The GXP1620 is Grandstream’s standard IP phone for small businesses.

This Linux-based model features 2 lines, 3 XML programmable soft keys, HD audio and 3-way conferencing. A 132x48 LCD screen creates a clear display for easy viewing. Both the GXP1620 and GXP1625 include dual 10/100mb network ports and the GXP1625 includes integrated PoE. Additional features such as multi-language support, Electronic Hook Switch support for Plantronics headsets and call-waiting allow the GXP1620 and GXP1625 to be high quality, user-friendly and dependable IP phones.

(GXP1620)

2 dual-color line keys (with 2 SIP accounts and up to 2 call appearances), 3 XML programmable context-sensitive soft keys, 3-way conferencing, multi-language support
Automated personal information service (e.g., local weather, etc.), personalized music ring tone/ring back tone, customizable screen content/format using XML, advanced web and enterprise applications integration (pending)
Dual-switched 10/100 Mbps ports
Use with Grandstream’s UCM6100 series IP PBX appliance for Zero-Config provisioning, 1-touch call recording and more
HD wideband audio, superb dull-duplex hands-free speakerphone with advanced acoustic echo cancellation and excellent double-talk performance
Automated provisioning using TR-069 or encrypted XML configuration file, SRTP and TLS for advanced security protection, 802.1x for media access control
132 x 48 pixel backlit graphical LCD display
Large phonebook (up to 500 contacts) and call history (up to 200 records)
Network Interfaces
Dual switched auto-sensing 10/100 Mbps Ethernet ports
Graphic Display
132 x 48 backlit graphical LCD display
Feature Keys
2 line keys with dual-color LED and 2 SIP accounts, 3 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 13 dedicated function keys for MUTE, HEADSET, TRANSFER, CONFERENCE, SEND and REDIAL, SPEAKERPHONE, VOLUME, PHONEBOOK, MESSAGE, HOLD, PAGE/INTERCOM, RECORD, HOME
Voice Codecs
Support for G.711µ/a, G.722 (wideband), G.723, G.726-32, G.729 A/B, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC
HD Audio
Yes, HD handset and speakerphone with support for wideband audio
Headset Jack
RJ9 headset jack (allowing EHS with Plantronics headsets)
Base Stand
Yes, 2 angled positions available, wall mountable
Wall Mountable
Yes
Upgrade/Provisioning
Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR-069 or AES encrypted XML configuration file
Power & Green Energy Efficiency
Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA
Physical
Dimension: 209mm (L) x 184.5mm (W) x 76.2mm (H) (with handset)
Unit weight: 0.73kg
Package weight: 1.1kg
Temperature and Humidity
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing
SKU GXP1620
Barcode # 6947273701781
Brand Grandstream
Shipping Weight 1.5000kg
Shipping Width 0.210m
Shipping Height 0.080m
Shipping Length 0.260m
Shipping Cubic 0.004368000m3
Manufacturer Warranty
1 Year Limited Warranty
