Specification:

HARDWARE FEATURES
Interfaces:
   16 PoE+ 10/100Mbps RJ45 Ports
   2 10/100/1000Mbps RJ45 Ports
   2 Combo Gigabit SFP Slots

Network Media:
   10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
   EIA/TIA-568 100Ω STP (maximum 100m)
   100BASE-TX: UTP category 5, 5e cable (maximum 100m)
   EIA/TIA-568 100Ω STP (maximum 100m)
   1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
   EIA/TIA-568 100Ω STP (maximum 100m)
   1000BASE-X MMF, SMF

Fan Quantity: 2 Fans
Power Supply: 100-240V AC, 50/60 Hz
Backup Bandwidth: 7.2 Gbps

PoE+ Ports(RJ45):
   Standard: 802.3at/802.3af compliant
   PoE Ports: Port1- Port16
   PoE Power Budget: 192W

Mac Address Table: 8K
Dimensions ( W x D x H ): 440 × 180 × 44 mm (17.3 × 7.1 × 1.7 in.)

Max Power Consumption:
   18.7 W (no PD connected)
   217.2 W (with 192W PD connected)

Max Heat Dissipation:
   63.9 BTU/h (no PD connected)
   741.2 BTU/h (with 192W PD connected)

SOFTWARE FEATURES

Advanced Features:
   Compatible with IEEE 802.3at/af compliant devices
   Port Priority Mode
   Extend Mode (Up to 250m PoE power supply and data transmission)
   Mac Address Auto-Learning And Auto-Aging
   IEEE802.3x Flow Control

Transmission Method: Store-And-Forward

OTHERS

Certification: FCC, RoHS

Package Contents:
   TL-SL1218MP
   Power Cable
   Installation Guide

Environment:
   Operating Temperature: 0°C~40°C (32°F~104°F)
   Storage Temperature: -40°C~70°C (-40°F~158°F)
   Operating Humidity: 10% ~ 90% non-condensing
   Storage Humidity: 5%~90% non-condensing

Manufacturer Warranty: 5 Years Limited Warranty
