Network standards

IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3x/ IEEE 802.3af/IEEE 802.3at

LED Indicator

Power
Link/Act
PoE MAX

Interfaces

(18) 1GE RJ45 ports
(2) 1GE SFP ports

Transmission media

Recommended: CAT5/5e UTP or better

Fan quantity

1

Dimension

440mm*178mm*44mm

Level of protection

Port: 6 KV
Power：6 KV

Forwarding mode

Store-and-forward

Switch capacity

40Gbps

Packet forwarding rate

29.8Mpps

Buffer

4Mb

MAC address table

8K

PoE budget

Single port: AF: 15.4W, AT: 30W
Whole device: 135W

Power consumption

150W

Input voltage

100-240V AC，50 / 60Hz

Mounting

Rack mounting : support
Desktop mounting: support
Wall mounting: support

Environment

Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Certification

FCC, CE, RoHS

Funtions

One-key to change network mode:
1.Standard: All ports can communicate with each other. It can be used as a common non-management PoE switch.
2.Priority: Ports 1 to 8 are high-priority ports, which greatly reduce packet loss and congestion when the network is congested.
3.Extend: The maximum transmission distance of the 9-16 ports of the switch can reach 250 meters, and all ports can communicate with each other.
4.VLAN: Ports 1 to 16 cannot communicate with each other, but can communicate with ports 17, 18, SFP1 (19), and SFP2 (20), which can be used to isolate broadcast storms and DHCP conflicts.
