Instant Connectivity with Reliable Performance

The NETGEAR Gigabit Unmanaged Switch series helps businesses cost-effectively expand their network to Gigabit speeds and higher port counts. These unmanaged Gigabit switches come in a wide range of models including desktop and rackmount form factors and 5 to 24 port configurations. The GS108PP supports high-power PoE for an affordable PoE solution.





High quality components and Energy Efficiency

Unmanaged Gigabit switches are built with Top Quality components to assure a long life. Unmanaged switches are built to last, and rigorously tested to provide the reliability businesses need.

NETGEAR Unmanaged Switches also support the latest Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active ports or when there is no link or no activity detected. It can further save energy when a short cable is used.

PoE+ Support (GS108PP only)

Power-Over-Ethernet (PoE) option available for powering IP Security Cameras, VoIP phones, wireless access points, and other Ethernet-powered devices.

Eight (8) PoE+ ports (up to 30W per port) allow for the connection of up to 8 PoE/PoE+ (802.3af and 802.3at) devices (up to a total PoE power budget of 123W). PoE ports may also be used for non-PoE devices.

The flexible mounting system gives you the flexibility to place the GS108PP in a desktop environment, mounted in a rack (accessories included) or wall-mounted.





(GS108PP)

Product Number

GS108PP

Product Thumbnail
Speed
  • 10/100/1000Mbps Gigabit Ethernet
Datasheet (PDF)
Number of Ports
  • 8
PoE ports
  • 8 PoE+ ports, up to 30W per port
Total PoE Budget
  • 123W
Loop Detection
  • n/a
Short cable power saving
  • n/a
Energy Efficient Ethernet Support (IEEE 802.3az)
  • Yes
Jumbo Frame Support
  • Yes
Queue WRR Ratio
  • 1:2:4:8
MAC Table Size
  • 4K
Packet buffer size
  • 192KB
IEEE 802.1p QoS
  • Yes
Dimensions (WxDxH) @mm
  • 236 x 101 x 26 mm
Weight (kg)
  • 0.6
Max Power Consumption
  • 4.9W
Operating Temperature
  • 0 to 50° C
MTBF (hours)
  • 1,044,500
FCC Class
  • B



SKU GS108PP
Barcode # 606449130027
Brand Netgear
Shipping Weight 1.5000kg
Shipping Width 0.230m
Shipping Height 0.080m
Shipping Length 0.260m
Shipping Cubic 0.004784000m3
Manufacturer Warranty
Limited Product Lifetime Warranty
Manufacturer Contact Info
http://www.netgear.com.au/
(02) 8117 6800

Great switch!

By: on 16 March 2018
Gigabit connections with 9k Jumbo Frame support and a lifetime warranty (assuming you register it online with netgear). I bought one of these about 6 years ago and it recently started only connecting at 100Mbps connections and some devices wouldn't connect at all. I took it apart, found some bulging capacitors, soldered in two new 6.3v u820 caps and it's working great again; after going through all that, I discovered the lifetime warranty; go figure... I saw some reviews stating that the switch runs hot; this is NOT the case in my experience. My switch is used 7x24 with a minimum of 10 active connections, and if never even feels warm.
