TP-Link TL-SG1210MP 10-Port Gigabit Desktop Switch with 8-Port PoE+

•    9× gigabit RJ45 ports, and 1× gigabit combo SFP/RJ45 Port
•    8× PoE+ ports transfer data and power via a single cable with a total power budget of 123 W*
•    Compliance with IEEE 802.3af/at PoE+, the switch supports PoE Power up to 30 W for each PoE port
•    Up to 250 m data and power transmission range under Extend Mode**
•    Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive applications
•    Isolation Mode allows one-click client traffic separation for higher security and performance
•    Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto Recovery.
•    Plug and play with no configuration required
•    Fanless design reduces power consumption and works silently in its location

HARDWARE FEATURES
Interface    • 9× 10/100/1000 Mbps RJ45 Ports
• 1× 1000 Mbps Combo SFP/RJ45 Port
• AUTO Negotiation
• AUTO MDI/MDIX
Network Media    • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity    Fanless
Physical Security Lock    Yes
External Power Supply    External Power Adapter (Output: 53.5VDC / 2.43A)
Packet Forwarding Rate    14.88 Mpps
PoE Ports (RJ45)    • Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–8
• Power Supply: 123 W
Mac Address Table    4K
Jumbo Frame    16 KB
Switching Capacity    20 Gbps
Dimensions ( W x D x H )    8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)
Max Power Consumption    • 7.93 W (220V / 50Hz with no PD connected)
• 141.40 W (220V / 50Hz with 123 W PD connected)
Max Heat Dissipation    • 27.04 BTU/h (220V / 50Hz with no PD connected)
• 482.17 BTU/h (220V / 50Hz with 123 W PD connected)
SOFTWARE FEATURES
Transmission Method    Store-And-Forward
Advanced Functions    • Compatible With IEEE 802.3af/at Compliant PDs
• Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data tra

(TL-SG1210MP)

SKU TL-SG1210MP
Barcode # 6935364052683
Brand TP-LINK
Shipping Weight 5.0000kg
Manufacturer Warranty: 5 Year Manufacturer Warranty

Be The First To Review This Product!

Help other Device Deal users shop smarter by writing reviews for products you have purchased.

Write a product review

TP-Link TL-SG1210MP 10-Port Gigabit Desktop Switch with 8-Port PoE+PORT: 8× Gigabit PoE+ Ports, 2x Gigabit Non-PoE Ports, 1× Combo Gigabit SFP SlotS

Model # TL-SG1210MP

  • SKU: TL-SG1210MP

$149.00
In Stock
