NETGEAR GS752TXP-300AUS
NETGEAR (GS324P) 48-PORT SMART MANAGED SWITCH, POE+(48), 380W, SFP(4)

Name: NETGEAR GS752TXP-300AUS 48-PORT SMART MANAGED SWITCH
Brand: Netgear
SKU: GS752TXP-300AUS
Price: 859 AUD
Availability: OutOfStock

48-Port Gigabit Ethernet Smart Switch

Number of PoE+ ports (802.3at) : 48

10G SFP+ ports : 4

Total PoE Power budget (Watts) : 380W

Overview:

All ports PoE+ with up to 760W PoE budget and Remote/Cloud Management option - Select your new network engine!

As a leading provider of network equipment for SMBs, NETGEAR® understands the importance of providing a great choice of PoE port counts and power budgets that can adapt to your business’ needs, whether in the hospitality, catering, education or retail domains.

The GS728TXPv3 and GS752TXPv3 Gigabit Ethernet Switches with PoE+ and 4 SFP+ Ports join the NETGEAR Smart switches with Cloud family, adding full 24 and 48 port PoE+ support for organizations that deploy high-density PoE+ devices and require a powerful interconnect link between access and aggregation.

Organizations who buy infrastructure for the long term and want future proofing for the unforeseeable can now select a switch with a PoE power budget of 190W over 24-port, or 380W over 48-port providing more headroom.

Temperature- and load-based fan-speed control combines accurate monitoring with minimized system acoustic noise: the GS728TXPv3 supports quiet rack mounting operation with a maximum of 26.80dBA even at full PoE power with traffic on all ports and 25°C (77°F) ambient. Following the same measurements, GS752TXPv3 is rated at 36.6dBA.

Highlights

The NETGEAR PoE+ Gigabit Smart switches with Remote/Cloud Management provides a great value, with configurable L2 network features like VLANs and PoE operation scheduling, allowing SMB customers to deploy PoEbased VoIP phones, IP cameras, videoover-IP endpoints and Wireless access points simply and securely. Advanced features such as IPv4/IPv6 Layer 3 static routing, LACP link aggregation, DiffServ QoS, Private VLANs, Multicast VLAN Registration and Spanning Tree will satisfy even the most advanced small business networks.

Key features include:

• 24-port and 48-port PoE+ with 190W and 380W total PoE budget
• 4 Dedicated 10G SFP+ ports, not only providing high-speed fiber uplinks, but also uplink redundancy and failover, improving reliability and availability for the network
• Quiet rack mounting operation with 26.80dBA to 36.6dBA at 25°C (77°F) ambient
• Layer 3 static routing with 32 routes (IPv4 and IPv6) for interVLAN local routing
• Advanced VLAN and Private VLAN support for better network segmentation
• L2/L3/L4 access control lists (ACLs) for granular network access control including 802.1x port authentication
• Advanced per port PoE controls for remote power management of PoE connected devices including operation scheduling (e.g. Wireless APs, IP security cameras, LED lighting, secure access door locks, IoT devices…)
• Advanced QoS (Quality of Service) for traffic prioritization including port-based, 802.1p and L2/L3/L4 DSCP-based
• Auto “denial-of-service” (DoS) prevention
• IGMP Snooping and Querier for multicast optimization
• Multicast VLAN Registration (MVR) for larger L2 multicast networks and AV over IP deployment
• Dynamic ARP for increased security targeting a class of Man in the Middle attack
• Rate limiting and priority queuing for better bandwidth allocation
• Port mirroring for network monitoring
• Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings
• Cable test to troubleshoot connection issues
• SNMP v1, v2c, v3 and RMON remote monitoring

Build a future-proof network with NETGEAR:

• Solid performance with non-blocking architecture, 16K MAC addresses, 256 VLANs, 100 shared (ingress) ACLs and 512 Multicast groups
• Comprehensive IPv6 supporting management, QoS, ACL and routing, ensuring investment protection and a smooth migration to IPv6-based network

Fully-integrated cloud-manageable devices

• Remote/Cloud Management capability with NETGEAR Insight. Instantly activate NETGEAR Insight Cloud management from the web GUI, for simpler configuration and deployment from anywhere using the NETGEAR Insight app on mobile devices or the Insight Cloud portal through a web browser

Smart IT, not Big IT

• Easy-to-use Web browser-based management GUI
• Network Management System (NMS300), allowing all NETGEAR business products to be deployed and managed through this single interface
• Dual firmware images improve reliability and uptime to your network
• Text-based Lite Command-line Interface (CLI)

NETGEAR quality and reliability

• Worry-free NETGEAR Limited Lifetime Warranty*, online technical chat support and Next Business Day (NBD) replacement
• 90-days Free 24x7 Advanced Technical Phone Support**

Features:

Management FEATURES

Traffic Management

Auto Negotiation of speed and duplex modes
IEEE 802.3x Flow Control
Dynamic MAC address management
IEEE 802.1Q-based VLAN
Auto Voice VLAN
Auto Video VLAN (selected models)
VLAN routing (selected models)
QoS based on WRR, strict priority, or both
Port-based and IEEE 801.2p-based QoS
TCP/UDP-based QoS
DiffServ
IPv4 and IPv6-based QoS (selected models)
DSCP Support
Rate Limiting (ingress, or egress)
Link Aggregation and LACP

Switch Management

Insight mobile app or Insight Cloud Portal
Web browser-based management GUI
Smart Lite CLI Software for multi-switch management
IP Access List
IPv6 Management
Configurable Management VLAN
SNMP v1/v2c and v3
Standard MIBs (RFC1213, RFC1643, and RFC1493)
RMON group 1, 2, 3, 9
Firmware download (to switch) and upload (to server) through TFTP/HTTP
Configuration and Image Upload (to PC) through HTTP
Configuration Download (to Switch) thru TFTP/HTTP and upload (to server)
Memory & FLASH log
Syslog (server)
System password protection

Security and More FEATURES

Security

MAC lockdown
MAC lockdown by number of MACs
IEEE 802.1x port authentication (EAP) - MD5: FS728TPv2, FS728TLP, GS108Tv2, GS110TP, GS510TP
IEEE 802.1x port authentication - EAP: GS510TLP, GS510TPP, GS418TPP, GS516TP, GS716Tv3, GS724Tv4, GS748Tv5, GS724TPv2, GS728TP, GS728TPv2, GS728TPP, GS728TPPv2, GS752TP, GS752TPv2, GS752TPP
Dynamic VLAN Assignment
Guest VLAN
TACACS+
3 HTTPS /SSL versions (except FS728TLP)
TLS session (except FS728TLP)
Trusted MAC
IPv4, L4-based Access Control List (ACL)
IPv6-based ACL (selected models)

Multicast Efficiency

IGMP snooping, v1, v2 and v3
IGMP snooping querier
Blocking of unknown multicast traffic

Spanning Tree, Routing and Stacking

IEEE 802.1D, IEEE 802.1w RSTP and MSTP
Option to enable/disable BPDU flooding when STP is disabled
Static routing with 32 static routes (Selected models)
Hosted ARP table size of 512 (Selected models)

RELIABILITY FEATURES

Reliability, Performance and Troubleshooting

Port mirroring both on ingress and egress traffic
Jumbo frame support
Broadcast Storm control
Cable diagnostics
Loop Detection
DoS Prevention
IEEE 802.1ab LLDP
LLDP-MED
Dual Image
SNTP
Option to enable/disable the flooding of EAPOL when 802.1x is disabled
Protected ports
DNS client
DHCP clients
DHCP snooping
Ping and traceroute client
Energy Efficient Ethernet (IEEE 802.3az) compliant (Selected models)

(GS752TXP-300AUS)

Specifications:

NETGEAR GS752TXP-300AUS Specifications

Technical Specification

Width : 440mm
Depth : 310mm
Height : 43.2mm
Weight : 11.08lb (5.03kg)
Model Description : 48-Port Gigabit Ethernet Smart Switch with 4 10G SFP+ Ports
10/100Mbps ports : 48
10G SFP+ ports : 4
Number of PoE+ ports (802.3at) : 48
Total PoE Power budget (Watts) : 380W
Max MAC entries : 16K
Buffer size : 1.5MB
VLAN (Number Supported) : 256
VLAN routing : Yes
Dynamic VLAN assignment : Yes
MLD Snooping : Yes
Static route : Yes
Host ARP table : 512
EEE : Yes
DoS Prevention : Yes
Internal/External Power Supply/Adapter : Internal
Max consumption without PoE (Watts) : 51W
FAN : 3
Acoustic Noise Level @25C (dBA) : 36.6dBA
Operating Temperature : 0° to 50° C
MTBF : 1,296,949 hours  (148 years)

Support & Warranty

This product is backed by a NETGEAR Limited Lifetime Hardware Warranty. Lifetime Next Business Day Hardware Replacement.

ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts.

ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat.
