Hardware Included Power Adapter No PoE Yes Ethernet Port 5 Optical Port 2 Ethernet Port Speed 10 Mbps/100 Mbps/1000 Mbps Optical Port Speed 1000 Mbps Console Port 1 Power Supply Mode 48 V–57 V DC Operating Temperature –40 °C to +75°C (–40 °F to +167 °F) Operating Humidity 10%–90% (RH) Power Consumption Idling: ? 9 W Full load: 120 W Performance Layer L2 Managed Yes Switching Capacity 14 Gbps Packet Forwarding Rate 10.42 Mpps Packet Buffer Size 1.75 Mbits Communication Standard IEEE 802.3i; IEEE 802.3u; IEEE 802.3ab; IEEE 802.3x; IEEE 802.3z MAC Table Size 4K Function PoE Protocol IEEE 802.3af (PoE); IEEE 802.3at (PoE+); Hi-PoE; IEEE 802.3bt PoE Power Port 1-2: ? 90 W Port 3-5: ? 30 W Total: ? 120 W PoE Power Consumption Management Power consumption management PoE power on and off Power off when PoE power is overloaded Green PoE PoE Pin Assignment 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) Long Distance PoE Transmission Yes Jumbo Frame 9,000 bytes Spanning Tree Protocol ERPS VLAN Function 802.1Q Flow Control Full-duplex flow control (back pressure) Full-duplex flow control (PAUSE) Link Aggregation Static link aggregation; LACP Port Mirroring Multiple-to-one port mirroring Multicast Yes DHCP Function DHCP client DHCP-Server DHCP-Snooping Security User management HTTPS SSH SNMP V1/V2C/V3 ACL 802.1x Loop protection QoS CoS/DPL based QoS 8 output queue for each port Port shaping SP, WRR queue scheduling DSCP-based QoS Maintenance Uploading/downloading configuration files Online upgrade System logs Device Management Web ; SNMP General Statics Protection Air discharge: 15 kV Contact discharge: 8 kV Lightning Protection Common mode: 6 kV Differential mode: 4 kV Net Weight 0.65 kg (1.43 lb) Gross Weight 2.8 kg (6.17 lb) Product Dimensions 94.4mm × 53.5 mm × 135 mm (3.7” × 2.11”× 5.31") (L × W × H) Packing Dimensions 254 mm × 187 mm × 101 mm (10.00” × 7.36”× 3.97") (L × W × H) Ordering Information Type Model Description SFP module GSFP-1310T-20-SMF 1.25G 1310/1550nm, 20km, LC, Single-mode GSFP-1310R-20-SMF 1.25G 1550/1310nm, 20km, LC, Single-mode GSFP-1310-20-SMF 1.25G 1310nm, 20km, LC, Single-mode GSFP-850-MMF 1.25G 850nm, 550m, LC, Multi-mode DIN-Rail Power Supply DRL-48V120W1AA 120W, 100VAC~240VAC-48V2.5A Note: This product does not include a power adapter, the power adapter needs to be purchased separately to use with the product. Transmission Performance: Switch power supply voltage 53V. CAT5E/CAT6. Max. DC resistance < 10 ?/100 m Cable(m) Load Capacity(W) Bandwidth(Mbps) IEEE802.3bt 90 W 100 71.3 1000 150 62 10 200 51 10 250 40 10 Hi-PoE 60 W 100 53 1000 150 50 10 200 47 10 250 37 10 IEEE802.3at 30 W 100 25.5 1000 150 25.5 10 200 25.5 10 250 25.5 10
