Camera Image Sensor 1/1.8" CMOS Max. Resolution 2688 (H) × 1520 (V) ROM 8 GB RAM 4 GB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.0005 lux@F1.2 (Color, 30 IRE) 0.0002 lux@F1.2 (B/W, 30 IRE) 0 lux (Illuminator on) S/N Ratio >56dB Illumination Distance Up to 60 m (196.85 ft) (IR LED) Illuminator On/Off Control Auto Illuminator Number 4 (IR LED) Angle Adjustment Pan: 0-360° Tilt: 0-90° Rotation: 0-360° Lens Lens Type Motorized vari-focal Lens Mount ?16 Focal Length 2.7 mm–12 mm Max. Aperture F1.2 Field of View H: 107°–48°; V: 55°–27°; D: 130°–56° Iris Control Auto Iris Control Type P-Iris Close Focus Distance 1.8 m (5.91 ft) DORI Distance Lens Detect Observe Recognize Identify W 60.4 m (198.16 ft) 24.2 m (79.39 ft) 12.1 m (39.70 ft) 6.0 m (19.69 ft) T 128.7 m (422.24 ft) 51.5 m (168.96 ft) 25.7 m (84.32 ft) 12.9 m (42.32 ft) DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. Smart Event IVS Abandoned object; missing object Intelligence IVS (Perimeter Protection) Intrusion, tripwire, fast moving (the three functons support the classifcaton and accurate detecton of vehicle, animal and human); loitering detecton, people gathering, parking detecton. Supports long- distance mode. Supports self-learning, it filters out false alarms.Supports privacy protection. Face Detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting; privacy protection Face Recognition There are two modes: General mode and counting mode. General mode: Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face or one inch photo; snapshot strategies (recognition priority and optimization snapshot); face angle filter; optimization time setting. privacy protection Supports adding 5 group face databases; registering person one by one or in batches; setting face similarity; and supports face comparison with the face database containing up to 200,000 face pictures. Counting mode: Offers advanced customer counter, filters out specified faces from the face database, and exports reports both before and after removing duplicate faces. PPE Detection Triggers alarms when the detected object matches or does not match all of the configured attributes (helmets, hats, uniforms, masks, gloves, shoe covers, shoes, safety vests, seatbelts);Supports self-learning, it detects the different colors and styles of workwear. Supports privacy protection. People Counting Tripwire people counting, generating and exporting report (day/week/month/year); people counting in area and queue management, generating and exporting report (day/week/month); 4 rules can be set for tripwire people counting, people counting in area and queue management; privacy protection Heat Map Yes ANPR ANPR: ANPR, track, priority, snapshot. Vehicle attributes: License plate, vehicle type, vehicle color. Other attributes: Seat belt, smoking, calling. Suppor up to 10,000 blocklist records and 10,000 allowlist records. The camera can recognize plate numbers of vehicles moving at speeds of up to 60km/h. Parking Space Management Parking Space Management: Manage outdoor and planned parking lots; manage parking spaces in multiple areas; display the total number of parking spaces and parking spaces that are available; trigger alarms based on a predefined number of vehicles. Video Metadata Motor vehicle, non-motor vehicle, face, and human body detection; snapshot; snapshot optimization; optimal face snapshot upload. Motor vehicle attributes: License plate, vehicle type, vehicle color, vehicle logo, seatbelt, smoking, and calling. Generates flow statistics for people, motor vehicles and non-motor vehicles based on the direction, and exports reports. Non-motor vehicle attributes: Type, vehicle color, number of people, top type and color, and hat. Human body attributes: Top and bottom type and color, bag, hat, gender and umbrella. privacy protection. Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos AcuPick Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people, animal,and motor vehicles, and search through live and recorded videos to quickly locate targets. Video Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) Smart Codec Smart H.265+; Smart H.264+ Video Frame Rate Main Stream: 2688 × 1520@(1–50/60 fps) Sub stream: 1920×1080@(1–25/30 fps) Third stream: 1920 × 1080@(1–25/30 fps) Fourth stream: 1920 × 1080@(1–25/30 fps) Fifth stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) Stream Capability 5 streams Resolution 4M (2688 × 1520); 3M (2048 × 1536); 3M (2304 × 1296) 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–10240 kbps; H.265: 12 kbps–10240 kbps Day/Night Auto(ICR)/Color/B/W BLC Yes HLC Yes WDR 150 dB Scene Self-adaptation (SSA) Yes White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Image Stabilization Electronic Image Stabilization (EIS) Smart Illumination Yes Defog Yes Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) Mirror Yes Privacy Masking 8 areas LDC Yes Time-Division Exposure Yes Audio Audio Compression G.711a; G.711Mu; PCM; G.726; G.723 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; parking space management; scene changing; audio detection; defocus detection; external alarm; face detection; face recognition; video metadata; ANPR; people counting in area; stay alarm; people counting; people number error detection; people stay detection; security exception; PPE detection Network Network Port RJ-45 (10/100/1000 Base-T) SDK and API Yes Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Register Interoperability ONVIF (Profile S/Profile G/Profile T/Profile M); CGI User/Host 20 (Total bandwidth: 340 M) Storage FTP;SFTP; Micro SD card (support max. 1 TB); NAS Browser IE: IE11 and later; Chrome: Chrome 88.0.4324.190 and later; Firefox: Firefox 47.0.2 and later; Management Software SmartPSS Lite; DSS; DMSS Mobile Client iOS; Android Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade Certification Certifications CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14; UL 50E NEMA Type 4X Port RS-485 1 (baud rate range:1200 bps–115200 bps) Audio Input 1 channel (RCA port) Audio Output 1 channel (RCA port) Alarm Input 3 channels in: wet contact, 5 mA 3–5 VDC Alarm Output 2 channels out: dry contact, 1,000 mA 30 VDC/500 mA 50 VAC Analog Output 1 channel (CVBS output: BNC) Power Output 12 VDC power output, max. current 165 mA, peak current 700 mA Power Power Supply 12 VDC/24 VAC/PoE+ (802.3at)/ePoE Power Consumption Basic: 7.3 W (12 VDC); 10.2 W (24 VAC); 10.6 W (PoE) Max. (ICR switch + IR intensity): 18.2 W (12 VDC); 24.2 W (24 VAC); 24.3 W (PoE) Heating: 3 W (12 VDC); 4.6 W (24 VAC); 5.47 W (PoE) Environment Operating Temperature –40 °C to +65 °C (–40 °F to +149 °F) Operating Humidity ?95% Storage Temperature –40 °C to +65 °C (–40 °F to +149 °F) Storage Humidity 10–95% Protection IP67; IK10; Anti-Corrosion Protection (optional) Structure Casing Material Metal + plastic Product Dimensions 345.6 mm × 134.2 mm × 135.1 mm (13.61" × 5.28" × 5.32") (L × W × H) Net Weight 1.65 kg (3.64 lb) Gross Weight 2.73 kg (6.02 lb)
