Camera Image Sensor 1/2.7 inch CMOS Effective Pixels 2560(H)×1440(V), 4MP Scanning System Progressive Electronic Shutter Speed PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s S/N Ratio >65dB Minimum Illumination 0.02Lux/F1.7, 30IRE, 0Lux IR on Fill Light Working Distance 30 m (98.4 ft) IR On/Off Control Auto; manual IR LED Number 2 Pan/Tilt/Rotation Range Pan: 0°–355° Tilt: 0°–75° Rotation: 0°–355° Lens Lens Type Motorized vari-focal Auto Focus N/A Mount Type ?14 Focal Length 2.7 mm-12 mm Max. Aperture F1.7 Field of View Diagonal: 38°– 127° Horizontal: 33°– 106° Vertical: 19°– 56° Iris Type Fixed iris Close Focus Distance 0.8m (2.6 ft) DORI Distance Detect Observe Recognize Identify 2.7mm 58.7m (192.6 ft) 23.5m (77.1 ft) 11.7m (38.4 ft) 5.9m (19.4 ft) 12mm 177.8m (583.3 ft) 71.1m (233.27 ft) 35.6m (116.8 ft) 17.8m (58.4 ft) Video Frame Rate CVI: PAL: 4M@25fps; 1080P@25fps; NTSC: 4M@30fps; 1080P@30fps AHD: PAL: 4M@25fps; NTSC: 4M@30fps TVI: PAL: 4M@25fps; NTSC: 4M@30fps CVBS: PAL: 960H; NTSC: 960H Resolution 4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480) Day/Night Auto switch by ICR BLC BLC/HLC/DWDR WDR DWDR White Balance Auto; manual Gain Control Auto; manual Noise Reduction 2D NR Smart IR Yes Electronic Defog Yes Mirror Off/On Privacy Masking Off/On (8 area, rectangle) Certifications Certifications CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) Port Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port Power Power Supply 12V ±30% DC Power Consumption Max 5.3W (12V DC, IR on) Environment Operating Temperature -30°C to +60°C (-22°F to 140°F);<95% (non-condensation) Storage Temperature -30°C to +60°C (-22°F to 140°F);<95% (non-condensation) Protection Grade IP67, IK10 Structure Casing Plastic dome cover+mental upper casing+mental pedestal Camera Dimensions ?122.0 mm × 88.9 mm ( ?4.80" × 3.50" ) Net Weight 0.44 Kg (0.97 lb) Gross Weight 0.7 Kg (1.54 lb)
