Name: Ubiquiti AmpliFi Alien Router WiFi 6 with Alien Mesh Point - AFI-ALN
Brand: UBIQUITI
SKU: AFI-ALN
Price: 1237.26 AUD
Availability: InStock

Experience out-of-this-world WiFi range and performance with the world's only 16-stream WiFi router. Includes a MeshPoint for seamless WiFi coverage expansion.

True Gigabit Speeds

AmpliFi Alien delivers 4x the overall network capacity and 2x the coverage while reaching true gigabit speeds.

WiFi6 8x8 MIMO

3,000 ft² Coverage for Each Alien

True Gigabit Mesh

Up to 120 Connected Devices

Super Antenna Design

8x8 Super Antenna

5 GHz and 2.4 GHz Radios

Full Control in AmpliFi App

4x GbE LAN Ports

Expandable Range

Scalable Mesh System

Standalone Router covers 3,000 ft², combination with unlimited number Alien Routers for additional 3,000 ft² per device.

Simple Setup and Management

Plug-and-play solution with convenient AmpliFi mobile app.

Free VPN with Teleport

With the Teleport, you can create a VPN connection to your AmpliFi home network.

Mechanical

Dimensions

Router: 110 x 110 x 250 mm (4.3 x 4.3 x 9.8")
MeshPoint: 110 x 110 x 250 mm (4.3 x 4.3 x 9.8")

Weight

Router: 1.2 kg (2.7 lb)
MeshPoint: 1.1 kg (2.4 lb)

Enclosure material

Polycarbonate

Hardware

Processor

Quad-Core ARM® Cortex® A53s at 2.2 GHz

Memory

Router/MeshPoint: 1GB DDR3L

Management interface

WiFi
Ethernet

Networking interface

Router:
(1) GbE RJ45 WAN
(4) GbE RJ45 LAN

MeshPoint:
(1) GbE RJ45 LAN

Power method

Router/MeshPoint: Universal AC input, 100–240V AC, 1A Max., 50/60 Hz

Max. power consumption

Router: 35W
MeshPoint: 34W

ESD/EMP protection

Air/contact: ± 24kV

Max. TX power
US:
2.4 GHz
5 GHz

International:
2.4 GHz
5 GHz

23 dBm
19 dBm (low band)/ 20 dBm (high band)

23 dBm*
20 dBm**
^{*Depends from the country selected, up to 30 dBm per chain.

**Depends from the country selected, up to 24 dBm per chain.}

MIMO
US:
2.4 GHz
5 GHz

International:
2.4 GHz
5 GHz

4 x 4
4 x 4 (low band) / 8 x 8 (high band)

4 x 4
8 x 8

Speeds
US:
2.4 GHz
5 GHz

International:
2.4 GHz
5 GHz

1150 Mbps
1700 Mbps(low band) / 4800 Mbps (high band)

1148 Mbps
4800 Mbps

Antenna gain
2.4 GHz
5 GHz

3 dBi
6 dBi

Antenna

Router/MeshPoint: Internal dual-band metal stamp with 12 polarity

Display

Router: 4.7" diagonal, 274 x 1268, 279 ppi, G+F touch, full color
MeshPoint: No display

LEDs

Router/MeshPoint: Green ring

MeshPoint: Green status indicator
Flashing: initial conguration
Lights up in sequence bottom to top: Bootup in progress
Lights up in sequence from the middle outwards: WiFi not ready or connected
Steady: Device is adopted (lit based on the signal strength receiving from the router)
Flash quickly: Locate
Lights up one by one: Firmware upgrading

Button

Router/MeshPoint: Factory reset

Ambient operating temperature

-10 to 45° C (14 to 113° F)

Ambient operating humidity

5 to 95% honcondensing

Certifications

CE, FCC, IC

Software

WiFi standards

Up to WiFi 6

WiFi functions

MU-MIMO, OFDMA, TX-beamforming

Wireless security

WPA2

VLAN

Yes

Advanced QoS

Yes

Guest traffic isolation

Yes

Power save

Yes

Supported data rates

802.11a: 54 Mbps
802.11b: 11 Mbps
802.11g: 54 Mbps
802.11n: 600 Mbps + 600 Mbps
802.11ac: 1733 Mbps + 800 Mbps
802.11ax: 4800 Mpbs Router-Mesh connection (Backbone)
802.11ax: 4800 Mbps + 1148 Mbps (Available to clients)

Operating frequency*
2.4 GHz
5 GHz

2412 - 2472 MHz
5150 - 5875 MHz
* Depends on regulatory region.

Ubiquiti AmpliFi Alien Router WiFi 6 with Alien Mesh Point - AFI-ALN
