Netgear MSM4310-100AJS 8x2.5G PoE++ (119W base, up to 551W) and 2x25G SFP28 Managed Switch
Model # MSM4310-100AJS
-
SKU: MSM4310-100AJS
- Pick Up Available
- Australian Warranty
- Checkout Securely
8x2.5G PoE++ (119W base, up to 551W) and 2x25G SFP28 Managed Switch
- 8 2.5G PoE++ ports with 2 25GBASE-X SFP28 uplinks.
- Comes with one APS254W power adapter providing 119W of base PoE budget.
- Half-width form factor enables one or two switches in a single rack space
- Up to three APS254W power adapters provide up to 551W PoE budget and/or N+1 redundancy
- The PoE budget can reach 551W, when the redundant PoE budget is 119W (1+1) or 322W (2+1).
- Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover.
- Layer 3 feature set includes static, policy-based, and dynamic routing.
- NETGEAR IGMP Plus™, NETGEAR AV OS, and Engage Controller speed up AV installations.
- SMPTE ST 2110 Grand Master Clock and Boundary Clock for AES67 and ST2059-2 applications.
- Multi-color LED on each physical port reflecting the profile color in the NETGEAR AV OS™ and Engage Controller.
- NETGEAR ProSAFE® Limited Lifetime Hardware Warranty.
- Lifetime Next Business Day Hardware Replacement.
(MSM4310-100AJS)
/What's Included
| Item | Quantity |
|---|---|
| M4350-8M2V (MSM4310) | 1 |
| Power cord(s) | 1 |
| Console USB Type-C cable | 1 |
| Rack-mounting standard bracket set | 1 |
| Set of longer brackets for recessed mounting | 1 |
| Rubber footpads for tabletop installation | 4 |
| Installation guide | 1 |
Technical Details
| Specification | Value |
|---|---|
| Width | 220 mm |
| Depth | 300 mm |
| Height | 43.2 mm |
| Weight | 2.9 kg (6.39 lb) |
| Primary Port Speed | 2.5 Gigabit |
| Number of Ports | 10 (8 × 2.5G PoE++, 2 × 25G SFP28) |
| Total PoE++ Ports | 8 |
| Total PoE++ Budget | 119W Base, up to 551W |
| IGMP Support | Enhanced (NETGEAR IGMP Plus™) |
| Jumbo Frame Support | Yes, up to 12 kb |
| AVB Support | Yes, included |
| Acoustics | Quiet Mode 32.1 dB @ 25ºC |
| Power Consumption (Max PoE) | 682 W / 2,324.93 Btu/hr |
| Power Consumption (Without PoE) | 82 W / 27.95 Btu/hr |
| Power Consumption (Standby, no ports) | 61.2 W / 208.6 Btu/hr |
| PSU Compatible Models | APS254W external power adapter (max. 3) |
| SKU | MSM4310-100AJS |
| Brand | Netgear |
| Shipping Weight | 2.9000kg |
Manufacturer Warranty: Limited Life Time Warranty
