Hardware Ethernet Port 4 Optical Port 0 Ethernet Port Rate 100 Mbps Number of Business Card Slots Port 1–4: 4 × RJ-45 10/100 M (PoE) Port 5–6: 2 × RJ-45 10/100 M (uplink) Power Supply 53V DC Operating Temperature –10°C to +55°C (+14°F to +131°F) Operating Humidity 5%–95% Storage Temperature –20°C to +70°C (–4°F to +158°F) Storage Humidity 5%–95% Power Consumption Idling: 1.5W Full load: 60W Performance Switching Capacity 1.80 Gbps Packet Forwarding Rate 0.89 Mpps Packet Buffer Size 1 Mbit MAC Table Size 2K Communication Standard IEEE802.3, IEEE802.3u, IEEE802.3x PoE PoE Standard IEEE802.3af/IEEE802.3at/Hi-PoE PoE Power 60W PoE Power Consumption Management Yes PoE Pin Assignment PoE/Hi-PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) Far Distance Mode 250 m @10 Mbps General ESD Air discharge: 8kV Contact discharge: 6kV Thunderproof Common mode: 2kV Differential mode: 1kV Net Weight 0.3 kg (0.66 lb) Gross Weight 0.9 kg (1.98 lb) Product Dimensions 130 mm × 85 mm × 26 mm (5.12" × 3.35" × 1.02") Packaging Dimensions 267 mm × 239 mm × 77 mm (10.51" × 9.41" × 3.03")
