StarTech.com RK419WALLV

4U vertical 19-inch wall-mount rack bracket

A fully assembled 4U steel rack bracket for mounting compatible 19-inch equipment vertically against a wall or horizontally under a desk, rated up to 125.3 lb (56.7 kg).

4U125.3 lb / 56.7 kgVertical or under-deskLifetime warranty

StarTech RK419WALLV 4U vertical wall-mount rack bracket

Key capabilities

Vertical or under-desk mounting

Mounts compatible rack equipment vertically against a wall or horizontally under a desk.

125.3 lb / 56.7 kg capacity

The exact RK419WALLV specification lists a maximum equipment load of 125.3 lb (56.7 kg).

19-inch rack standard

Built to EIA/ECA-310-E with square cage-nut mounting holes and an L-shaped rail profile.

Fully assembled steel design

Ships assembled with 16 M5 cage nuts, 16 M5 screws and six wood screws.

What to know before buying

The included mounting screws are intended for wood surfaces. Other wall, ceiling or desk materials require suitable additional mounting hardware. Confirm the structure and equipment load before installation.

Product video

Australian version and manufacturer warranty

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com Lifetime manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

What is the StarTech RK419WALLV used for?

It provides 4U of 19-inch rack space for mounting compatible equipment vertically on a wall or horizontally under a desk.

How much weight can the RK419WALLV support?

The exact RK419WALLV specification lists a capacity of 125.3 lb (56.7 kg).

Can it be installed under a desk?

Yes. The product is designed for vertical wall mounting or horizontal under-desk installation.

What rack standard does it use?

It follows EIA/ECA-310-E with square cage-nut mounting holes.

Does it require assembly?

No. The specification states that it is not flat-packed and arrives assembled.

What hardware is included?

The package includes 16 M5 cage nuts, 16 M5 screws, six wood screws and an instruction manual.

Are the included screws suitable for every surface?

No. The supplied screws are intended for wood surfaces; other materials require suitable additional hardware.

What warranty applies to the StarTech RK419WALLV in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(RK419WALLV)

Features and highlights

Vertical or under-desk mounting

Mounts compatible rack equipment vertically against a wall or horizontally under a desk.

125.3 lb / 56.7 kg capacity

The exact RK419WALLV specification lists a maximum equipment load of 125.3 lb (56.7 kg).

19-inch rack standard

Built to EIA/ECA-310-E with square cage-nut mounting holes and an L-shaped rail profile.

Fully assembled steel design

Ships assembled with 16 M5 cage nuts, 16 M5 screws and six wood screws.

4U
125.3 lb / 56.7 kg
Vertical or under-desk
Lifetime warranty

Warranty confidence: Official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com warranty terms and assessment.

Specifications

Verified specifications for StarTech RK419WALLV.

Hardware

Warranty	Lifetime
Frame type	Open Frame
Industry standard	EIA/ECA-310-E
Mounting hole type	Square (For Cage Nut)
Mounting rail profile	L-Shape
Rack type	2-Post
U height	4U
Wallmountable	Yes

Performance and Requirements

Weight capacity	125.3 lb [56.7 kg]
Mounting note	Package includes screws for mounting to wood surfaces; additional hardware is required for other materials

Physical Characteristics

Colour	Black
Construction material	Steel
Enclosure type	Steel
Product height	7.6 in [19.3 cm]
Product length	5.9 in [15.1 cm]
Product width	19.8 in [50.4 cm]
Weight of product	2.4 lb [1.1 kg]

Packaging

Flat pack / assembly required	No
Package height	6.4 in [16.2 cm]
Package length	20.4 in [51.9 cm]
Package width	8.3 in [21.1 cm]
Shipping weight	3.7 lb [1.7 kg]

What's in the Box

Vertical wall-mount bracket	1
M5 cage nuts	16
M5 screws	16
Wood screws	6
Instruction manual	1

SKU	RK419WALLV
Barcode #	65030834414
Brand	Startech
Shipping Weight	1.6800kg
Shipping Width	0.210m
Shipping Height	0.170m
Shipping Length	0.522m
Shipping Cubic	0.018635000m3
