Camera Image Sensor 1/2.7” 2Megapixel progressive scan CMOS Effective Pixels 1920(H) x 1080(V) RAM/ROM 128MB/16MB Scanning System Progressive Electronic Shutter Speed Auto/Manual, 1/3~1/100000s Minimum Illumination 0.02Lux/F2.1( Color,1/3s,30IRE) 0.2Lux/2.1( Color,1/30s,30IRE) 0Lux/F2.1(IR on) S/N Ratio More than 50dB IR Distance Distance up to 30m (98ft) IR On/Off Control Auto/ Manual IR LEDs 1 Lens Lens Type Fixed Mount Type Board-in Focal Length 2.8mm (3.6mm, 6mm optional) Max. Aperture F2.1 (F2.0, F2.0) Angle of View H: 115° (86°, 53°), V: 62° (47°, 30°) Optical Zoom N/A Focus Control Fixed Close Focus Distance N/A DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 40m(131ft) 16m(52ft) 8m(26ft) 4m(13ft) 3.6 mm 53m(173ft) 21m(68ft) 11m(36ft) 5m(16ft) 6.0 mm 80m(262ft) 32m(104ft) 16m(52ft) 8m(26ft) Pan/Tilt/Rotation Pan/Tilt/Rotation Range N/A Intelligence IVS N/A Advanced Intelligent Functions N/A Video Compression H.265+/H.265/H.264+/H.264 Streaming Capability 2 Streams Resolution 1080P(1920×1080)/1.3M(1280x960)/ 720P(1280×720)/D1(704×576/704×480)/ VGA(640×480)/CIF(352×288/352×240) Frame Rate Main Stream: 1080P(1~25/30fps) Sub Stream: D1(1~25/30fps) Bit Rate Control CBR/VBR Bit Rate H.264: 32~6144Kbps H.265: 12~6144Kbps Day/Night Auto(ICR) / Color / B/W BLC Mode BLC / HLC / DWDR White Balance Auto/Natural/Street Lamp/Outdoor/Manual Gain Control Auto/Manual Noise Reduction 3D DNR Motion Detetion Off / On (4 Zone, Rectangle) Region of Interest Off / On (4 Zone) Electronic Image Stabilization (EIS) N/A Smart IR Support Defog N/A Digital Zoom N/A Flip 0°/90°/180°/270° Mirror Off / On Privacy Masking Off / On (4 Area, Rectangle) Audio Compression N/A Network Ethernet -M12:M12 A-Coding(10/100Base-T) Protocol HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP Interoperability ONVIF profile S, CGI Streaming Method Unicast / Multicast Max. User Access 10 Users /20 Users Edge Storage NAS Local PC for instant recording Web Viewer IE, Chrome, Firefox, Safari Management Software Smart PSS, DSS, Easy4ip Smart Phone IOS, Android Certifications Certifications CE (EN 60950:2000) FCC: FCC Part 15 Subpart B E-mark(ECE-Regulation No.10) EN50155(Optional) Interface Video Interface N/A Audio Interface N/A RS485 N/A Alarm N/A Electrical Power Supply DC12V Power Consumption <3.7W Environmental Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH Ingress Protection IP67,IP6K9K Construction Casing Metal Dimensions 80.2mm×65.8mm×59.2mm (3.16”×2.59”×2.33”) Net Weight 0.28Kg (0.62lb) Gross Weight 0.35Kg (0.77lb)
