TP-Link Archer TX10UB Nano AX900 Nano Wi-Fi 6 Bluetooth 5.3 USB Adapter, 600 Mbps at 5 GHz + 287 Mbps at 2.4 GHz , Internal Antennas, USB 2.0
Model # ARCHER-TX10UBNANO
-
SKU: ARCHER-TX10UBNANO
- Pick Up Available
- Australian Warranty
- Checkout Securely
AX900 Nano Wi-Fi 6 Bluetooth 5.3 USB Adapter
- High Speed Wi-Fi – Up to 900 Mbps speeds with 287 Mbps on 2.4 GHz and 600 Mbps on 5 GHz, upgrades your devices to higher AX Wi-Fi speeds.
- Dual Band Wireless – 2.4GHz and 5GHz band for flexible connectivity, upgrades your devices to work with the latest dual-band Wi-Fi router for faster speed and extended range.
- Reliable Bluetooth 5.3 – Bluetooth 5.3 has been enhanced in terms of reliability and security, which ensures a more robust coordination with your game controllers, headphones, keyboards an etc.
- Nano design – Small, unobtrusive design allows you to plug it in and forget it is even there
- Operating System – Supports Windows 11/10
- Advanced Security – Supports WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK, WPA3-SAE encryption standards
(ARCHER-TX10UBNANO)
Hardware Features
| Specification | Details |
|---|---|
| Interface | USB 2.0 |
| Dimensions (W × D × H) | 19.2 × 15.7 × 7.4 mm |
| Antenna | Omni Directional |
Wireless Features
| Specification | Details |
|---|---|
| Wireless Standards | IEEE 802.11b/g/n/ax (2.4 GHz) IEEE 802.11a/n/ac/ax (5 GHz) |
| Frequency | 2.4 GHz, 5 GHz |
Signal Rates (Dynamic)
| Band | Standard | Max Speed |
|---|---|---|
| 5 GHz | 11ax | Up to 600 Mbps |
| 11ac | Up to 433 Mbps | |
| 11n | Up to 150 Mbps | |
| 11a | Up to 54 Mbps | |
| 2.4 GHz | 11ax | Up to 287 Mbps |
| 11n | Up to 200 Mbps | |
| 11g | Up to 54 Mbps | |
| 11b | Up to 11 Mbps |
Reception Sensitivity
| Band | Standard | Sensitivity |
|---|---|---|
| 5 GHz | 11a 6M | -94 dBm |
| 11ax HE80 MCS11 | -59 dBm | |
| 11ax HE80 MCS0 | -87 dBm | |
| 2.4 GHz | 11g 6M | -95 dBm |
| 11ax HE40 MCS11 | -65 dBm | |
| 11ax HE40 MCS0 | -93 dBm |
| Wireless Modes | Infrastructure Mode |
|---|---|
| Wireless Security | WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK |
| Modulation Technology | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024-QAM |
Others
| Specification | Details |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Content | - AX900 Nano Wi-Fi 6 Bluetooth 5.3 USB Adapter (Archer TX10UB Nano) - Quick Installation Guide |
| System Requirements | Windows 11 / 10 |
| Environment | Operating Temp: 0℃~40℃ (32℉~104℉) Operating Humidity: 10%~90% non-condensing |
| SKU | ARCHER-TX10UBNANO |
| Barcode # | 8885020624526 |
| Brand | TP-LINK |
| Shipping Weight | 0.1000kg |
Manufacturer Warranty: 3 Year Manufacturer Warranty
