StarTech 1m Coax High Resolution VGA Monitor Cable (M/M), Black - MXTMMHQ1M
Model # MXTMMHQ1M
-
SKU: MXTMMHQ1M
- Pick Up Available
- Australian Warranty
- Checkout Securely
The MXTMMHQ1M High Resolution VGA Cable (1-meter) is designed to provide the highest video quality possible through VGA, ideally suited for high resolution applications of 1920x1200 and above.
This durably constructed coaxial VGA video cable (HD15 to HD15) eliminates the picture "ghosting" and fuzzy images that are inherent to non-coaxial VGA cables, while delivering superior EMI interference protection by using ferrite cores near the connector ends.
(MXTMMHQ1M)
| Warranty Information | ||
|---|---|---|
| Warranty | Lifetime | |
| Hardware | ||
| Cable Jacket Type | PVC - Polyvinyl Chloride | |
| Cable Shield Type | Aluminum-Mylar Foil with Braid | |
| Connector Plating | Nickel | |
| Fire Rating | CMG Rated (General Purpose) | |
| Number of Ferrites | 1 | |
| Regulatory Approvals | UL2919 | |
| Performance | ||
| Impedance | 75 Ohm | |
| Connector(s) | ||
| Connector A | 1 - VGA (15 pin, High Density D-Sub) Male | |
| Connector B | 1 - VGA (15 pin, High Density D-Sub) Male | |
| Environmental | ||
| Humidity | 0 - 80 %RH | |
| Operating Temperature | 0 to 60 °C | |
| Storage Temperature | -20 to 80 °C | |
| Physical Characteristics | ||
| Cable Length | 3.3 ft [1 m] | |
| Cable OD | 0.4 in [9 mm] | |
| Color | Black | |
| Max Connector Dimension | 1.3 in [34 mm] | |
| Product Length | 3.3 ft [1 m] | |
| Weight of Product | 6.9 oz [195 g] | |
| Wire Gauge | 28 AWG | |
| Packaging Information | ||
| Package Height | 0.7 in [17 mm] | |
| Package Length | 8.7 in [22 cm] | |
| Package Quantity | 1 | |
| Package Width | 7.9 in [20 cm] | |
| Shipping (Package) Weight | 0.5 lb [0.2 kg] | |
| What's in the Box | ||
| Included in Package | 1 - 1 m Coax High Resolution Monitor VGA Cable - HD15 M/M | |
| 2 - Nuts | ||
| SKU | MXTMMHQ1M |
| Barcode # | 65030846851 |
| Brand | STARTECH |
| Shipping Weight | 0.2000kg |
| Shipping Width | 0.170m |
| Shipping Height | 0.010m |
| Shipping Length | 0.190m |
| Shipping Cubic | 0.000323000m3 |
Manufacturer Warranty: Limited Product Lifetime Warranty
