The MXTMMHQ10M High Resolution VGA Cable (10-meter) is designed to provide the highest video quality possible through VGA, ideally suited for high resolution applications of 1920x1200 and above.

This durably constructed coaxial VGA video cable (HD15 to HD15) eliminates the picture "ghosting" and fuzzy images that are inherent to non-coaxial VGA cables, while delivering superior EMI interference protection by using ferrite cores near the connector ends.

(MXTMMHQ10M)

Warranty Information
	Warranty	Lifetime
Hardware
	Cable Jacket Type	PVC - Polyvinyl Chloride
	Cable Shield Type	Aluminum-Mylar Foil with Braid
	Connector Plating	Nickel
	Fire Rating	CMG Rated (General Purpose)
	Number of Conductors	14
	Number of Ferrites	1
Connector(s)
	Connector A	1 - VGA (15 pin, High Density D-Sub) Male
	Connector B	1 - VGA (15 pin, High Density D-Sub) Male
Environmental
	Humidity	0 - 80 %RH
	Operating Temperature	0 to 60 °C
	Storage Temperature	-20 to 80 °C
Physical Characteristics
	Cable Length	32.8 ft [10 m]
	Color	Black
	Product Length	32.8 ft [10 m]
	Weight of Product	34.8 oz [987 g]
	Wire Gauge	28 AWG
Packaging Information
	Package Height	2.3 in [59 mm]
	Package Length	13 in [33 cm]
	Package Quantity	1
	Package Width	10 in [25.5 cm]
	Shipping (Package) Weight	2.2 lb [1 kg]
What's in the Box
	Included in Package	1 - 10m Coax High Resolution Monitor VGA Cable - HD15 M/M
		2 - Nuts

SKU	MXTMMHQ10M
Barcode #	65030843720
Brand	STARTECH
Shipping Weight	1.0100kg
Shipping Width	0.200m
Shipping Height	0.060m
Shipping Length	0.215m
Shipping Cubic	0.002580000m3
