8-Port 10/100Mbps Desktop Switch with 4-Port PoE TL-SF1008P With four PoE ports, transfers data and power on one single cable Working with IEEE 802.3af compliant PDs, expands home and office network Requires no configuration and installation
(TL-SG108PE)
- 8 10/100/1000Mbps ports provide instant large file transfers
- Equipped with 4 802.3af PoE ports with up to 15.4W for each port
- Supports PoE power up to 55W for all PoE ports
- IEEE 802.3x flow control provides reliable data transfers
- 15KB Jumbo frame improves performance of large data transfers
- Effective network monitoring via Port Mirroring, Loop Prevention and Cable Diagnostics
- Port/802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Abundant VLAN features improve network security via traffic segmentation
- IGMP Snooping optimizes multicast applications
- Web-based user interface and Easy Smart Configuration Utility simplify configuration
| HARDWARE FEATURES |
| Standards and Protocols |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,
IEEE 802.3x, IEEE 802.1q, IEEE 802.1p |
| Interface |
8 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX |
| Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity |
Fanless |
| Power Supply |
External Power Adapter(Output: 48VDC / 1.25A) |
| Power Consumption |
Maximum (PoE on): 65.2W (220V/50Hz)
Maximum (PoE off): 5.2W (220V/50Hz) |
| PoE+ Ports(RJ45) |
|
| PoE Ports (RJ45) |
Standard: 802.3 af compliant
PoE Ports: Port 1- Port 4
PoE Power Budget: 55W |
| PERFORMANCE |
| Switching Capacity |
16Gbps |
| Packet Forwarding Rate |
11.9Mpps |
| MAC Address Table |
4K |
| Packet Buffer Memory |
1.5Mb |
| Jumbo Frame |
15KB |
| SOFTWARE FEATURES |
| Quality of Service |
Support Port-Based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control |
| L2 Features |
IGMP Snooping V1/V2/V3
Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention |
| VLAN |
Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN |
| Management |
Web-based GUI
Easy Smart Configuration Utility |
| Transmission Method |
Store-And-Forward |
| OTHERS |
| Certification |
FCC, CE, RoHS |
| Package Contents |
TL-SG108PE
Power Adapter
Installation Guide
Resource CD
Rubber Feet |
| System Requirements |
Microsoft® Windows® for running Utility |
| Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90%RH non-condensing
Storage Humidity: 5%~95%RH non-condensing |
| SKU |
TL-SG108PE |
| Barcode # |
6935364094744 |
| Brand |
TP-LINK |
| Shipping Weight |
0.9900kg |
| Shipping Width |
0.100m |
| Shipping Height |
0.050m |
| Shipping Length |
0.180m |
| Shipping Cubic |
0.000900000m3 |
Manufacturer Warranty: 3 Year Manufacturer Warranty
