Basic Switching Capacity 16 Gbps Packet Forwarding Rate 11.90 Mpps Description of Function Slots Port 1-4: 4 × RJ-45 10/100/1000 Mbps (PoE) Port 5-6: 2 × RJ-45 10/100/1000 Mbps (uplink) Port 7-8: 2 × SFP 1000 Mbps (uplink) PoE Power Port 1 ? 60 W, Port 2-4 ? 30 W, total ? 60 W Layer Layer 2 Management Type Yes Operating Temperature –30 °C to +65 °C (-22 °F to +149 °F) Operating Humidity 5%–95% (RH), non-condensing Power Consumption Idling: ?4 W ; Full load: 65 W Power Supply External power supply: 53 VDC, 1.22 A Statics Protection Air discharge: 8 kV; Contact discharge: 6 kV Lighting Protection Common mode: 4 kV; Differential mode: 2 kV Net Weight 0.66 kg (1.45 lb) Product Dimensions 162 mm × 123.6 mm × 42 mm (6.38" × 4.87" × 1.65") (L × W × H) Hardware Included Power Adapter Yes PoE Yes Ethernet Port 4 Ethernet Port Speed 10/100/1000 Mbps Ethernet Port Uplink Speed 10/100/1000 Mbps Optical Port Uplink Speed 1 Gbps Debugging 1 × Console port Reset Button 1 Storage Temperature –40 °C to +70 °C (–40 °F to +158 °F) Storage Humidity 5%–95% (RH), non-condensing Performance Packet Buffer Size 4 Mbit Jumbo Frame 15K Byte MAC Table Size 8K VLAN Number 32 Communication Standard IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab Feature PoE Protocol IEEE802.3af; IEEE802.3at; Hi-PoE PoE Power Consumption Management Yes PoE Pin Assignment 1,2,4,5 (V+),3,6,7,8 (V-) Long Distance PoE Transmission Yes Spanning Tree Protocol STP/RSTP VLAN Function Port-based VLAN IEEE 802.3x Flow Control Yes DHCP Function DHCP Client Equipment Management Web management QoS/ACL Qos Equipment Management Web (http and https) SNMP V1/V2C/V3 General Gross Weight 1.37 kg (3.02 lb) Packaging Dimensions 311.5 mm × 251.5 mm × 128.5 mm (12.26" × 9.90" × 5.06") (L × W × H) Casing Material Sheet metal Installation Desktop mount; DIN-Rail mount

Manufacturer Warranty
