TENDA (TEF1118P-16-150W) 16FE+2GE/1SFP Desktop Switch With 16-Port PoE
Model # TEF1118P-16-150W
-
SKU: TEF1118P-16-150W
- Pick Up Available
- Australian Warranty
- Checkout Securely
TEF1118P-16-150W
16FE+2GE/1SFP Desktop Switch With 16-Port PoE
- Supports desktop and rack mounting
- Support four modes of Standard, Priority,Extend and VLAN
- Single port output power 30W, maximum output power 135W
- 2×Gigabit RJ45 ports and 1×combo SFP slot
- 16×PoE+ 10/100Mbps RJ45 ports
TEF1118P-16-150W is a unmanaged PoE switch independently designed by Tenda. Compliant with IEEE 802.3af and IEEE 802.3at standards, it can identify PoE-powered devices intelligently. With a maximum PoE power output of 150 W, and 30 W for a single port, it can supply power when transmitting data with APs, IP cameras, and IP phones. The switch supports 4 working modes, including standard, priority, extend and VLAN modes, is an ideal choice for SMBs, hotels, schools, factories with video surveillance and wireless networking requirements.
(TEF1118P-16-150W)
Hardware
Network standards
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af/at
LED Indicator
16 * Link/Act LEDs
1 * G1 LED
1 * G2/SFP2 LED
1 * PoE-MAX LED
1 * Power LED
Interfaces
16 * 10/100 Base-TX Ethernet ports (Data/Power)
2 * 10/100/1000 Base-T Ethernet ports (Data)
1 * 1000 Base-X SFP port (Combo)
Transmission media
Recommended: CAT5/5e UTP or better
Dimension
294.0mmx178.8mmx44.0mm
Level of protection
Lightning protection for ports: 6kV
Lightning protection for power: 6kV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Switch capacity
7.2 Gbps
Packet forwarding rate
5.36 Mpps
Buffer
1.25Mb
MAC address table
4K
PoE budget
Single port: AF: 15.4W, AT: 30W
Whole device: 130W
Input voltage
100-240V AC 50/60Hz
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting : support
Environment
Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Certification
FCC、CE、RoHS
| SKU | TEF1118P-16-150W |
| Barcode # | 6932849431360 |
| Brand | TENDA |
| Shipping Weight | 2.6300kg |
