Grandstream unmanaged Gigabit network switch

Grandstream GWN7701PA 8-Port Gigabit Unmanaged Network Switch with 8 PoE+ output ports

A plug-and-play unmanaged switch with 8 Gigabit RJ45 ports with 8 PoE+ output ports, auto-negotiation, auto MDI/MDIX, storm control and energy-saving operation for home offices and SMB networks.

8 × Gigabit RJ45 ports
8 × PoE+ output ports
Auto-negotiation and auto MDI/MDIX
Storm control and QoS

Grandstream GWN7701PA 8-Port Gigabit Unmanaged Network Switch with 8 PoE+ output ports GWN7701PA

Product highlights

Plug-and-play switching

Requires no configuration or software installation for straightforward network expansion.

Gigabit connectivity

8 Gigabit RJ45 ports automatically negotiate 10/100/1000Mbps link speeds.

Cable flexibility

Auto MDI/MDIX removes the need for crossover cables.

Traffic protection

Broadcast, multicast and unicast storm control helps monitor excessive traffic.

What to know before ordering

Review the stated model, capacity and compatibility details for SKU GWN7701PA. Only the specifications supplied for this exact product are shown.

Frequently asked questions

What is the Grandstream GWN7701PA?

The GWN7701PA is a 8-port unmanaged Gigabit Ethernet switch with 8 PoE+ output ports.

Does it require configuration?

No. It is designed for plug-and-play operation without configuration or software installation.

How many Gigabit ports are included?

The exact product data identifies 8 Gigabit RJ45 ports.

Does it support auto-negotiation?

Yes. Each port automatically recognises 10/100/1000Mbps device speeds.

Does it support auto MDI/MDIX?

Yes. Auto MDI/MDIX removes the need for crossover cables.

How many PoE+ output ports are included?

8 PoE+ output ports are identified for this model.

Which PoE standards are supported?

IEEE 802.3af/at support is listed, with up to 30W per PoE port.

What traffic controls are included?

Broadcast, multicast and unicast storm control plus Default Strict Priority QoS are listed.

Where can it be used?

It is intended for home offices and small-to-medium business networks.

What warranty applies?

DeviceDeal is an authorised Grandstream reseller. The applicable Grandstream manufacturer warranty is subject to Grandstream terms; no exact warranty period was supplied.

(GWN7701PA)

GWN7701PA

Features and highlights

Plug-and-play switching

Requires no configuration or software installation for straightforward network expansion.

Gigabit connectivity

8 Gigabit RJ45 ports automatically negotiate 10/100/1000Mbps link speeds.

Cable flexibility

Auto MDI/MDIX removes the need for crossover cables.

Traffic protection

Broadcast, multicast and unicast storm control helps monitor excessive traffic.

Energy efficiency

Green technology reduces power consumption.

Status visibility

LED indicators show link, activity and speed per port plus device power.

Quality of service

Default Strict Priority QoS is supported when present.

PoE+ output

8 ports provide IEEE 802.3af/at smart dynamic PoE output, up to 30W per port as supplied for this model.

Installation

The supplied family data identifies desktop and wall-mountable installation.

Key points

8 × Gigabit RJ45 ports
8 × PoE+ output ports
Auto-negotiation and auto MDI/MDIX
Storm control and QoS

Technical specifications

Grandstream GWN7701PA 8-Port Gigabit Unmanaged Network Switch with 8 PoE+ output ports

Specifications below are organised from the information supplied for SKU GWN7701PA.

Network interfaces
RJ45 ports	8 × Gigabit Ethernet
Port speeds	10/100/1000Mbps auto-negotiation
Auto MDI/MDIX	Supported
PoE
PoE output ports	8
PoE standard	IEEE 802.3af/at
Maximum per PoE port	Up to 30W stated
Operation and controls
Management	Unmanaged / plug and play
Storm control	Broadcast, multicast and unicast
QoS	Default Strict Priority when present
Energy saving	Green technology
Indicators	Per-port link/activity/speed and device power

SKU	GWN7701PA
Barcode #	6947273704607
Brand	Grandstream
Shipping Weight	1.0000kg

Manufacturer warranty

Grandstream warranty information

DeviceDeal is an authorised Grandstream reseller. This product is covered by the applicable Grandstream manufacturer warranty, subject to Grandstream warranty terms, eligibility requirements and product assessment. No exact warranty period was supplied for this SKU.

Please retain your DeviceDeal tax invoice or order record as proof of purchase for any eligible claim or service request.
