Camera Image Sensor 1/2.7 inch CMOS Effective Pixels 3840 (H)× 2160 (V), 4K Scanning System Progressive Electronic Shutter Speed PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s S/N Ratio >65dB Minimum Illumination 0.03Lux/F2.0, 30IRE, 0Lux IR on Fill Light Working Distance 30 m (98.4 ft) IR On/Off Control Auto; manual IR LED Number 12 Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° Lens Lens Type Fixed-focal Mount Type M12 Focal Length 2.8 mm; 3.6 mm; 6 mm Max. Aperture F2.0 Angle of View 2.8 mm: 125° x 105° x 56° (diagonal x horizontal x vertical) 3.6 mm: 104° x 87° x 47° (diagonal x horizontal x vertical) 6 mm: 62.4° x54.7° x31.3°(diagonal x horizontal x vertical) Iris Type Fixed iris Close Focus Distance 2.8 mm: 1.0 m (3.3 ft) 3.6 mm: 1.9 m (6.2 ft) 6 mm: 3.6 m (11.8 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8mm 74.7 m (245.1 ft) 29.9 m (98.1 ft) 14.9 m (48.9ft) 7.5 m (24.6 ft) 3.6mm 106.7 m (350.1 ft) 42.7 m (140.1 ft) 21.3 m (69.9 ft) 10.7 m (35.1 ft) 6mm 160m (524.9 ft) 64 m (210.0ft) 32 m (105.0ft) 16 m (52.5ft) DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. Video Frame Rate CVI: 4K@25/30fps; 4K@15fps; 5M@20fps; 4M@25fps/30fps; AHD: 4K@15fps; TVI: 4K@15fps; CVBS: 960H Resolution 4K (3840 × 2160); 5M (2592 × 1944); 4M (2560 × 1440); 960H (960 × 576/960 × 480) Day/Night Auto switch by ICR BLC BLC/HLC/WDR WDR DWDR White Balance Auto; manual Gain Control Auto; manual Noise Reduction 2D NR Smart IR Yes Mirror Off/On Privacy Masking Off/On (8 area, rectangle) Certifications Certifications CE (EN55032, EN55024, EN50130-4,EN60950-1) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) Port Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port Power Power Supply 12V ±30% DC Power Consumption Max 4.3W (12V DC, IR on) Environment Operating Temperature -40°C to +60°C (-40°F to +140°F); <95% (non-condensation) Storage Temperature -40°C to +60°C (-40°F to +140°F); <95% (non-condensation) Protection Grade IP67 Structure Casing Metal throughout the whole casing Camera Dimensions ?93.4mm×79.4mm ( ?3.68"×3.13" ) Net Weight 0.27 Kg (0.60lb) Gross Weight 0.35 Kg (0.77lb)
