Wired Gigabit connection
The RJ45 port supports 10/100/1000Mbps networks through a USB 3.0 5Gbps host connection.
StarTech USB-C Gigabit Ethernet Network Adapter with PD Charging - US1GC30PD
Model # US1GC30PD
-
SKU: US1GC30PD
$78.00
Stock Availability
🟢Live
In Stock · 5+ available
Pickup from Vermont, VIC
Allow 1–2 business days for stock transfer
Allow 1–2 business days for stock transfer
- Pick Up Available
- Australian Warranty
- Checkout Securely
StarTech.com | US1GC30PD
StarTech USB-C Gigabit Ethernet Adapter with 60W PD
Add 10/100/1000Mbps Ethernet while passing up to 60W USB Power Delivery to a compatible USB-C laptop through its existing USB-C power adapter.
Gigabit Ethernet60W Power DeliveryUSB-powered
Key features at a glance
Direct, product-specific information to help confirm whether this model fits the intended setup.
60W charging pass-through
The adapter supports Power Delivery 2.0 with up to 60W listed output.
Network capabilities
Auto MDIX, full-duplex flow control, 9K jumbo frames and UASP support are listed in the supplied specifications.
Compact attached-cable design
The USB-powered adapter is designed for portable use with a compatible USB-C or Thunderbolt 3 host.
Australian version with official 2 Years warranty
Supplied by DeviceDeal and covered by the official StarTech.com manufacturer warranty in Australia. Retain your DeviceDeal tax invoice; coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
Frequently asked questions
Quick answers based on the supplied product information and specifications.
What does the StarTech US1GC30PD provide?
It provides one RJ45 Gigabit Ethernet connection and USB-C Power Delivery pass-through for a compatible host.
What network speeds are supported?
The supplied specifications list 10/100/1000Mbps Ethernet networks.
How much Power Delivery is supported?
The adapter supports up to 60W Power Delivery.
Can the Power Delivery USB-C port transfer data or video?
No. The supplied notes state that the port is for Power Delivery only and does not support data or DisplayPort Alt Mode.
What is required for charging pass-through?
The host USB-C port and connected USB-C power adapter must support USB Power Delivery 2.0.
Which operating systems are listed?
The supplied specification lists Windows 10, Windows Server 2016 and 2019, and Mac OS X 10.11 to 10.14, with VLAN tagging unsupported in Mac OS.
What is included in the package?
The package includes one USB-C adapter and one quick-start guide.
What warranty applies in Australia?
The Australian-version product supplied by DeviceDeal is covered by a two-year official StarTech.com manufacturer warranty in Australia, subject to StarTech.com terms, eligibility and product assessment.
(US1GC30PD)
Features and highlights
StarTech US1GC30PD
Wired Gigabit connection
The RJ45 port supports 10/100/1000Mbps networks through a USB 3.0 5Gbps host connection.
60W charging pass-through
The adapter supports Power Delivery 2.0 with up to 60W listed output.
Network capabilities
Auto MDIX, full-duplex flow control, 9K jumbo frames and UASP support are listed in the supplied specifications.
Compact attached-cable design
The USB-powered adapter is designed for portable use with a compatible USB-C or Thunderbolt 3 host.
- One RJ45 Gigabit Ethernet port
- One USB-C Power Delivery-only input
- Green link and yellow activity LEDs
- Optional USB-C power adapter required for charging pass-through
Warranty confidence: Australian-version product with a 2 years official StarTech.com manufacturer warranty in Australia, subject to StarTech.com terms and assessment.
Technical specifications
StarTech US1GC30PD specifications organised from the supplied product data.
Warranty Information
| Warranty | 2 Years |
|---|
Hardware
| Bus Type | USB 3.0 |
|---|---|
| Chipset ID | Realtek - RTL8153 |
| Fast-Charge Port(s) | No |
| Industry Standards | IEEE 802.3, 802.3u and 802.3ab |
| Interface | USB 3.0; RJ45 (Gigabit Ethernet) |
| Ports | 1 |
| USB-C Device Port(s) | USB Power Delivery |
| USB-C Host Connection | Yes |
Performance
| Auto MDIX | Yes |
|---|---|
| Compatible Networks | 10/100/1000 Mbps |
| Flow Control | Full duplex flow control |
| Full Duplex Support | Yes |
| Jumbo Frame Support | 9K max. |
| Maximum Data Transfer Rate | 5 Gbps (USB 3.0); 2 Gbps (Ethernet - Full-Duplex) |
| Type and Rate | USB 3.0 - 5 Gbit/s |
| UASP Support | Yes |
Connector(s)
| Connector Type(s) | 1 - USB Type-C (24 pin) USB 3.0 (5Gbps) Male; 1 - USB-C (24 pin) USB Power Delivery only Female; 1 - RJ-45 Female |
|---|
Software
| OS Compatibility | Windows® 10; Windows Server® 2016, 2019; Mac OS X® 10.11 to 10.14 VLAN tagging is currently not supported in Mac OS ; |
|---|
Special Notes / Requirements
| Note | The adapter's USB-C port is for USB Power Delivery only. It does not support DisplayPort alt mode, or data transfers.; Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host laptop's USB-C port supports USB Power Delivery 2.0; The adapter can connect to a host laptops USB-C port that doesnt support USB Power Delivery 2.0. However, in this configuration if a power adapter is connected to the hub, it will not pass power through to your host laptop.; USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps. |
|---|---|
| System and Cable Requirements | Available USB Type-C port - USB 3.0 (5Gbps) (to ensure the network adapter powers and charges your laptop, your host laptop's USB-C port must support USB Power Delivery 2.0); Optional: USB-C power adapter (for example, your laptops USB-C based power adapter) |
Indicators
| LED Indicators | 1 - Link (green); 1 - Activity (yellow) |
|---|
Power
| Power Delivery | 60W |
|---|---|
| Power Source | USB-Powered |
Environmental
| Humidity | 5% ~ 90% RH |
|---|---|
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -10°C to 80°C (14°F to 176°F) |
Physical Characteristics
| Cable Length | 0.5 in [12 mm] |
|---|---|
| Color | Black |
| Enclosure Type | Plastic |
| Product Height | 0.7 in [1.7 cm] |
| Product Length | 2.5 in [62.5 mm] |
| Product Width | 1.6 in [40 mm] |
| Weight of Product | 1.2 oz [34 g] |
Packaging Information
| Package Height | 1.3 in [32 mm] |
|---|---|
| Package Length | 6.9 in [17.4 cm] |
| Package Width | 5.8 in [14.7 cm] |
| Shipping (Package) Weight | 4 oz [113 g] |
What's in the Box
| Included in Package | 1 - USB-C adapter; 1 - quick-start guide |
|---|
| SKU | US1GC30PD |
| Barcode # | 65030867764 |
| Brand | Startech |
| Shipping Weight | 0.1100kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.170m |
| Shipping Cubic | 0.000850000m3 |
Australian version and official StarTech.com warranty
This is the Australian-version product supplied by DeviceDeal and is covered by the official StarTech.com manufacturer warranty in Australia for 2 years.
Please retain the DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
