Ericsson Cradlepoint R1900 Ruggedised 5G SD-WAN Router and Security Appliance for Vehicle Deployments
Model# r1900-series
-
SKU: r1900-series
- Pick Up Available
- Australian Warranty
- Checkout Securely
Ericsson Cradlepoint R1900
Ruggedized 5G, SD-WAN, and security appliance for vehicle deployments
Firewall Throughput:
940 Mbps
WAN Connectivity:
5G Low/Mid-Band & Cat 20 LTE
LAN Connectivity:
Wi-Fi 6, GbE, Bluetooth® wireless technology
Management:
Ericsson NetCloud
Manage connectivity and security from anywhere through Ericsson NetCloud Manager
Ericsson NetCloud Manager allows you to accomplish more, faster, and with fewer resources. It’s an intuitive, easy-to-use cloud management and orchestration platform designed to simplify the configuration, deployment, operation, and troubleshooting of far-flung wireless routers. With browser and mobile application access, Ericsson NetCloud Manager enables effective management — from anywhere!
Hardware specs
 | Category | Mobile |
 | Cloud management | Yes |
 | Wireless connectivity | Dual Connectivity; 5G & Cat 20 LTE |
 | 5G status | 5G embedded |
 | Form factor | Ruggedized metal |
 | Ethernet ports | 4 GbE (LAN/WAN switchable) |
 | USB ports | 1 |
 | Serial ports | 1 |
 | Bluetooth | Yes, embedded Bluetooth version 5.2 |
 | Dual-modem support | Yes, with RX30-MC |
 | Network operator standards | PTCRB (U.S), GCF (global) |
 | Network operator certifications | AT&T, EE, T-Mobile, Verizon |
 | Regions | North America, Latin America, Europe, Africa/Middle East, Asia-Pacific |
 | Public safety networks | ESN, FirstNet Trusted, T-Mobile Connecting Heroes, Verizon Frontline |
 | Throughput | 940 Mbps (Firewall) |
 | VPN tunnel count | 10 |
 | Wi-Fi | Dual-band, dual-concurrent; 802.11ax (Wi-Fi 6) |
 | GNSS | Discrete active GNSS with dead reckoning |
 | PoE | Yes, with RX30-PoE |
 | Operating temperature | -30 °C to 75 °C (-22 °F to 167 °F) |
 | Rack mountable | No |
 | Private cellular network | Yes — CBRS, 4G LTE, 5G |
Benefits
- Deploy the ultimate 5G NR / Cat 20 LTE mobile networking solution
- Add a second cellular modem for simultaneous dual-carrier connectivity
- Take advantage of Wi-Fi 6 for the best possible connections
- Integrate into AVL systems with discrete GNSS and dead reckoning
- Extend your deployment with powerful edge compute capabilities and container support
- Enable unified edge security with application aware multizone firewalls, IDS/IPS, Internet security, and available FIPS 140-3 Level 1 and available FIPS 140-3 module in process
- Define policies through centralized cloud-based management for easy deployment at scale
Ericsson Cradlepoint R1900
Ruggedized 5G, SD-WAN, and security appliance for vehicle deployments
The purpose-built router
Hardware specs
Software features
Want to learn more about how we help organizations connect beyond traditional wired networks?
(r1900-series)
Hardware specs
| Category | Mobile |
| Cloud management | Yes |
| Wireless connectivity | Dual Connectivity; 5G & Cat 20 LTE |
| 5G status | 5G embedded |
| Form factor | Ruggedized metal |
| Ethernet ports | 4 GbE (LAN/WAN switchable) |
| USB ports | 1 |
| Serial ports | 1 |
| Bluetooth | Yes, embedded Bluetooth version 5.2 |
| Dual-modem support | Yes, with RX30-MC |
| Network operator standards | PTCRB (U.S), GCF (global) |
| Network operator certifications | AT&T, EE, T-Mobile, Verizon |
| Regions | North America, Latin America, Europe, Africa/Middle East, Asia-Pacific |
| Public safety networks | ESN, FirstNet Trusted, T-Mobile Connecting Heroes, Verizon Frontline |
| Throughput | 940 Mbps (Firewall) |
| VPN tunnel count | 10 |
| Wi-Fi | Dual-band, dual-concurrent; 802.11ax (Wi-Fi 6) |
| GNSS | Discrete active GNSS with dead reckoning |
| PoE | Yes, with RX30-PoE |
| Operating temperature | -30 °C to 75 °C (-22 °F to 167 °F) |
| Rack mountable | No |
| Private cellular network | Yes — CBRS, 4G LTE, 5G |
| SKU | r1900-series |
| Brand | ERICSSON |
| Shipping Weight | 3.3000kg |
