to 300 Mbps download and 100 Mbps upload, with LTE Band 32 included in its supported bands. Built-in GPS supports fleet tracking, mobile video and location-aware monitoring. Two internal LTE antennas keep the installation compact, with U.FL connectors available for external LTE antennas.
Choose DC jack input, passive PoE input or the automotive power connector. Two mini PCIe slots allow expansion with an additional LTE modem, a 5 GHz interface or other supported add-ons. A Gigabit Ethernet port, USB Type-A port and RS232 serial console are provided.
RouterOS v7 provides firewalling, VPNs, VLANs, DHCP, routing policies, GPS data processing and scripting. The 2.4 GHz radio supports 802.11b/g/n with a maximum wireless data rate of 300 Mbit/s.
(LtAP-2HnDR11e-LTE7)
| Product code | LtAP-2HnD&R11e-LTE7 |
|---|---|
| Architecture | MMIPS |
| CPU | MT7621AT |
| CPU core count | 2 |
| CPU nominal frequency | 880 MHz |
| CPU Threads count | 4 |
| RouterOS license | 4 |
| Operating System | RouterOS v7 |
| Size of RAM | 128 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| Number of DC inputs | 3 (DC jack, PoE-IN, Automotive) |
|---|---|
| DC jack input Voltage | 12-30 V |
| Automotive input Voltage | 12-27 V |
| Max power consumption | 24 W |
| Max power consumption without attachments | 12 W |
| Cooling type | Passive |
| PoE in | Passive PoE |
| PoE in input Voltage | 12-30 V |
| 10/100/1000 Ethernet ports | 1 |
|---|
| Number of SIM slots | 3 Modem (Mini SIM) |
|---|---|
| Serial console port | RS232 |
| MiniPCI-e slots | 2 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 1 |
| Certification | CE, EAC, ROHS |
|---|---|
| IP | 54 |
| 3G Category | R8 (DL: 42.2 Mbps; UL: 5.76 Mbps) |
|---|---|
| 3G bands | 1 (2100 MHz) 3 (1800 MHz) 5 (850 MHz) 8 (900 MHz) |
| MIMO DL | 2x2 |
| LTE Category | 7 (DL: 300 Mbps; UL: 100 Mbps) |
| MIMO UL | 1x1 |
| LTE FDD bands | 1 (2100 MHz) 3 (1800 MHz) 5 (850 MHz) 7 (2600 MHz) 8 (900 MHz) 20 (800 MHz) 28 (700 MHz) 32 (1500 MHz) |
| LTE TDD bands | 38 (2600 MHz) 40 (2300 MHz) 41 (2500 MHz) |
| TAC | 35312597 |
| PCB temperature monitor | Yes |
|---|---|
| GNSS standards | GPS |
| Voltage Monitor | Yes |
| Wireless 2.4 GHz Max data rate | 300 Mbit/s |
|---|---|
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 2.5 |
| Wireless 2.4 GHz chip model | AR9382 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
| LTE antenna connections | Two internal LTE antennas; U.FL connectors for external antennas |
|---|---|
| GPS connection | SMA connector |
| Expansion options | Second LTE modem, 5 GHz interface or other add-ons via mini PCIe |
| SKU | LtAP-2HnDR11e-LTE7 |
| Brand | MIKROTIK |
| Shipping Weight | 3.0000kg |
